Summary of Contents for Hemisphere GPS SBX-4
- Page 1 875-0176-000 SBX-4 OEM Board Integrator Guide Revision: B2 January 12, 2018...
-
Page 2: Copyright Notice
, L-Dif miniEclipse , PocketMax3 PC , PocketMax3 , PocketMax3 , S320 , SBX-4 , Vector ,and XF2 are proprietary trademarks of Hemisphere GNSS, Inc. Other trademarks are the properties of their respective owners. Patents Hemisphere GNSS products may be covered by one or more of the following patents: U.S. -
Page 3: Table Of Contents
Terms and Definitions ..........................iii Chapter 1: Introduction ..........................1 Product Overview ............................2 Chapter 2: Integrating the SBX-4 ........................3 Mechanical Layout ............................4 LED Indicators ............................. 7 SBX-4 Block Diagram ..........................8 ... -
Page 4: Terms And Definitions
Terms and Definitions The following table lists the terms and definitions used in this document Term Definition DGPS/DGNSS Differential GPS/GNSS refers to a receiver using Differential Corrections. Firmware Firmware is the software loaded into the receiver that controls the functionality of the receiver and runs the GNSS engine. -
Page 5: Chapter 1: Introduction
Chapter 1: Introduction Product Overview SBX-4 Integrator Guide Chapter 1 - Introduction Page 1 of 22... -
Page 6: Product Overview
This document provides instructions and recommendations related to a successful integration of the SBX-4 engine. The SBX-4 is an extremely sensitive 300 kHz minimum shift keying (MSK) demodulator. It obtains differential GPS corrections broadcast by radio beacons adhering to standards such as International Telecommunications Union M.823 and various broadcast standards in the frequency... -
Page 7: Chapter 2: Integrating The Sbx-4
SBX-4 Connector Pin Assignments Signal Lock Indicator Pin Reset Pin Antenna Interface Radio Frequency Immunity and Emissions SBX-4 Dual Serial Port Overview Factory Default Settings SBX-4 Integration Summary SBX-4 Integrator Guide Chapter 2 – Integrating the SBX-4 Page 3 of 22... -
Page 8: Mechanical Layout
Chapter 2: Integrating the SBX-4 OEM Board Mechanical Layout Figures 1-1 to 1-3 provide the physical layout of the SBX-4 beacon receiver, including dimensions and key components. Note: Figure 1-1 to Figure1-3 dimensions are in inches. Figure 1-1: Top-side view of SBX-4... - Page 9 Figure 1-2: SBX-4 bottom view SBX-4 Integrator Guide Chapter 2-Integrating the SBX-4 Page 5 of 22...
- Page 10 Figure 1-3: SBX-4 side view SBX-4 Integrator Guide Chapter 2-Integrating the SBX-4 Page 6 of 22...
-
Page 11: Led Indicators
When power is applied to the SBX-4, the power LED illuminates and when the SBX-4 achieves signal acquisition on a valid DGPS beacon, the lock LED illuminates. Figure 1-4 shows the front and back of the SBX-4, including the illumination of the power and lock LED indicators. -
Page 12: Sbx-4 Block Diagram
SBX-4 Block Diagram The SBX-4 accepts an analog input signal between 283.5 kHz and 325.0 kHz from an antenna into its front end where it is filtered and converted to a digital output. The Digital Signal Processor (DSP) demodulates GPS correction information from the digital stream. The output of the SBX-4 is RTCM SC-104 DGPS correction data at a 3.3V CMOS interface level. -
Page 13: Sbx-4 Connector Pin Assignments
SBX-4 Connector Pin Assignments The SBX-4 has two header connectors designated as J200 and J300, labeled with on-board silk- screening. The J200 connector is a 1 x 4 pin header with 0.1 in (2.54 cm) spacing that provides antenna power input, and signal distribution. The J300 connector is a 2 x 12 pin header with 0.1 in (2.54 cm) spacing that provides access to antenna power input, receiver serial ports, receiver... -
Page 14: Signal Lock Indicator Pin
Signal Lock Indicator Pin Pin 16 of connector J300 may be used to drive an LED or sensor to indicate that the SBX-4 is locked to a beacon signal and is demodulating RTCM SC-104 data. The maximum current available from this pin is 5 mA at an input voltage 3.3 V. -
Page 15: Reset Pin
Reset Pin Pin 19 of connector J300 may be used to reset the SBX-4. Activating the reset circuit of the SBX- 4 results in the same effect as cycling the input power to the receiver. The operating configuration of the receiver before reset is maintained, including operating mode, baud rate, frequency and MSK rate of the last tuned station. -
Page 16: Antenna Interface
Pin 4 of connector J200 is internally connected to Pins 1 and 2 of connector J300. Antenna signal input to the receiver is provided via Pin 2 of J200. Note: The antenna input voltage is not current limited on the SBX-4 board. If current limiting is required, the circuitry must be provided within your integration. -
Page 17: Sbx-4 Dual Serial Port Overview
SBX-4 Dual Serial Port Overview The SBX-4 features two full duplex serial ports (Port 0 and Port 1). Use of the second serial port is an option as the SBX-4 supports identical functionality as its predecessor, the SBX-3 on Port 0. -
Page 18: Factory Default Settings
The following steps summarize the general requirements for integrating the SBX-4 and identifies the command and control features provided: SBX-4 Power Input - Apply a 3.3 VDC power input to Pin 3 of J300 with the power- return connection at Pin 21 of J300. - Page 19 $PCSI,F2835,0,R100,0,C0,0 $PCSI,F2835,0,R100,0,C1,0 6. When powered for the first time, the SBX-4 will operate in the default ABS mode and will conduct a Global Search (GS) to identify the highest quality beacon signal. Following the signal acquisition phase of the GS and when the primary receiver channel has acquired a beacon, the receiver’s second channel will conduct a...
-
Page 20: Chapter 3: Sbx-4 Operation
Chapter 3: SBX-4 Operation Introduction Beacon Information Operating Modes New SBX-4 Commands Evaluating Performance SBX-4 Integrator Guide Chapter 3 – SBX-4 Operation Page 16 of 22... -
Page 21: Introduction
The SBX-4 is able to operate in manual or automatic tuning mode, or using Database mode which will select the closest station in compliance with IEC 61108-4 standards. In Database mode, the receiver will search for the closest station based on its current location and distance to the internal list of station locations. -
Page 22: Operating Modes
ABS Global Search When powered for the first time in ABS mode, the SBX-4 initiates a Global Search (GS), examining each available DGPS beacon frequency, and recording Signal Strength (SS) measurements in units of decibel micro volts to the Global Search Table. The receiver uses these measured values to compute an average SS, noise floor and to sort the frequencies in descending order of SS. -
Page 23: Abs Background Search
15 seconds. Database Mode This operating mode has been added to the SBX-4 in order to be compliant with the specification IEC 61108-4 for ship borne DGPS maritime radio beacon receiver equipment. The basic operation is outlined below. -
Page 24: New Sbx-4 Commands
NEW SBX-4 Commands Database tune command: $GPMSK,,D,,D<CR><LF> Display contents of station database: $PCSI,3,3<CR><LF> Response: $PCSI,3,3,IDref1,IDref2,StationID,name,freq,lat,long,datum,s tatus $PCSI,3,3, ... $PCSI,3,3, ... $PCSI,3,3, ... Example: $PCSI,3,3,0282,0283,0891,Level Island AK,2950,20554,- 24221,1,0 $PCSI,3,3,0306,0307,0906,Sandspit BC,3000,19377,- 23991,1,0 $PCSI,3,3,0278,0279,0889,Annette Is. AK,3230,20044,- 23951,1,0 $PCSI,3,3,0300,0301,0909,Alert Bay BC,3090,18412,- 23099,1,0 $PCSI,3,3,0302,0303,0908,Amphitrite Pt BC,3150,17806,- 22850,1,0 $PCSI,3,3,0270,0271,0885,C. - Page 25 Status: 0 (operational), 1 (undefined), 2 (no information), 3 (do not use) • Health: -1 (not updated), 8 (undefined), 0-7 (valid range) • WER: -1 (not updated), 0-100 (valid range) Status message: $PCSI,1,1<CR><LF> • SBX-4 Integrator Guide Appendix A-Troubleshooting Page A5...
-
Page 26: Evaluating Performance
If noise is affecting performance, try to find a better location with higher SNR. Table 2-1 describes the general quality of reception as measured by the SNR reading of the SBX-4. Table 2-1: SBX-4 Performance - SNR reading... -
Page 27: Appendix A: Troubleshooting
Appendix A: Troubleshooting SBX-4 Integrator Guide Appendix A-Troubleshooting Page A7... - Page 28 Appendix A: Troubleshooting Table A-1 provides troubleshooting for common SBX-4 problems. Table A-1: Troubleshooting Symptom Possible solution No data from SBX-4 • Check receiver power status (power LED illuminated?) • Verify that SBX-4 is locked to a valid beacon (Lock LED illuminated) •...
- Page 29 • Verify frequency of transmitting beacon or choose Auto Frequency Mode • Check MBA-3 antenna • Verify SBX-4 antenna port output voltage (5 VDC) • Verify 5 VDC across antenna cable connector No response to NMEA • Verify baud rate settings of...
-
Page 30: Appendix B: Technical Specifications
Appendix B: Technical Specifications SBX-4 Integrator Guide Appendix B-Technical Specifications Page B1... -
Page 31: Sbx-4 Specifications
Appendix B: Technical Specifications SBX-4 Specifications Tables B-1 to B-5 provide the SBX-4’s operational, serial interface, power, mechanical and environmental specifications. Table B-1: Operational Item Specification Channels 2-channel parallel tracking Frequency range 283.5 - 325.0 kHz Channel spacing 500 Hz... - Page 32 -30° C to +70° C (-22° F to +158° F) Operating temperature -40° C to +80° C (-40° F to +176° F) Humidity 95% non-condensing EN50081-4-2 ESD Output 5 VDC applied externally SBX-4 Integrator Guide Appendix B-Technical Specifications Page B3...
- Page 33 End User License Agreement IMPORTANT ‐ This is an agreement (the "Agreement") between you, the end purchaser ("Licensee") and Hemisphere GNSS Inc. ("Hemisphere") which permits Licensee to use the Hemisphere software (the "Software") that accompanies this Agreement. This Software may be licensed on a standalone basis or may be embedded in a Product. Please read and ensure that you understand this Agreement before installing or using the Software Update or using a Product. In this agreement any product that has Software embedded in it at the time of sale to the Licensee shall be referred to as a "Product". As well, in this Agreement, the use of a Product shall be deemed to be use of the Software which is embedded in the Product. BY INSTALLING OR USING THE SOFTWARE UPDATE OR THE PRODUCT, LICENSEE THEREBY AGREES TO BE LEGALLY BOUND BY THE TERMS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO THESE TERMS, (I) DO NOT INSTALL OR USE THE SOFTWARE, AND (II) IF YOU ARE INSTALLING AN UPDATE TO THE SOFTWARE, DO NOT INSTALL THE UPDATE AND PROMPTLY DESTROY IT. HEMISPHERE PROVIDES LIMITED WARRANTIES IN RELATION TO THE SOFTWARE. AS WELL, THOSE WHO USE THE EMBEDDED SOFTWARE DO SO AT THEIR OWN RISK. YOU SHOULD UNDERSTAND THE IMPORTANCE OF THESE AND OTHER LIMITATIONS SET OUT IN THIS AGREEMENT BEFORE INSTALLING OR USING THE SOFTWARE OR THE PRODUCT. LICENSE. Hemisphere hereby grants to Licensee a non‐transferable and non‐exclusive license to use the Software as embedded in a Product and all Updates (collectively the "Software"), solely in binary executable form. RESTRICTIONS ON USE. Licensee agrees that Licensee and its employees will not directly or indirectly, in any manner whatsoever: install or use more copies of the Software than the number of copies that have been licensed; use or install the Software in connection with any product other than the Product the Software was intended to be used or installed on as set out in the documentation that accompanies the S oftware. copy any of the Software or any written materials for any purpose except as part of Licensee's normal backup processes; modify or create derivative works based on the S oftware; sub‐license, rent, lease, loan or distribute the Software; permit any third party to use the Software; use or operate Product for the benefit of any third party in any type of service outsourcing, application service, provider service or service bureau capacity; reverse engineer, decompile or disassemble the Software or otherwise reduce it to a human perceivable form; Assign this Agreement or sell or otherwise transfer the Software to any other party except as part of the sale or transfer of the whole Product. UPDATES. At Hemisphere's discretion Hemisphere may make Updates available to Licensee. An update ("Update") means any update to the Software that is made available to Licensee including error corrections, enhancements and other modifications. Licensee may access, download and install Updates during the Warranty Period only. All Updates that Licensee downloads, installs or uses shall be deemed to be Software and subject to this Agreement. Hemisphere reserves the right to modify the Product without any obligation to notify, supply or install any improvements or alterations to existing Software. SUPPORT. Hemisphere may make available directly or through its authorized dealers telephone and email support for the Software. Contact Hemisphere to find the authorized dealer near you. As well, Hemisphere may make available user and technical documentation regarding the Software. Hemisphere reserves the right to reduce and limit access to such support at anytime. BACKUPS AND RECOVERY. Licensee shall back‐up all data used, created or stored by the Software on a regular basis as necessary to enable proper recovery of the data and ...
- Page 34 exclusion may not apply to Licensee and Licensee may also have other legal rights which may vary from jurisdiction to jurisdiction. BASIS OF BARGAIN. Licensee agrees and acknowledges that Hemisphere has set its prices and the parties have entered into this Agreement in reliance on the limited warranties, warranty disclaimers and limitations of liability set forth herein, that the same reflect an agreed‐to allocation of risk between the parties (including the risk that a remedy may fail of its essential purpose and cause consequential loss), and that the same forms an essential basis of the bargain between the parties. Licensee agrees and acknowledges that Hemisphere would not have been able to sell the Product at the amount charged on an economic basis without such limitations. PROPRIETARY RIGHTS INDEMNITY. Hemisphere shall indemnify, defend and hold harmless Licensee from and against any and all actions, claims, demands, proceedings, liabilities, direct damages, judgments, settlements, fines, penalties, costs and expenses, including royalties and attorneys' fees and related costs, in connection with or arising out of any actual infringement of any third party patent, copyright or other intellectual property right by the Software or by its use, in accordance with this Agreement and documentation, PROVIDED THAT: (a) Hemisphere has the right to assume full control over any action, claim, demand or proceeding, (b) Licensee shall promptly notify Hemisphere of any such action, claim, demand, or proceeding, and (c) Licensee shall give Hemisphere such reasonable assistance and tangible material as is reasonably available to Licensee for the defense of the action, claim, demand or proceeding. Licensee shall not settle or compromise any of same for which Hemisphere has agreed to assume responsibility without Hemisphere's prior written consent. Licensee may, at its sole cost and expense, retain separate counsel from the counsel utilized or retained by Hemisphere. INFRINGEMENT. If use of the Software may be enjoined due to a claim of infringement by a third party then, at its sole discretion and expense, Hemisphere may do one of the following: (a) negotiate a license or other agreement so that the Product is no longer subject to such a potential claim, (b) modify the Product so that it becomes non‐ infringing, provided such modification can be accomplished without materially affecting the performance and functionality of the Product, (c) replace the Software, or the Product, with non‐infringing software, or product, of equal or better performance and quality, or (d) if none of the foregoing can be done on a commercially reasonable basis, terminate this license and Licensee shall s top using the Product and Hemisphere shall refund the price paid by Licensee less an amount on account of amortization, calculated on a straight‐line basis over a deemed useful life of three (3) years. The foregoing sets out the entire liability of Hemisphere and the sole obligations of Hemisphere to Licensee in respect of any claim that the Software or its use infringes any third party rights. INDEMNIFICATION. Except in relation to an infringement action, Licensee shall indemnify and hold Hemisphere harmless from any and all claims, damages, losses, liabilities, costs and expenses (including reasonable fees of lawyers and other professionals) arising out of or in connection with Licensee's use of the Product, whether direct or indirect, including without limiting the foregoing, loss of data, loss of profit or business interruption. TERMINATION. Licensee may terminate this Agreement at any time without cause. Hemisphere may terminate this Agreement on 30 days notice to Licensee if Licensee fails to materially comply with each provision of this Agreement unless such default is cured within the 30 days. Any such termination by a party shall be in addition to and without prejudice to such rights and remedies as may be available, including injunction and other equitable remedies. Upon receipt by Licensee of written notice of termination from Hemisphere or termination by Licensee, Licensee shall at the end of any notice period (a) cease using the Software; and (b) return to Hemisphere (or destroy and provide a certificate of a Senior Officer attesting to such destruction) the Software and all related material and any magnetic or optical media provided to Licensee. The provisions of Sections 6), 7), 8), 9), 10), 15), 21), 26) and 27) herein shall survive the expiration or termination of this Agreement for any reason. EXPORT RESTRICTIONS. Licensee agrees that Licensee will comply with all export control legislation of Canada, the United States, Australia and any other applicable country's laws and regulations, whether under the Arms Export Control Act, the International Traffic in Arms Regulations, the Export Administration Regulations, the regulations of the United States Departments of Commerce, State, and Treasury, or otherwise as well as the export control legislation of all other countries. PRODUCT COMPONENTS. The Product may contain third party components. Those third party components may be subject to additional terms and conditions. Licensee is required to agree to those terms and conditions in order to use the P roduct. FORCE MAJEURE EVENT. Neither party will have the right to claim damages as a result of the other's inability to perform or any delay in performance due to unforeseeable ...
- Page 35 Warranty Notice COVERED PRODUCTS: This warranty covers all products manufactured by Hemisphere GNSS and purchased by the end purchaser (the "Products"), unless otherwise specifically and expressly agreed in writing by Hemisphere GNSS. LIMITED WARRANTY: Hemisphere GNSS warrants solely to the end purchaser of the Products, subject to the exclusions and procedures set forth below, that the Products sold to such end purchaser and its internal components shall be free, under normal use and maintenance, from defects in materials, and workmanship and will substantially conform to Hemisphere GNSS's applicable specifications for the Product, for a period of 12 months from delivery of such Product to such end purchaser (the ”Warranty Period”). Repairs and replacement components for the Products are warranted, subject to the exclusions and procedures set forth below, to be free, under normal use and maintenance, from defects in material and workmanship, and will substantially conform to Hemisphere GNSS's applicable specifications for the Product, for 90 days from performance or delivery, or for the balance of the original Warranty Period, whichever is greater. EXCLUSION OF ALL OTHER WARRANTIES. The LIMITED WARRANTY shall apply only if the Product is properly and correctly installed, c onfigured, interfaced, m aintained, stored, a nd operated in accordance with Hemisphere GNSS's relevant User’s Manual and Specifications, AND the Product is not modified or misused. The Product is provided “AS IS” and the implied warranties of MERCHANTABILITY and FITNESS FOR A PARTICULAR PURPOSE and ALL OTHER WARRANTIES, express, implied or arising by statute, by course of dealing or by trade usage, in connection with the design, sale, installation, service or use of any products or any component thereof, are EXCLUDED from this transaction and shall not apply to the Product. The LIMITED WARRANTY is IN LIEU OF any other warranty, express or implied, including but not limited to, any warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE, title, and non‐infringement. LIMITATION OF REMEDIES. The purchaser’s EXCLUSIVE REMEDY against Hemisphere GNSS shall be, at Hemisphere GNSS's option, the repair or replacement of any defective Product or components thereof. The purchaser shall notify Hemisphere GNSS or a Hemisphere GNSS's approved service center immediately of any defect. Repairs shall be made through a Hemisphere GNSS approved service center only. Repair, modification or service of Hemisphere GNSS products by any party other than a Hemisphere GNSS approved service center shall render this warranty null and void. The remedy in this paragraph shall only be applied in the event that the Product is properly and correctly installed, configured, interfaced, maintained, stored, and operated in accordance with Hemisphere GNSS's relevant User’s Manual and Specifications, AND the Product is not modified or misused. NO OTHER REMEDY (INCLUDING, B UT NOT LIMITED TO, S PECIAL, I NDIRECT, I NCIDENTAL, CONSEQUENTIAL OR CONTINGENT DAMAGES FOR LOST PROFITS, LOST SALES, INJURY TO PERSON OR PROPERTY, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL LOSS) SHALL BE A VAILABLE TO PURCHASER, even if Hemisphere GNSS has been advised of the possibility of such damages. Without limiting the foregoing, Hemisphere GNSS shall not be liable for any ...
- Page 36 ...
