Summary of Contents for Genie 360 Z135
- Page 1 TECH TIPS Service Call: Z135 axle position indicator lights flashing when axles fully extended or fully retracted. Calibrating axle sensors Tools Needed: Digital multimeter 7/16" open wrench Model: Z135...
- Page 2 Tech Tips Safety Rules Danger Failure to obey the instructions and safety rules in the appropriate Operator's Manual and Service Manual for your machine will result in death or serious injury. Many of the hazards identified in the operator’s manual are also safety hazards when maintenance and repair procedures are performed.
- Page 3 TECH TIPS Step 1 Make sure the boom is in the fully retracted position, the lower emergency stop button is pulled out and the off/ground controls/platform controls keyswitch is in the platform controls position. Move the boom if necessary to an area where there will be enough room to fully retract and extend the axles.
- Page 4 TECH TIPS Step 3 In the left and right lower side trays on the boom chassis you will find a 4 pin Deutsch connector coming into the cabinet from the axle position sensors. With your multimeter check for voltage between pin 2 (green/ white) and pin 3 (black) for voltage between 4.2 and 4.4 volts on both the front and rear Deutsch plugs.
- Page 5 TECH TIPS Step 5 At the ground controls put the run/service bypass/recovery keyswitch in the service bypass position. Put the off/ground controls/platform controls keyswitch in the ground controls position. While holding the ENTER button pull out the ground controls emergency stop button. Press the following buttons in this order: PLUS - ENTER - ENTER - PLUS Use the enter button to scroll through the menu to "RESET...
- Page 6 TECH TIPS Step 7 At the ground controls put the off/ground controls/platform controls keyswitch in the ground controls position. With the PLUS button change the display from NO to YES. Press the "ENTER" button to save the change. Continue to scroll through the menu by using the "ENTER" button until the display reads "EXIT NO/YES"...
