- Page 1 Dolby Cat. No. 868 ® Remote Fader for the CP750 Issue 1 Part Number 9110360...
- Page 2 Dolby Laboratories, Inc. Corporate Headquarters Dolby Laboratories, Inc. 100 Potrero Avenue San Francisco, CA 94103‐4813 USA Telephone 415‐558‐0200 Fax 415‐863‐1373 www.dolby.com European Headquarters Dolby Laboratories, Inc. Wootton Bassett Wiltshire SN4 8QJ England Telephone 44‐1793‐842100 Fax 44‐1793‐842101 DISCLAIMER OF WARRANTIES: EQUIPMENT MANUFACTURED BY DOLBY LABORATORIES IS WARRANTED AGAINST DEFECTS IN MATERIALS AND WORKMANSHIP FOR A PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE. THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES AND NO WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR OF NONINFRINGEMENT OF THIRD‐PARTY RIGHTS (INCLUDING, BUT NOT LIMITED TO, COPYRIGHT AND PATENT RIGHTS). LIMITATION OF LIABILITY: IT IS UNDERSTOOD AND AGREED THAT DOLBY LABORATORIES’ LIABILITY, WHETHER IN CONTRACT, IN TORT, UNDER ANY WARRANTY, IN NEGLIGENCE, OR OTHERWISE, SHALL NOT EXCEED THE COST OF REPAIR OR REPLACEMENT OF THE DEFECTIVE COMPONENTS OR ACCUSED INFRINGING DEVICES, AND UNDER NO CIRCUMSTANCES SHALL DOLBY LABORATORIES BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, DAMAGE TO SOFTWARE OR RECORDED AUDIO OR VISUAL MATERIAL), COST OF DEFENSE, OR LOSS OF USE, REVENUE, OR PROFIT, EVEN IF DOLBY LABORATORIES OR ITS AGENTS HAVE BEEN ADVISED, ORALLY OR IN WRITING, OF THE POSSIBILITY OF SUCH DAMAGES.
- Page 3 The Cat No. 868 Remote Fader The Cat. No. 868 Remote Fader includes the fader knob and level display shown in Figure 1. Figure 1 Figure 1 The Cat. No. 868 Remote Fader Guidelines for Use Only one Cat. No. 868 remote unit can be used with a CP750. The combined length of cable connecting the remote unit tothe CP750 should not exceed 100 m (300 ft). As soon as you connect the remote unit, it is live and communicates with the CP750. A level adjustment made on either changes the display on both. Installation The Cat. No. 868 Remote Fader can be mounted on a wall or in a console, or can stand alone. Installing the remote fader consists of these processes: • Removing the Housing • Connecting the Interface Cable • Reattaching the Housing • Connecting to the CP750 ® Dolby Cat.
- Page 4 Removing the Housing To remove the housing: Remove the four screws from the corners of the front panel. Store the screws nearby. Remove the rear housing. Caution: Do not touch circuit board components. Static electricity can damage components. Connecting the Interface Cable Follow these steps: Select the cable you intend to use to connect to the CP750. Use a Cat 5 cable or better. Slide a rubber or neoprene grommet or conduit bushing onto the cable to prevent wear on the cable from the metal edge of the hole you create. Make a hole in the housing for the interface wire. The diameter of the hole you make should be the same as the diameter of the cable grommet or conduit bushing. We recommend you place the hole on the bottom if the remote fader will be mounted, or on a side if the fader will stand alone. Thread the interface wire through the hole in the housing and connect an RJ45 connector to the end of the wire. Plug the newly wired connector into J1 on the remote fader cirucit board. Using the two holes in the cicuit board along with the included wire tie, secure the cable as shown in Figure Figure 2 Figure 2 Circuit Board Interface Cable Connection Reattaching the Housing Secure the front panel to the housing with the screws that were removed in Step 1. ...
- Page 5 Installation Connecting to the CP750 To connect the remote to the CP750: Attach an RJ45 connector to the loose end of the interface cable. Plug the newly wired connector into the port on the CP750. Remote Your remote fader is ready to use. ® Dolby Cat. No. 868 Remote Fader for the CP750...
