- Page 1 Linear One DMX Exterior User guide...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ............2 Welcome Safety Maintenance Cleaning Supplied items Optional accessories INSTALLATION ............5 Mount adjustment Using an optional mounting track Using optional extender bars Removing and refitting the end panels Fitting an optional glare shield Fitting an optional louver Power and control wiring Interconnecting Input wiring protection Tips for achieving successful DMX control... -
Page 4: Introduction
Control is achieved using the industry standard DMX-512A format, with RDM for configuration. Each Linear One DMX Exterior fixture has a short in-line input cable and a panel mount output connector (power and control signals are combined via a proprietary IP67 rated socket). -
Page 5: Supplied Items
SUPPLIED ITEMS Linear One DMX Exterior 1’ or 4’ (two (2) 90° swivel mount brackets included) OPTIONAL ACCESSORIES Glare shield 1’ (30cm) [LXEGS1] 4’ (121cm) [LXEGS4] Louver 1’ (30cm) [LXELV1] 4’ (121cm) [LXELV4] Feed cables 10’ (3m) [LNFC10] 50’ (15m) - Page 6 OPTIONAL ACCESSORIES (CONTINUED) Mounting track* 1’ (30cm) [LNMT1] 4’ (121cm) [LNMT4] * not required for all installations Flat mounting bracket* [LXFMB] * factory fitted option Extender bars 1’ (30cm) [LNEB1] 2’ (60cm) [LNEB2] 3’ (91cm) [LNEB3] IP66 junction box [AJBOX1] www.acclaimlighting.com...
-
Page 7: Installation
INSTALLATION When installing each Linear One fixture, ensure that the surface is level and that nothing is protruding to damage the mounting bracket(s). Suitable mounting surfaces include steel, aluminum, concrete or wood structures. Each Linear One fixture is fitted with two swivel mounting brackets, each of which have two slots measuring 0.26”... -
Page 8: Using An Optional Mounting Track
USING AN OPTIONAL MOUNTING TRACK Mounting tracks are aluminum profiles that provide an additional way to secure Linear One fixtures to surfaces. Once attached to the surface, the mounting track allows the standard swivel mounting brackets to slide into and be fixed to the track. Note: The mounting tracks are not symmetrical, one lip is larger than the other in order to accommodate the shape of the swivel mounts. -
Page 9: Using Optional Extender Bars
USING OPTIONAL EXTENDER BARS A common fixing method is to use optional extender bars. These are available in 1’ , 2’ and 3’ (30, 60 and 91cm) standoff lengths. Each 1’ Linear One fixture requires a single extender bar, while 4’ fixtures require two. 1 0 m "... -
Page 10: Removing And Refitting The End Panels
REMOVING AND REFITTING THE END PANELS Several alterations to the Linear One fixture begin with the removal of the end panels. There are just four screws holding each end panel in place and these require a medium sized Pozi- Drive (Philips) screwdriver. Please note that removing the end panels in no way affects the integrity of the IP66 rating and there should be no fear of water infiltration in performing this task. -
Page 11: Fitting An Optional Glare Shield
FITTING AN OPTIONAL GLARE SHIELD Optional glare shields are available which can be fitted on either side of the emitter housing to help conceal the emitters from side view. TO INSERT A GLARE SHIELD 1 Remove both of the end panels (see page 8). 2 Slide out the required shoulder strip. -
Page 12: Fitting An Optional Louver
FITTING AN OPTIONAL LOUVER Optional 1’ louvers are available, which can be fitted to eliminate side spill in all directions. For 4’ Linear One fixtures, use four louvers together. TO FIT A LOUVER 1 Remove both of the end panels (see page 8). 2 Slide out both shoulder strips. -
Page 13: Power And Control Wiring
Note: Do not exceed a total of 32 fixtures on a single line without signal boosting. An Acclaim Lighting RDS-6 RDM/DMX splitter or equal device can be used for this purpose. Ensure that the output connector of the final fixture has a terminator plug [Part #: LXTEC fitted to correctly terminate the DMX signal. -
Page 14: Interconnecting
INTERCONNECTING Each Linear One DMX fixture has a short cabled control/power input connector at one end and an integral control/power output at the other. When fixtures are daisy-chained (end to end), the input plug of one fixture can connect directly to the output socket of the previous fixture. -
Page 15: Input Wiring Protection
Ensure that appropriate care is taken to protect the junction where the mains and control inputs are joined to the feed cable. An optional IP66-rated junction box is available from Acclaim Lighting [Part #: AJBOX1] which provides separated mains and control inputs for connection to the combined feed-in cable:... -
Page 16: Tips For Achieving Successful Dmx Control
• Do not exceed a total cable length of 3,900 ft (1200m) or a total of 32 fixtures on a single line without signal boosting. An Acclaim Lighting RDS-6 RDM splitter or equal device can be used for this purpose. -
Page 17: Optional Wireless Control
OPTIONAL WIRELESS CONTROL Using optional units it is possible to wirelessly transmit and receive a DMX signal over distances up to 2600 feet (792m): USING TWO ARIA MODULES DMX IN DMX OUT USING A COMBINATION OF ARIA AND UDM•W MODULES DMX IN DMX OUT www.acclaimlighting.com... - Page 18 USING TWO ARIA MODULES PLUS ONE OR MORE RANGE EXTENDERS DMX IN Up to 2600’ (792m) Range extender Up to 2600’ (792m) DMX OUT www.acclaimlighting.com...
-
Page 19: Operation
MAKING A TEMPORARY CONTROL LINK WITH THE XMT-350 Each Acclaim lighting XMT-350 DMX/RDM tool is supplied with a 5-pin male XLR lead that can be used to make a temporary control input link with the Linear One feed-in cable. Use a 3-pin terminal block, wire nuts, conn blocks or Wago®... -
Page 20: Addressing Fixtures
ADDRESSING FIXTURES TO ADDRESS FIXTURES USING THE ACCLAIM LIGHTING XMT-350 1 Connect the XMT-350 to the DMX input line of either a single fixture or multiple fixtures in a pre-arranged daisy chain configuration. 2 Power on the fixture(s) and the XMT-350. -
Page 21: Setting The Cell Mode (4' Models Only)
4 Press the button to view details for the chosen fixture and then use the down button to highlight the DMX PERSONALITY entry: LINEAR ONE DMX EXTERIOR LABEL: LINEAR ONE DMX EXTERI... MODEL:LINEAR ONE DMX EXTERI... MAN: ACCLAIM LIGHTING DMX START ADDRESS: DMX PERSONALITY:STD.BLACKOU... -
Page 22: Setting The Signal Loss Behavior
4 Press the button to view details for the chosen fixture and then use the down button to highlight the DMX PERSONALITY entry: LINEAR ONE DMX EXTERIOR LABEL: LINEAR ONE DMX EXTERI... MODEL:LINEAR ONE DMX EXTERI... MAN: ACCLAIM LIGHTING DMX START ADDRESS: DMX PERSONALITY:STD.BLACKOU... -
Page 23: Testing Emitter Output
After you have addressed each Linear One fixture we recommend that you also test each one prior to installation. This can be achieved with your RDM (Remote Device Management) tool. Various third party DMX/RDM tools are available; we recommend the Acclaim Lighting XMT-350 for this task. -
Page 24: Further Information
FURTHER INFORMATION TROUBLESHOOTING NO LIGHT OUTPUT IS VISIBLE WHEN EXPECTED • Check that power is correctly applied to the fixture and that there is no damage to the power input cord. • Use an RDM tool to perform an emitter test. •... -
Page 25: Specifications
SPECIFICATIONS Color models RGBW (W=3000K, 4000K or 6000K), RGBA, DW (2200K to 5000K) Beam angle options 10º x 10º, 10º x 25º, 10º x 40º, 10º x 70º, 30º x 30º, 30º x 60º, 60º x 60º, 40º x 70º, Asymmetric (60º x 60º + 20º tilt), Lumen maintenance (L 150,000 hours (25 Control... -
Page 26: Limited Product Warranty
If the requested repairs or service (including parts replacement) are within the terms of this warranty, Acclaim Lighting will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in its original package. - Page 28 www.acclaimlighting.com...
