2N Helios IP Security Relay How To Use

2N® Helios IP Security Relay – what it is and
how to use it with 2N® Helios IP intercom?
®
The 2N Helios IP Security Relay
and higher. It significantly enhances security of the connected electric lock because it prevents the lock from
opening by forced intercom tampering.

Function:

®
The 2N Helios IP Security Relay
outside the secured area and the electric lock installed inside the secured area. The interconnection scheme is
shown in the picture below:
®
The 2N Helios IP Security Relay
from the intercom.

Specifications:

Passive switch: NO and NC contacts, up to 30V/1A AC/DC
Active switch output: typically 8 – 13 V DC depending on power supply (adapter: input voltage minus
0.6V), max 700mA
Dimensions: 56x31x24mm
Weight: 20g

Installation:

®
Install the 2 N Helios IP Security Relay
the area in order to be secured (typically behind the door). The device is powered and controlled via this two-wire
cable and so it can be added to an existing installation. Thanks to its compact dimensions the device can be
installed into a standard mounting box.

Settings for the Helios IP Vario:

The settings are the same as described below, but in addition you need to change the jumpers on the
configuation connector on the PCB to position
2N® TELEKOMUNIKACE a.s., http://wiki.2n.cz
®
is designed for any 2N Helios IP
is a small device installed between
includes a relay that can only be activated if the valid opening code is received
onto a two-wire cable between the intercom and the electric lock inside
normally OPEN
intercom model with firmware versions 1.15
®
2N Helios IP intercom which is placed
and Lock Power Supply settings can be set either
Page 1
