NRS Healthcare M48611 User Instructions

User Instructions
Lightweight Telescopic
Channel Ramp - Range

Maximum Load

Product Code Length
Number Minimum
M48611 915mm
(36")
M48623 1170mm
(46")
General Safety Warning
Please ensure these instructions are fully
read and implemented. Failure to do so
may result in injury to the user. Retain in a
safe place for future reference.

Intended Use

Intended Use
This Lightweight Telescopic Channel Ramp is
designed to provide access for wheelchair or
scooter users (and their carers, if
appropriate) over thresholds, steps and
curbs. The two part telescopic design is
easily adjusted to provide the desired length.
There are two length versions in the range,
see table above for size information

Unpacking

·
No tools are required to assemble this
product. (However if the ramp is to be
secured to the landing surface, then
appropriate tools will be required)
·
Remove items from packaging; Check for
damage. If you see any, or suspect a
fault, do not assemble or use the product;
contact your supplier immediately.
Length Track
Maximum width
1660mm 140mm
(65") (5½")
2130mm 140mm
(84") (5½")
*Product weights are approximate and may vary
Overall Overall
Width Height
190mm 65mm
(7½") (2½")
190mm 65mm
(7½") (2½")

Safety Precautions

When choosing a ramp, the length, and therefore
the angle of the ramp depend upon:
·
The height to be raised
·
The type of wheelchair or scooter
·
The weight of the wheelchair or scooter
and the user
·
The strength of the helper or user.
As a general guide, a raise of 1 in 12 is suggested
when the user is seated on the wheelchair or
scooter.
For loading an unmanned wheelchair or scooter
into a vehicle, a higher gradient can be used, but
this should not exceed 1 in 3. In addition to this, it
is important that you refer to your vehicle's user
guide for the proper degree of incline/decline and
direction before using the ramp.
- Never exceed its recommendations.
·
Only carry the ramp using the carry
handles. Take care when lifting; follow
standard manual handling procedures.
·
Take particular care when using the ramp
in wet/damp conditions.
Product weight
(Each)*
4.9kg (10.8lb)
6.3kg (13.9lb)
