Summary of Contents for Henderson Prometheus
- Page 1 INSTRUCTIONMANUAL XS-2/230V Motor Prometheus Product group: Sliding shutters, -windows, -doors, Version: Language: english Orig. Language: german Document: ------...
-
Page 2: Used Symbols
w w w . b a i e r - g m b h . d e About this document 1.4 Used Symbols Hint A hint gives important and additional information. N O T I C E Description of type and source of hazards Warnings, marked with this symbol, are related to safety. -
Page 3: Requirements For Operation
Read the instruction manual before performing the initial operation. 2.1.1 Environmental conditions The Prometheus XS-2/230 motor is designed for use in protected outdoor areas. It must not be exposed to direct moisture, such as rain. More information can be found in the datasheet. -
Page 4: Functional Description
w w w . b a i e r - g m b h . d e Functional Description 3 Functional Description Construction and Function of the Motor The motor’s internal construction consists of a 24V DC motor, the electronics and a mains adapter. - Page 5 w w w . b a i e r - g m b h . d e Functional Description Configuration and Commissioning The motor has no other setting or configuration options. It is ready for operation after installation. No additional steps are required for commissioning. Power Shutdown The integrated motor control unit serves to operate the motor until such time as it exceeds the permissible torque.
-
Page 6: Cable Installation
w w w . b a i e r - g m b h . d e Cable installation Cable installation 4.1 Cable diagrams 4.1.1 4-wire connection button On site connection Motor / (on site) open 2 (3) close power line (PE) -
Page 7: 4-Wire-Connection
w w w . b a i e r - g m b h . d e Connection 5 Connection 5.1 Completing the electrical connections Disconnect power supply secure shutdown safety instructions, see chapter 2 do connections as indicated The motor is connected 5.2 4-wire-connection Connection... -
Page 8: Wireless Receiver
w w w . b a i e r - g m b h . d e Wireless Receiver 6 Wireless Receiver An integrated wireless receiver in the engine is available for operation using one or more wireless transmitters. The wireless receiver is already installed at the factory and is ready for use without any further connections. - Page 9 w w w . b a i e r - g m b h . d e Wireless Receiver Briefly press one of the function buttons (Open, Closed or the like) on the desired wireless transmitter (<1.6 seconds) The wireless transmitter has been taught-in ...
- Page 10 w w w . b a i e r - g m b h . d e Wireless Receiver Supply motor with voltage (<0,5 seconds) and disconnect again immediately. Stop of the third turn on process Supply motor and thus wireless receiver away from voltage for min. 10 seconds ...
