Summary of Contents for First Power Stinger
- Page 1 Version 2 Owner / Operator’s Manual Rev A.2 PATENT PENDING 8941 Dutton Dr, Twinsburg, Ohio 44087 330-963-2050...
-
Page 2: Table Of Contents
Table of Contents Stinger® Kit Overview ……………………………………………………………………………… 1 Operation Guide ……………………………………………………………………………………. 2 GoPro® Camera Installation and Usage ………………………………………….. Battery Replacement …………………………………………………………………………….. Replace Black Transmitter Batteries …………………………………………… Replace Receiver Batteries …………………………………………… Stinger® Fluid Overview ………………………………………………………………………… Recommended Maintenance and Safety …………………………………………. 16 Specifications and Certifications …………………………………………………………... -
Page 3: Stinger® Kit Overview
Case: The Stinger® Kit comes in a durable and waterproof case. Main Assembly: Non-conductive housing that safely protects the can and houses the plumbing and valve to route the Stinger® fluid to the nozzle. Receiver: Allows for remote communication between the main assembly, and the transmitter to turn the dispense on and off. -
Page 4: Operation Guide
Operation Guide Step 1: Take the Main Assembly (2) out of the Case (1). Typically, the Receiver (3) is left in the Main Assembly (2). If the Receiver (3) is not installed, installed it using the procedure shown on page 20. Begin with screwing a Nozzle (4) into the threaded insert on the Main Assembly (2). - Page 5 DO NOT FORCIBLY SCREW IN THE CAN. If the can isn’t fully screwed in, the Can could leak or fail inside the Can Housing. The Stinger® can only be used with proprietary Stinger® fluids, DO NOT attempt to insert other cans into the Stinger®.
- Page 6 Be sure to attach the Main Adapter Stick Assembly (2) at an appropriate angle to easily aim stream of Stinger fluid to the desired location. We recommend you practice moving and operating the stinger when the hot stick is fully extended before using it in the field.
- Page 7 Step 10: Remove the can cap then, unscrew the can. Make sure the Main Assembly (2) is upright to prevent the Stinger® fluids from leaking onto your clothes when the can is unscrewed. Then reinstall the can cap. 5 | ©2020 FirstPower Group LLC...
- Page 8 Operation Guide Step 11: Place the Main Assembly (2) with the Receiver (3a) into the Case (1) and close the Case (1). Make sure this manual is in the Case (1) if the Stinger is not in use. 6 | ©2020 FirstPower Group LLC...
-
Page 9: Gopro® Camera Installation And Usage
GoPro® Camera Installation and Usage Note: FirstPower Group LLC does not supply the microSD cards with the camera Step 1: Lift the grey Rubber Locking Plug that is a part of the GoPro® Camera so that it is touching the back of the camera as shown below. Before After Rubber... - Page 10 GoPro® Camera Installation and Usage Step 3: Slide the GoPro® Camera (5) into the camera mount on the right side of the Stinger® Main Assembly (2). Make sure that the camera lens is in the same direction as the nozzle (4).
-
Page 11: Battery Replacement
Battery Replacement Replace Black Transmitter Batteries The status of the batteries is indicated by the Transmitter’s LED. If the Transmitter’s LED doesn’t turn on when the button is pressed, then the batteries must be replaced. Step 1: Flip the Transmitter Bottom over so that it is on its bottom side. - Page 12 Battery Replacement Replace Black Transmitter Batteries Step 3: Remove the green Metal Circuit Board circuit board from the Container Transmitter. Gently pull on the black plastic ring, that holds the batteries, from the Batteries metal container. Both batteries are directly stacked Black on top of each other and will Plastic...
-
Page 13: Replace Receiver Batteries
Battery Replacement Replace Receiver Batteries Step 1: Remove the Receiver (3) from its initial position shown in the “Before” figures. Gently slide it out the back of the Main Assembly (2) which is presented in the “After” figures. Before After 11 | ©2020 FirstPower Group LLC Stgr-Manual-V2 Rev. - Page 14 Battery Replacement Replace Receiver Batteries Step 2: Make sure that the Receiver is turned off. Then use a #2 Philips screwdriver to unscrew each screw on the battery door. Be sure to not completely unscrew the 2 screws from the battery door or else the washers will detach.
- Page 15 Battery Replacement Replace Receiver Batteries Step 3: This photo shows the battery caps assembled and the proper orientation of the batteries with the wires facing up. Philips Head Screws Battery Door Step 4: Make sure the battery wires are routed as shown on this photo. This will Alkaline 9V prevent wire damage and allow proper Batteries...
- Page 16 Battery Replacement Step 5: Finally, insert the Receiver (3a) back into the back of the Main Assembly (2) as shown in the “Before” figures. Confirm the that Receiver (3a) is fully inserted into the Main Assembly (2) as shown in the “After” figures. Before After 14 | ©2020 FirstPower Group LLC...
-
Page 17: Stinger® Fluid Overview
1FR has a proprietary threaded top which only allows it to be used in the Stinger®. Simply apply to a seized joint and let sit for 20-30 minutes to ensure penetration and repeat if needed. -
Page 18: Recommended Maintenance And Safety
Recommended Maintenance and Safety Recommended Maintenance Extend the life of the Stinger® by not storing outdoors or in extreme conditions Wipe the Stinger® using a clean lint-free cloth after each use. o DO NOT USE CHEMICAL SOLVENTS AS THIS WILL VOID WARRANTY. -
Page 19: Specifications And Certifications
Stinger® Warranty Information The Stinger® is warranted for one year from the date of purchase with a factory warranty. This warranty applies to parts and labor for any defects that are corrected in our shop when the product has been returned for repair. Pass through warranties provided where applicable. -
Page 20: Parts Diagram
1FR, Not included in Stinger® Kit STGR-Aerosol 2C 2C, Not included in Stinger® Kit STGR-Aerosol 3PAO 3PAO, Not included in Stinger® Kit *The Receiver comes with two Transmitter and the Receiver exclusively with those included Transmitters. **This product and/or service is not affiliated with, endorsed by or in any way associated with GoPro Inc. - Page 21 Questions? Contact FirstPower Group LLC at 330-963-2050 www.firstpowergroupllc.com...
