M-system MCN201 Instruction Manual

INSTRUCTION MANUAL
BEFORE USE ....
Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System's Sales Office or representatives.

■ PACKAGE INCLUDES:

Cable ....................................................................................(1)

■ MODEL NO.

Confirm Model No. marking on the product to be exactly
what you ordered.
■ INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product.
EXTERNAL DIMENSIONS & CONNECTOR PIN ASSIGNMENTS unit: mm (inch)
CODE: 1

SIDE A CONNECTOR

14 (.55)
46 (1.81)

• Connector Pin Assignments

Side A
A B
20 20
A B
1 1
CABLE
(40-pin to 20-pin)
2- M3 solderless terminal
(FG: Green)
MCN201-FT1-20
L 2 m (6.6 ft.)

• Wiring Diagram

Side B
19 20
1 2
Pins No. B1 – B20 on Side A are not connected.
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
POINTS OF CAUTION
• When you connect or disconnect the cable, be sure to hold
the connector body in order to protect the wires from
breakdown. DO NOT hold the cable in pulling it.
Side B Connector
10.4 (.41)
L
MCN201-FT1-30
3 m (9.8 ft.)
Side A
A1
A2
A3
A4
A5
:
:
A16
A17
A18
A19
A20
FG
MCN201
MODEL
6 (.24)
Side B
1
2
3
4
5
:
:
16
17
18
19
20
FG
EM-9616 Rev.2 P. 1 / 2
