Industrial Electronic Devices
User Manual
Revision 2.000
English
M-Bus Slave / Modbus Master -
Converter
(Order Code: HD67059-232-B2, HD67059-485-B2)
For Website information:
www.adfweb.com?Product=HD67059
For Price information:
www.adfweb.com?Price=HD67059-232-B2
www.adfweb.com?Price=HD67059-485-B2
Benefits and Main Features:
Very easy to configure
Electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com S.r.l.
User Manual M-Bus Slave / Modbus Master - Converter
Document code: MN67059_ENG
For others M-Bus products see also the following link:
Converter M-Bus Wireless to
www.adfweb.com?Product=HD67083
Slave)
www.adfweb.com?Product=HD67084
Converter M-Bus to
www.adfweb.com?Product=HD67021
www.adfweb.com?Product=HD67022
Analyzer / Scanner /Sniffer M-Bus
www.adfweb.com?Product=HD67031
Isolator/Repeater M-Bus
www.adfweb.com?Product=HD67032M
Gateway M-Bus / Modbus TCP
www.adfweb.com?Product=HD67044
Gateway M-Bus / PROFIBUS
www.adfweb.com?Product=HD67053M
Gateway M-Bus Concentrator
www.adfweb.com?Product=HD67054M
Gateway M-Bus Slave / Modbus RTU master
www.adfweb.com?Product=HD67059M-232
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
Revision 2.000
Page 1 of 33
(Modbus TCP
(Ethernet)
(RS232)
(RS485)
Advertisement
Table of Contents
Summary of Contents for ADF HD67059-232-B2
- Page 1 Page 1 of 33 Industrial Electronic Devices User Manual Revision 2.000 English M-Bus Slave / Modbus Master - Converter (Order Code: HD67059-232-B2, HD67059-485-B2) For Website information: For others M-Bus products see also the following link: www.adfweb.com?Product=HD67059 Converter M-Bus Wireless to www.adfweb.com?Product=HD67083 (Modbus TCP...
-
Page 2: Table Of Contents
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 2 of 33 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 3 of 33 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 4 of 33 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 5 of 33 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67059-232-B2 ADFweb.com S.r.l. - Page 6 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 6 of 33 Industrial Electronic Devices Figure 1b: Connection scheme for HD67059-485-B2 ADFweb.com S.r.l.
-
Page 7: Characteristics
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 7 of 33 Industrial Electronic Devices CHARACTERISTICS: The HD67059 is a M-Bus slave to Modbus master converter. It allows the following characteristics: Electrical isolation between RS232/RS485 - M-Bus – Power Supply; Baud Rate and Parity changeable with software;... -
Page 8: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. The consumption depends to the code of the device. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device [W/VA] HD67059-232-B2 HD67059-485-B2 Warning: Not reverse the polarity power HD67059 ADFweb.com S.r.l. -
Page 9: Function Modes
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 9 of 33 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of Dip1 of ‘Dip-Switch A’ of HD67059-xxx-B2: The first, with Dip1 of ‘Dip-Switch A’... -
Page 10: Leds
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 10 of 33 Industrial Electronic Devices LEDS: The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 11: Rs232
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 11 of 33 Industrial Electronic Devices RS232: The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed). -
Page 12: Rs485
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 12 of 33 Industrial Electronic Devices RS485: To terminate the RS485 line with a 120Ω resistor, it is necessary to put dip 1 ON, like in figure. The maximum length of the cable should be 1200m (4000 feet). -
Page 13: M-Bus
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 13 of 33 Industrial Electronic Devices M-BUS: The M-Bus is a unpolarized bus. A two wire standard telephone cable (JYStY N*2*0.8 mm) is used as the transmission medium for the M- Bus. -
Page 14: Use Of Compositor Sw67059
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 14 of 33 Industrial Electronic Devices USE OF COMPOSITOR SW67059: To configure the Converter, use the available software that runs with Windows called SW67059. It is downloadable from the site www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on the web site). -
Page 15: New Configuration / Open Configuration
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 15 of 33 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “M-Bus Slave / Modbus Master - Converter”... -
Page 16: Software Options
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 16 of 33 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 17 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 17 of 33 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 18: Set Communication
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 18 of 33 Industrial Electronic Devices SET COMMUNICATION: By Pressing the “Set Communication” button from the main window for SW67059 (Fig. 2) the window “Set Communication” appears (Fig. 3). The window is divided in different sections in order to define the different parameters of the converter: Select Device... - Page 19 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 19 of 33 Industrial Electronic Devices ELECT EVICE This section is used to define hardware type used: HD67059M (Serial Update): old hardware version (6M box) HD67059-B2 (Serial Update): new hardware version (4M box) Figure 3b: “Set Communication...
- Page 20 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 20 of 33 Industrial Electronic Devices THERNET This section is used to define the general parameters of Ethernet. The means of the fields are: In the field “Ip Address”...
-
Page 21: M-Bus
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 21 of 33 Industrial Electronic Devices M-BUS By Pressing the “M-Bus” button from the main window for SW67059 (Fig. 2) the window “M-Bus Network” appears (Fig. 4). In the section “Nodes”... - Page 22 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 22 of 33 Industrial Electronic Devices ECTION ARIABLES Selecting the desired node it is possible to add a variable. In order to create a new variable it is necessary to fill these items: To use the created variable the field “Enable Variable”...
- Page 23 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 23 of 33 Industrial Electronic Devices In the field “Tariff” if it is necessary it is possible to insert the value of the tariff of that variable. The Tariff is used for indicates from which device the data come;...
- Page 24 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 24 of 33 Industrial Electronic Devices Possible choices for the fields used to create a variable: Type of Data: Function Field: |_Energy (Wh) |_Instantaneous Value |_Energy (J) |_Minimum Value |_Volume (m...
- Page 25 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 25 of 33 Industrial Electronic Devices VIFE: |_ Not Selected |_ Period of tariff months(s) |_ Credit of the nominal local legal currency units |_ Period of tariff year(s) |_ Debit of the nominal local legal currency units |_ dimensionless/ no VIF |_ Access Number (transmission count)
- Page 26 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 26 of 33 Industrial Electronic Devices |_ per second |_ Duration of limit exceed |_ per minute |_ Duration of first/last |_ per hour |_ Date(/time) of first/last begin/end |_ per day |_ Multiplicative currection factor |_ per week...
-
Page 27: Update Device
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 27 of 33 Industrial Electronic Devices UPDATE DEVICE (FOR HD67059M): By pressing the “Update Device” button it is possible to load the created Configuration into the device, and also the Firmware if is necessary, using the RS232 port. - Page 28 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 28 of 33 Industrial Electronic Devices UPDATE DEVICE (FOR HD67059-B2): By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port.
- Page 29 User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 29 of 33 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67059 device. Warning: If Fig.
-
Page 30: Mechanical Dimensions
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 30 of 33 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7: Mechanical dimensions scheme for HD67059-xxx-B2 ADFweb.com S.r.l. -
Page 31: Ordering Informations
Serial port 232: RS232 485: RS485 Device Family HD67059: M-Bus Slave / Modbus Master – Converter Order Code: HD67059-232-B2 - M-Bus Slave / Modbus Master (RS232) Order Code: HD67059-485-B2 - M-Bus Slave / Modbus Master (RS485) ACCESSORIES: Order Code: AC34011 Isolated Converter 100..240V AC to 12V DC stabilized - AC/DC... -
Page 32: Disclaimer
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 32 of 33 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 33: Warranties And Technical Support
User Manual M-Bus Slave / Modbus Master - Converter Document code: MN67059_ENG Revision 2.000 Page 33 of 33 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
