- Page 1 Rada Intelligent Care MX1 Wall Mounted Tap Installation Operation & Maintenance Manual Please read and save these instructions 494-EN V1.6...
-
Page 2: Table Of Contents
Table of Contents General Important Safety Information Specification Factory Default Settings Pack Contents Dimensions Installation Requirements Installation Commissioning Operation Fault Diagnosis Maintenance Spare Parts Limited Warranty and Remedy North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com... -
Page 3: General
General Make sure that the Rada MX1 is installed by a competent installer. The product commissioning, clock (date/time) and tap set up can only be done in conjunction with the “RADA AP1” available from the Apple APP store. Time and date setting is critical to ensure data reporting is correct. -
Page 4: Specification
Specification General Valve Maximum Ambient Temperature 122°F (50°C) 104°F (40°C) Minimum Ambient Temperature 33.8°F (1°C) 33.8°F (1°C) Maximum Humidity 95% rH 95% rH Electrical Valve Supply Voltage 100 - 240 V 50/60 Hz 12 V DC Rated Input Current 2.0 A Water Ingress Protection IP X4 IP X4... -
Page 5: Factory Default Settings
Factory Default Settings Adjustable Fixed Range RADA App Tile / Section Temperature Temperature Units Min Value Max Value Varient Varient 1 Valve Setup / 4 Installation Setup 1. Setup Advice Info Field 2. Valve Identity Editable Text Field 3. Outlet Type and Sub Type Info Field 4. - Page 6 Factory Default Settings - continued Range Adjustable Fixed RADA App Tile/Section Temperature Temperature Units Min Value Max Value Varient Varient 13. Blocking Time 25 Min Seconds/min 14. Temperature Scale 9 Increments 9, 5 Increments 15. Tasks Apply Changes to Valve/Undo Changes 1 Valve Setup / 6 Duty Flush Setup 1.
- Page 7 Factory Default Settings - continued Range Adjustable Fixed RADA App Tile / Section Temperature Temperature Units Min Value Max Value Varient Varient 9. Cool Down Timeout 2 Mins 2 Mins 10 Mins Seconds/Min 10. Flow Test Start/Stop 11. Flow Rate 12.
-
Page 8: Pack Contents
Pack Contents 1 Power Supply 1 Tap 1 Template 1 Backplate 1 Rada Disable Key 2 Screws 2 Flow Regulator/Filter 2 Connectors Assemblies 2 Nuts 4 Wall Plugs 4 Fixing Screws North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com... -
Page 9: Dimensions
Dimensions MX1 60 10.31” (262 mm) 7.78” (200 mm) 41.85” (7 mm) 1.14” (29 mm) 7.83” 3.07” (199 mm) (78 mm) 10.31” (262 mm) 3.15” (80 mm) 1.02” 1.57” (26 mm) (40 mm) 6.69” (170 mm) 30º Connection to Power Supply Unit Total Cable Run: 3’87”... -
Page 10: Installation Requirements
Installation Requirements The Rada MX1 60 wall mounted tap is designed for panel mounting / scrub trough. Specifically where rear access is available. NOT suitable for solid wall installation. The filter flow regulator unit must be fitted. Hot - Red Dot, Cold - Blue Dot. -
Page 11: Installation
Installation Installation of the Tap on the Stud wall and IPS panel For Correct Height Refer to HBN00-10 Part C Use the installation template provided, level and mark the positions of the holes. 0.98” Ø25 mm 0.078” 0.59” Ø2 mm Ø15 mm Drill the holes to the dimensions shown. - Page 12 Secure the backplate using the supplied fixing screws. DO NOT overtighten. Fit the inlet connectors with isolation hex facing downwards, aligning with the holes in the backplate. Attach the backnuts (supplied) leaving approx. 10-15 mm float allowing access to the spanner flats. North America •...
- Page 13 Make the plumbing connections. DO NOT use jointing paste when making plumbing connections. Make the plumbing connections. DO NOT use jointing paste when making plumbing connections. North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
- Page 14 1 min Flush the pipework. Install the filter flow regulator unit. DO NOT use jointing paste when making joints. Red Dot - Hot, Blue Dot - Cold. The arrow indicates flow direction. North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
- Page 15 Connect flexible tails to filter flow regulator units. North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
- Page 16 1 min 18 mm 2.5 mm Open supply isolators. Flush pipework. North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
- Page 17 Secure the tap using the supplied screws. DO NOT overtighten. Open the isolator on the check valve / filter housing. North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
-
Page 18: Commissioning
Pull off the cover from tap. Commissioning The Rada MX1 wall mounted tap will operate to factory settings when first installed Download the “RADA AP1” from the Apple App Store and follow the on screen instructions Note: Run the tap for 30 seconds in order for self calibration to take place North America •... -
Page 19: Operation
Operation The Rada MX1 wall mounted tap will operate to factory settings when first installed Download the “RADA AP1” from the Apple App Store and follow the on screen instructions North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim... -
Page 20: Fault Diagnosis
Fault Diagnosis As with most electronic equipment re-setting the mixing valve by powering it down at the mains, waiting a few seconds and powering it up again can often cure any issues. Symptoms Probable Cause Possible Remedy Product has entered an error mode indicated by a flashing Refer to Error Log “spanner”... - Page 21 Fault Diagnosis - continued Symptoms Probable Cause Possible Remedy Inlet water pressures too high Check specification. Inlet check valves / flow regulators Flow rate too high Check and remedy. not fitted Digital Mixing Valve failure Contact Rada. Inlet filters or check valves blocked Check and remedy. Outlet spout, hose or handset Check and remedy.
- Page 22 Fault Diagnosis - continued Symptoms Probable Cause Possible Remedy Temperature adjustment set too Increase temperature control - Some models only Re-commission blend temperature Blend temperature set too low using “RADA AP1”. Inlet filters or check valves blocked Check and remedy. Outlet spout, hose or handset blocked Check and remedy.
- Page 23 Fault Diagnosis - continued Symptoms Probable Cause Possible Remedy Run on time set too long Check settings in “RADA AP1”. Power cycle the digital mixer (turn off and on again). Ensure inlet filters are No shut off/ Possible debris in Digital Mixing clean.
- Page 24 A flashing “spanner” symbol indicates the product has gone in to an error mode. If repeated errors are logged this MUST be diagnosed and corrected by a technician. The “RADA AP1” can be used to disable the valve until fault diagnosis can be made. Using the “RADA AP1”, navigate to the Health Check Page tile 12, to read the error log.
- Page 25 Error Codes Probable Cause Possible Remedy Non Product Fault - The supply Valve will self clear fault. conditions are out of specification Hot inlet water supply Reduce hot inlet water temperature to Temp imbalance temperature is too hot or between 131°F and 149°F (55°C and fluctuating 65°C), refer to “Specifications”.
-
Page 26: Maintenance
Maintenance Cleaning Caution! Risk of product damage. Many cleaners contain abrasive and chemical substances, and should not be used for cleaning stainless steel, enamel, plated or plastic fittings. These finishes should be cleaned using a mild washing up detergent or soap solution, rinsed and then wiped dry with a soft clean cloth. Note: Run the tap for 30 seconds in order for self calibration to take place Change the flow insert Enter cleaning mode. - Page 27 Clean the filter Isolate water supplies. Disconnect tails. Clean/replace filter. Refit the components in Separate the filter unit, reverse order. lower portion can remain attached to supply elbow. Remove filter. North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
- Page 28 ☺ North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
- Page 29 This Page is Intentionally Left Blank North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
-
Page 30: Spare Parts
Spare Parts D128117 D128110 D128122 D128106 D128109 1.97” (50mm) D128108 D128120 D129225 D128115 D128118 (x 1) D128127 D128119 (x 10) D128111 North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com... - Page 31 Spare Parts - continued Part Number Description MX1-Model D128106 Printed Circuit Board - Temperature MX1-60 D128108 Mount - Printed Circuit Board MX1-60 D128109 Inlet (1 each) MX1-60 D128110 Back Plate MX1-60 D128111 Cap (1 pair) MX1-60 D128115 Thermistor MX1-60 D128117 Interface Cover - Temperature MX1-60 D128118...
- Page 32 Spare Parts - continued D128128 (x2) D128132 (x2) D128129 (x20) 2L and 6L/Min D129224 D128130 - 2 L/min D128131- 6 L/min D128114 D35448 (x3) D129223 8’2”(2.5m) North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
- Page 33 Spare Parts - continued Part Number Description MX1-Model D128114 Power Supply Unit MX1-60 D128128 Filter Insert (pack of 2) MX1-60 D128129 Flow Insert (pack of 20)) MX1-60 D128130 Filter/Flow Regulator Assembly - Hot (1 each) MX1-60 D128131 Filter/Flow Regulator Assembly - Cold (1 each) MX1-60 D128132 Flow Regulator Pack (One 2L &...
-
Page 34: Limited Warranty And Remedy
Armstrong’s repair or replacement of the part or product, excluding any labor or any other cost to remove or install said part or product, or at Armstrong’s option, to repayment of the purchase price. - Page 35 Notes North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com...
- Page 36 Designs, materials, weights and performance ratings are approximate and subject to change without notice. Visit armstronginternational.com for up-to-date information. Armstrong International North America • Latin America • India • Europe / Middle East / Africa • China • Pacific Rim armstronginternational.com 494-EN V1.6 © Armstrong International, Inc.
