Herga Technology 6210-0084 Installation Instructions

Installation Instructions for
6210-0084 USB Footswitch
• Works with the following OS: Windows™, MAC™ and Linux™
• Third party tested USB 1.1 Compliant.
• Cable length 2.5M
• Extension cables may be used as USB 1.1 is low speed
and reliable
The Herga USB footswitch is programmed by the user to simulate up to three simultaneous keystrokes.No software installation is required
as it will be recognised by the operating system once plugged into a USB socket Programming is done simply by setting small switches
inside the footswitch having removed the cover (see page 2).

General Specifications

Standards/approvals USB HID Compliant (no software drivers required)
Power 5V @ 20 mA
Temperature range 10 .... 60° C
Material Moulded Glass filled nylon plastic construction
Rating Sealed to IPX2
Weight 395 g
Reference Dimensions in mm
141
Subject to change without notice
