Liko™ UniversalSling Mod. 000
Instructions for Use
Liko UniversalSling is a basic model which is designed to
adapt to the patient without individual adjustments and
is one of our most used slings.
The UniversalSling provides an upright sitting posture
and supports the entire back up to the neck. If the patient
needs support for the head it is recommended to use a
high back sling, e.g. Original HighBack Sling Mod 200/210
or Soft Original HighBack Sling Mod 26. The patient's arms
are held inside the sling. A properly fitted and carefully
applied UniversalSling will give the patient an excellent
sense of safety, as well as a high degree of comfort.
Sizes
The UniversalSling is available in different sizes. It is
important to choose the correct size to achieve the highest
level of comfort and safety. A sling which is too large
increases the risk of the patient sliding out of it, while
one which is too small can cut into the groin and cause
discomfort.
For larger sizes, a combination with a twin bar 670 can be a
good choice.
Fabrics
The UniversalSling is available in different fabrics. Since the
UniversalSling is not usually left under the patient after the
transfer, it is recommended to use the polyester design.
This fabric is durable and has low friction making the sling
easy to apply and easy to remove.
In this document, the person being lifted is referred to as the patient and the person helping is referred to as the caregiver.
IMPORTANT!
Lifting and transferring a patient always involves a certain level of risk. Read the instructions for use for both the patient
lift and lifting accessories before use. It is important to completely understand the contents of the instructions for use.
The equipment should only be used by trained personnel. Ensure that the lifting accessories are suitable for the lift used.
Exercise care and caution during use. As a caregiver, you are always responsible for the patient's safety. You must be aware
of the patient's ability to make it through the lifting situation. If something is unclear, contact the manufacturer or supplier.
7EN161110 Rev. 12
ENGLISH 2020
Product Description
The UniversalSling is also available in net polyester. This
fabric is recommended when the sling is left in place after
the transfer or when an airier alternative is desired.
For bathing and showering, a plastic-coated net design
is available, which is water permeable and can easily be
wiped. This material dries quickly and does not chill the
patient in the same way as a damp, absorbent fabric
would.
The sling's lift straps are always made of durable polyester
and are very secure.
Leg Supports
The UniversalSling is available with leg supports in several
different designs. Most common are leg supports with
reinforcements. The reinforcement provides high comfort,
equalizes pressure and prevents the sling from creasing
under the thighs.
Soft padded leg support (synthetic sheepskin) is available
as an accessory. Universal sling with padded leg support
is suitable for patients who are especially sensitive to
pressure.
Suitable lifts
The UniversalSling can be used along with all of Liko's
overhead and mobile lifts. You can choose between the
overhead lifts LikoGuard™, Likorall™, and Multirall™ or
the mobile lifts Golvo™, Viking™, Uno™, and Liko™ M220/
M230.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hill-Rom Liko UniversalSling
Summary of Contents for Hill-Rom Liko UniversalSling
- Page 1 Liko™ UniversalSling Mod. 000 Instructions for Use Product Description Liko UniversalSling is a basic model which is designed to The UniversalSling is also available in net polyester. This adapt to the patient without individual adjustments and fabric is recommended when the sling is left in place after is one of our most used slings.
-
Page 2: Table Of Contents
Different Ways of Connecting Leg Supports ....................12 The Patient does not Sit Well in the Sling – Why is This? ................12 Shortening Position ........................... 13 Accessories ..............................13 Overview Liko UniversalSling, Mod. 000, ....................14 Recommended Combinations ........................14 www.hillrom.com 7EN161110 Rev. 12 • 2020... -
Page 3: Symbol Description
Symbol description These symbols can be found in this document and/or on the product. Symbol Description Warning. Used were extra care and attention is needed. Read instructions for use before use Read instructions for use before use CE mark Legal manufacturer Date of manufacturing Ref number Serial Number... -
Page 4: Safety Instructions
PATENT www.hillrom.com/patents May be covered by one or more patents. See above Internet address. The Hill-Rom companies are the proprietors of European, US, and other patents and pending patent applications. Product Changes Liko’s products undergo continuous development, which is why we reserve the right to make product changes without prior notice. -
Page 5: Care And Maintenance
The entire product, including laths, padding material, etc. should be sorted as Combustible waste. Hill-Rom evaluates and provides guidance to its users on the safe handling and disposal of its devices to aid in the prevention of injury, including, but not limited to: cuts, punctures of the skin, abrasions, and any required cleaning and disinfection of the medical device after use and prior to its disposal. -
Page 6: How To Attach A Sling To Different Sling Bars
How to attach a sling to different sling bars Sling bar Sling loops to sling bar hooks Correct SlingGuard ™ Universal SlingGuard ™ Twin Universal Twin Cross-bar Example: Misuse www.hillrom.com 7EN161110 Rev. 12 • 2020... -
Page 7: How To Attach A Universalsling To A Sling Bar With 4 Hooks (Twin Bars And Cross Bars)
How to attach a UniversalSling to a sling bar with 4 hooks (twin bars and cross bars) Upper strap loops Leg support loops The illustrations 1, 2, and 3 shows a twin bar but this also applies to a Cross-bar. Lifting from the Sitting Position Place the sling behind the patient’s back with the product Using the palm of your hand, push the lower edge of the... -
Page 8: Lifting From A Sitting Position
Pull the sling’s leg supports forward along the outside of the Pull the leg supports forward to smooth out any creases in patient’s thighs. Place the palm of your hand between the the back. Check that both leg supports protrude the same patient’s body and the sling and push the leg support’s lower distance. -
Page 9: Lifting To A Sitting Position
Lifting to the Sitting Position When placing a patient in a wheelchair, it is important that the patient gets far enough back in the chair to sit well. This can be accomplished in several ways. When placing a patient in a wheelchair: Lean the chair Alternative: Apply slight pressure under the patient’s knees backwards during the lowering of the patient. -
Page 10: Lifting From The Bed
Lifting from the Bed The sling can be applied in different ways depending of the status of the patient. Either it is applied with the patient lying in bed or sitting in bed. If an advanced pressure-relieving mattress is used, it can to advantage be inflated maximally to facilitate the application of the sling. -
Page 11: Lifting To The Bed
Lifting to the Bed It is recommended to remove the sling after the transfer. If for some reason it is preferable to leave the sling in the bed, it is recommended to use a sling made of net polyester. Remember your own work posture and the patient’s comfort. Use the bed’s functions for raising and lowering. Good work posture is obtained when the mattress is level with the caregiver’s knuckles when the arms are held completely down. -
Page 12: Fitting Advice
Fitting Advice Different Ways of Connecting Leg Supports Before a connection alternative is chosen, an individual assessment should be performed to anticipate possible risks. Crossed-over leg supports. Overlapped under both thighs. Each leg support connected separately to the sling bar. The most common way of applying the This can be appropriate, for example sling. -
Page 13: Shortening Position
Note: This does not apply if you have an older model of the UniversalSling, Mod. 00/02, with an earlier design of the shortening position. For a description of the shortening procedure for Mod. 00/02, please contact Hill-Rom to obtain the instructions for use for that model. -
Page 14: Overview Liko Universalsling, Mod. 000
Combinations of accessories/products other than those recommended by Liko can result in risks for the safety of the patient. www.hillrom.com Liko AB Nedre vägen 100 975 92 Luleå, Sweden +46 (0)920 474700 Liko AB is a subsidiary of Hill-Rom Holdings, Inc.
