Summary of Contents for ShenZhen BigTree Technology TFT35 V3.0
- Page 1 TFT35 V3.0 User Manual SHENZHEN BIGTREE TECHNOLOGY CO., LTD. BIGTREE-TECH.COM VERSION 1.0 AUTHOR: MERT CAPKIN...
- Page 2 Product introduction TFT35 V3.0 is a medium size, dual-mode, ultra-clear 3D printer display. It is an excellent replacement for the standard 12864 LCD displays. Main features 1. ARM Cortex-M3 series STM32F207VCT6 chip with 32-bit CPU 120 MHz. 2. Users can select two work modes, they are UART serial port screen mode and 12864 screen mode.
- Page 3 Wiring Notes: 1. When using 12864 screen mode, connect the port EXP1 and EXP2 to the motherboard. There is no touch function in this mode. (If you want to use the SKR MINI E3 or SKR E3 DIP, just connect EXP3 to the motherboard.) 2.
- Page 4 Firmware The screen will be shipped with a test firmware, it can be used directly. The firmware is customizable according to your needs. You can find the needed firmware files on our Github page: http://github.com/bigtreetech Firmware update method: Firmware file name： BIGTREE_TFT35_V3.0.(version number).bin Fonts &...
