  • Page 1 PP017/PP018 Passive Probe Instruction Manual...
  • Page 2 Teledyne LeCroy documentation for their own internal educational purposes. Teledyne LeCroy, HDO 4000 and HDO 6000 are registered trademarks of Teledyne LeCroy Corporation. Other product or brand names are trademarks or requested trademarks of their respective holders. Information in this publication supersedes all earlier versions.

  • Page 3: Warranty

    OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS, OR ADEQUACY FOR ANY PARTICULAR PURPOSE OR USE. TELEDYNE LECROY SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER IN CONTRACT OR OTHERWISE. THE CUSTOMER IS RESPONSIBLE FOR THE TRANSPORTATION AND INSURANCE CHARGES FOR THE RETURN OF PRODUCTS TO THE SERVICE FACILITY.

  • Page 4: Terms And Symbols

    DOUBLE INSULATION PROTECTIVE (EARTH) TERMINAL Introduction The Teledyne LeCroy PP017 and PP018 are passive high impedance voltage oscilloscope probes designed and calibrated for use with general purpose oscilloscopes having an input impedance of 1 MΩ shunted by 16 pF. However, they may be compensated for use with instruments having an input capacitance between 10 to 30 pF.

  • Page 5: Specifications

    Attn. R (MΩ) C (pF) (MHz) (ns) (pF) PP017 10 - 30 PP018 6 - 22 Attenuation Ratio ........10x (10:1) 10:1 ±0.5% Max. Input Voltage ......... 600 V CAT I or 300 V CAT II (DC + peak AC) ..............

  • Page 6: Ec Declaration Of Conformity

    PP017/PP018 Passive Probe EC Declaration of Conformity Compliance was demonstrated to the specification as listed in the Official Journal of the European Communities: Low Voltage Directive 2006/95/EC. EN 61010-031/A1:2008 Safety requirements for electrical equipment for measurement, control and laboratory use – Part 031: Safety requirements for handheld probe assemblies for electrical measurement and test.
  • Page 7 Instruction Manual Do not use in wet or explosive atmospheres. Avoid physical injury. The probe tip is extremely sharp. Use care when handling to prevent injury, including accidental skin puncture. For indoor use only. Cleaning Use the following guidelines:  Clean only the exterior of the probe, cables, and accessories.

  • Page 8: Probe Compensation

    PP017/PP018 Passive Probe Probe Compensation Proper compensation of the probe is required to assure amplitude accuracy of the waveform being measured by matching the probe to the oscilloscope’s input capacitance. Compensation should be adjusted whenever the probe is connected to or transferred between oscilloscopes.
  • Page 9 Instruction Manual High Frequency (HF) High frequency should rarely require adjustment. However, if adjustment is required: Apply a 1 MHz square wave to the probe (< 0.7 ns rise-time). Adjust the right trimmer (HF) located on the PP017probe body: or both trimmers on the PP018 BNC Box (HF2 or HF1): until you achieve a flat-topped square wave per the center illustration in the figure below.
  • Page 10 PP017/PP018 Passive Probe PP017 Input Impedance Profile PP018 Input Impedance Profile 920876-00 Rev A...

  • Page 11: China Rohs Compliance

    Instruction Manual Voltage vs. Frequency Derating Curve China RoHS Compliance Toxic or Hazardous Substances and Elements Part Name PCBAs Mechanical Hardware Sheet Metal Plastic Parts Protective Case Cable Assemblies Probe Tips O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement specified in SJ/T11363-2006.
  • Page 12 PP017/PP018 Passive Probe 920876-00 Rev A...

  • Page 13: Replaceable Parts

    Instruction Manual Replaceable Parts Item Description Quantity Sprung Hook, 5 mm, Black GND Lead w/Alligator Clip BNC Adapter, 5 mm Replacement Tip, Black Deluxe Trimmer Tool IC Tip Insulator, 5 mm, Black Tip Insulator, 5 mm, Black Identifier Rings Probe Tip GND Standard Accessory Replacement Kit part number is PKIT4-5MM-101.

  • Page 14: Contact Teledyne Lecroy

    PP017/PP018 Passive Probe Contact Teledyne LeCroy Contact your local Teledyne LeCroy office for sales and support. Teledyne LeCroy Offices World Wide United States and Canada - World Wide Corporate Office Teledyne LeCroy Corporation 700 Chestnut Ridge Road Chestnut Ridge, NY, 10977-6499...
  • Page 15 Fax: ++ 81 4 2402 9586 Fax: ++82 2 3452 0490 www.teledynelecroy.com/japan www.teledynelecroy.com.kr Singapore (Oscilloscopes) Singapore (Protocol Analyzers) Teledyne LeCroy Singapore Pte Ltd. Genetron Singapore Pte Ltd. Blk 750C Chai Chee Road #02-08 37 Kallang Pudding Road, #08-08 Technopark@ChaiChee Tong Lee Building Block B...
  • Page 16 PP017/PP018 Passive Probe 920876-00 Rev A...
