Model
UHFDCD
(TOP VIEW)
DUAL CHARGING DOCK
Specifications:
Power Supply
For Use with Models
Input: AC 100~240V, 0.4A max.
UHT8011 (Hand Held Transmitter)
Output: DC 12V, 1A
and UBP8011 (Body Pack Transmitter)
Charge Battery:
Insert the UHT8011/UBP8011 into the appropriate Charger Slot.
The Charging Indicator(s) will flash GREEN when charging and
will become continuous/solid GREEN when fully charged.
Note 1: Once AC Power is connected, the
Charging Indicator illuminates GREEN.
Note 2: Insert the UHT8011 Hand Held
Transmitter or the UBP8011 Body
Pack Transmitter into the
Charging Dock as shown
to begin charging.
Note 3: Each Charging Slot can
accept only one transmitter
type at a time.
Note 4: IMPORTANT: Please be sure
to use only the rechargeable
batteries included with the
UHFDCD. Standard alkaline
batteries should never be recharged.
(TOP VIEW)
Specifications:
Power Supply
Input: AC 100~240V, 0.4A max.
Output: DC 12V, 1A
Charge Battery:
Insert the UHT8011/UBP8011 into the appropriate Charger Slot.
The Charging Indicator(s) will flash GREEN when charging and
will become continuous/solid GREEN when fully charged.
Note 1: Once AC Power is connected, the
Charging Indicator illuminates GREEN.
Note 2: Insert the UHT8011 Hand Held
UHFDCD
DUAL CHARGING DOCK
LED Indicator
Full Charge/Stand By: Green
Charging: Flashing Green
Fault: Flashing Red
UHFDCD
DUAL CHARGING DOCK
LED Indicator
Full Charge/Stand By: Green
Charging: Flashing Green
Fault: Flashing Red
UBP8011
Charger Slots
(100-240 VAC input, 12 VDC/1A output)
UHT8011
Charger Slots
Fault
Rechargeable Batteries
Indicators
(4 rechargeable batteries included)
Charging
Indicators
Charging Time
5 hours
(2000mAh rechargeable battery)
INCLUDED ACCESSORIES
UBP8011
Charger Slots
(100-240 VAC input, 12 VDC/1A output)
UHT8011
Charger Slots
Fault
Rechargeable Batteries
Indicators
(4 rechargeable batteries included)
Charging
Indicators
Charging Time
5 hours
(2000mAh rechargeable battery)
UHFDCD-RPS Adapter
UHFDCD-RPS Adapter
www.bogen.com
