Summary of Contents for ELITAL EL60/IS
- Page 1 2012 EL60/IS PV MODULES - KIT SETUP INSTRUCTIONS www.elitalspa.com Rev. 02.10.2012 Z.I. Pianodardine 83100 Avellino - ITALIA EL. ITAL. S.p.A. Tel. +39 0825 621 435 Fax +39 0825 621 480 www.elitalspa.com...
- Page 2 The "CAPILLARY COMB" frame, designed developed and manufactured by HELLER SpA is patented in Europe and is mounted exclusively on EL60/IS modules produced by EL.ITAL. S.p.a. The modules are certified to the requirements of the Extended Control IEC 61215 and are tested according to IEC 61215 Extended Control as well as those of the safety standard IEC 61730.
- Page 3 MODULES EL60/IS - INSTRUCTION 2012 1 X MODULE EL60/IS with Capillary Comb frame 3 X CLAMPS drilled and V-shaped 6 X MOUNTING SCREWS FOR PROFILE Auto-Drilling and Threading screws www.elitalspa.com...
-
Page 4: Table Of Contents
4. Module Dimensions and Photovoltaic Area ........7 5. EL60/IS Modules Positioning with Capillary Comb frame ...... -
Page 5: Safety Information
2. Instructions for the transport and storage The PV modules with EL60/IS CAPILLARY COMB frame are made with high quality materials and are therefore very sturdy and long lasting. However, to avoid damage,it is suggested to leave forms in their original packaging until the installation. -
Page 6: Requirements Of The Roof
Switching on roof The modules EL60/IS with CAPILLARY COMB frame look like as standard modules, can be handled with ease on the roof and can be placed on the roof structure making sure the deformation of the fins. It is important to pay attention on the placement of the modules with sharp corners on roof coverings because they may be damaged. -
Page 7: Module Dimensions And Photovoltaic Area
MODULES EL60/IS - INSTRUCTION 2012 4. Module Dimensions and Photovoltaic Area Frame Dimension Module External Dimensions EL60/IS equipe with CAPILLARY COMB frame A = 1716 mm A = L1 + 69mm B = 1060 mm Adjacent EL60/IS Modules Overlapping with CAPILLARY COMB frame... - Page 8 MODULES EL60/IS - INSTRUCTION 2012 Adjacent EL60/IS Modules recommended distance with CAPILLARY COMB frame A - 28mm A - 28mm A - 28mm www.elitalspa.com...
-
Page 9: El60/Is Modules Positioning With Capillary Comb Frame
MODULES EL60/IS - INSTRUCTION 2012 5. EL60/IS Modules Positioning with Capillary Comb frame Solution A – Modules with long side parallel to roof top edge ROOF TOP EDGE LINEA DI COLMO ROOF TOP EDGE Solution B – Modules with short side parallel to roof top edge... - Page 10 MODULES EL60/IS - INSTRUCTION 2012 Solution C – Modules having two different leanings on the same surface ROOF TOP EDGE LINEA DI COLMO ROOF TOP EDGE Recommended Tilt Angle For tilt angles below the minimum recommended limit (10°) it is suggested to get in contact with our tecnical staff.
-
Page 11: Setup With Metallic Or Wooden Profiles
MODULES EL60/IS - INSTRUCTION 2012 6. Setup with metallic or wooden profiles Metallic or wooden profiles must be always installed in the direction of the roof slope / gutter and must be installed with a distance of 50 mm minimum in order to allow a proper aeration of the photovoltaic surface. -
Page 12: Modules Installation Sequence
MODULES EL60/IS - INSTRUCTION 2012 7. Modules Installation Sequence ROOF TOP EDGE LINEA DI COLMO 8. Preliminary operations for rooftop building The rooftop setup is charged to the customer and must be preset or renovated following the rules of an entitled designer taking care of all the static as well as thermal parameters depending on the setup place gegraphic position. - Page 13 Metallic profiles / wooden profiles must be positioned following strictly the slope, this is done to ensure a proper setup and an adequate photovoltaic surface aeration. d. EL60/IS modules positioning with Capillary Comb frame www.elitalspa.com...
-
Page 14: Exclusion Of Liability
The following instructions for the proper setup are inteded to be applied with CAPILLARY COMB frames only supplied on the EL60/IS modules for the construction of highly integrate photovoltaic plants. The audience of those instructions are companies and skilled operators authorized and trained to install such a system. - Page 15 MODULES EL60/IS - INSTRUCTION 2012 Overview components PV Module EL60/IS with CAPILLARY COMB frame FASTEN BRACKETS MODULE n° 2 brackets per module for the other modules n° 4 brackets per module for the first low line of the pv surface FASTEN BRACKET SCREW (n°...
-
Page 16: Component Overview
MODULES EL60/IS - INSTRUCTION 2012 13. INSTALLATION THROUGH PHOTOGRAPHIC DEMONSTRATION Industrial roof framework with insulation panel Transpiring membrane under tile applying www.elitalspa.com... - Page 17 MODULES EL60/IS - INSTRUCTION 2012 Placement of PV fastening outline PV fastening on underlying outlines Detail of fitted and fasten bracket www.elitalspa.com...
- Page 18 MODULES EL60/IS - INSTRUCTION 2012 PV array during assembly fetch PV surface air shaft Plumbing connection www.elitalspa.com...
-
Page 19: Installation Examples
MODULES EL60/IS - INSTRUCTION 2012 14. Installation Examples www.elitalspa.com... - Page 20 MODULES EL60/IS - INSTRUCTION 2012 www.elitalspa.com...
