MODERN-AIRE VENTILATING

READ AND SAVE THESE INSTRUCTIONS

For use with: EM1400 External Blower

IMPORTANT:

Save these instructions for the local electrical

inspectors use.

INSTALLER:

Please leave these installation instructions with

this unit for the owner

OWNER:

Please Retain these instructions for future

reference.

WARNING:

TO REDUCE THE RISK

OF FIRE, ELECTRIC SHOCK OR

INJURY TO PERSONS, OBSERVE THE

FOLLOWING:

1. Use this unit in the manner intended by the

manufacturer. If you have questions, contact

the manufacturer or dealer.

2. Before installation, servicing or cleaning unit,

switch power off at the service panel and

lock the service disconnecting means to

prevent power from being switched on

accidentally. When the service

disconnecting means cannot be locked,

securely fasten a prominent warning device,

such as a tag, to the service panel.

3. Installation work and electrical wiring must be

done by a qualified person(s) in accordance

with all applicable codes and standards,

including fire-rated construction codes and

standards.

4. Sufficient air is needed for proper combustion

and exhausting of gases through the flue of

the fuel burning equipment to prevent

backdrafting. Follow the heating equipment

manufacturers guideline and safety standards

such as those published by the National Fire

Protection Association (NFPA), and the

American Society for Heating, Refrigeration

and Air Conditioning Engineers (ASHRAE),

and the local code authorities.

5. When cutting into wall or ceiling, do not

damage electrical wiring or other hidden

utilities.

6. Ducted fans must always be vented to the

outdoors

7. To reduce the risk of fire use only metal

ductwork

8. This unit must be grounded

CAUTION

For general ventilating use only. Do not use

to exhaust hazardous or explosive material

and vapors

To avoid motor bearing damage and noisy

and/or unbalanced impellers, keep drywall

spray, construction dust, etc. off power unit

Please read specification label on product

for further information and requirements

Electrical circuit including speed control

must be rated 6amps minimum
