Pasco Scientific SCIENCE WORKSHOP 500 INTERFACE Instruction Sheet

Instruction Sheet
for the PASCO
Model CI-6400
SCIENCE WORKSHOP
Logging
button
Digital
channels
Indicator light
Analog input channels
Introduction
The PASCO CI-6400 ScienceWorkshop
is a data acquisition computer interface designed for
use with DataStudio ™ software and ScienceWorkshop®
sensors.
Equipment included:
•
ScienceWorkshop® 500 Interface (1)
•
9 V AC adapter (1)
•
Serial cables (2), 6 ft. each., one for a Windows -
compatible PC, and one for a Macintosh
Additional Equipment Required:
•
Computer, with Windows 3.1 or later operating
system, 1 MB RAM available; OR 1 Macintosh,
operating system 7.0 or later, and Color Quickdraw
•
PC or MAC serial cable, with USB and R232
adapter for Macintosh iMAC and Power
Macintosh G-3 computers
•
One copy of DataStudio software per interface
•
4 AA batteries (for standalone operation)
•
At least 1 ScienceWorkshop® sensor
5 0 0
P A
I n t e
S C
s c i r f a
O
e n t c e
i f i c
P A A N
A L
S C
O G
s c i
O
e n t
C H
i f i c
A N
N E
L S
S c
W o i e n
c e
r k s
h o p
3 0 0
I n t e
r f a
c e
®
500 Interface
®
500 INTERFACE
Back panel of the 500 interface
Features:
Data Logging Capability
Interface is a portable datalogger for taking measurements
in the laboratory or field. To record data, all you need is the
interface and a sensor. Students can set up an experiment
using the 500 interface, disconnect the computer to collect
data at their lab table or out of the classroom, and then
reconnect the interface to the computer to upload data for
analysis inside DataStudio.
The interface uses a 50 KB storage
50 KB Storage Buffer -
buffer to store multiple data runs and experiment setup
information.
Cross-platform Compatible
either a Macintosh or Windows-compatible computer. The
interface stores the ScienceWorkshop sensor and data display
information so it knows what experiment setup to open.
Portability and Plug-in -
field or plug the interface into your computer. The interface
operates on 4 "AA" cell batteries or a 9 V AC adapter.
012-07915A
9 V AC adapter
- The 500 ScienceWorkshop
- Logged data will open on
You can carry the interface in the
© 2001 PASCO scientific
