- Page 1 PLANNING AND TRANSFER SYSTEMS System User Guide Revision 1.6 Copyright 2011, Brainlab AG Germany. All rights reserved.
-
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL INFORMATION ............7 . - Page 4 ................25 System Set Up .
- Page 5 ..............62 SAS Hard Drive LEDs .
- Page 6 System User Guide Rev. 1.6, Planning & Transfer Systems...
-
Page 7: General Information
GENERAL INFORMATION GENERAL INFORMATION Chapter Overview 1.1.1 Contents Topics Covered Section Contact Data & Legal Information Page 8 Symbols Used in This Guide Page 10 Intended Use Page 11 Training & Documentation Page 13 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 8: Contact Data & Legal Information
French-speaking regions Feedback Despite careful review, this manual may contain errors. Please contact us at igs.manuals@brainlab.com if you have suggestions as to how we can improve this manual. Manufacturer All workstations described in this user guide have been manufactured by Hewlett-Packard for: Brainlab AG Olof-Palme-Str. -
Page 9: Legal Information
This guide contains proprietary information protected by copyright. No part of this guide may be re- produced or translated without the express written permission of Brainlab. iPlan ® Brainlab is a registered trademark of Brainlab AG in Germany and/or the US. Trademarks ® ® ®... -
Page 10: Symbols
Symbols Symbols 1.3.1 Symbols Used in This Guide Warnings Warnings are indicated by triangular warning symbols. They contain safety-critical in- formation regarding possible injury, death or other serious consequences associated with equipment misuse. Cautions Cautions are indicated by circular caution symbols. They contain safety-critical infor- mation regarding possible problems with the device. -
Page 11: Intended Use
GENERAL INFORMATION Intended Use 1.4.1 Using the System Careful Hardware Handling System components comprise precise mechanical parts. Handle them carefully. Only trained medical personnel may operate the system. Symbols on Hardware Symbol Explanation Components Attention! Consult accompanying documents MR Unsafe MR Conditional: The number shown on each label specifies the MR environment in which the device can be used with caution Plausibility Review... -
Page 12: Laser Safety
Intended Use 1.4.2 Laser Safety DVD/CD The optical drive is a Class 1 laser according to IEC 60825-1. It contains a light emitting diode (LED) Drive/Writer which may produce a stronger laser beam than a Class 1 laser. It is dangerous to look directly at this laser beam. Do not remove any drive covers. Mouse The system is equipped with a laser mouse. -
Page 13: Training & Documentation
Brainlab Training To ensure safe and appropriate use, before using the system all users should participate in a training program held by a Brainlab representative. Responsibility This system solely provides assistance to the surgeon and does not substitute or re- place the surgeon’s experience and/or responsibility during its use. -
Page 14: Documentation
Please refer to the Safety Warnings Multilingual manual (for DL360G6), an original document pro- Multilingual Safety duced by the Hewlett-Packard Company. Brainlab AG has been officially authorised by the Hewlett- Manual Packard Company to distribute this manual for OEM purposes. -
Page 15: Before You Begin
BEFORE YOU BEGIN BEFORE YOU BEGIN Chapter Overview 2.1.1 Contents Topics Covered Section Handling the System Correctly Page 16 Servicing, Installation and Access Page 18 Handling Malfunctions Page 19 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 16: Correct Handling
Correct Handling Correct Handling 2.2.1 Handling the System Correctly Liquids & Condensation Ensure that liquid does not enter the system, as it is not IP protected (IPX0). Avoid condensation during operation. To prevent electric shock or permanent damage to the system, do not expose system components to excessive moisture. - Page 17 BEFORE YOU BEGIN Restrictions to Environment Do not use the system in the operating room. Always use it in accordance with all local and regional regulations. Do not use the system in explosive environments. The system is not suitable for use in the presence of flammable anesthetic mixtures containing air, oxygen or nitrous oxide.
-
Page 18: Servicing, Installation And Access
Brainlab. Unauthorized opening and improper repairs can result in considerable danger to the user (danger of electrical shock, high-voltage danger, fire danger). Repairs should only be performed by Brainlab or its authorized partners. Installation This system contains medical software. -
Page 19: Handling Malfunctions
Using the system when one of the above listed conditions exists may result in person- al injury or damage to the system. How to Respond to Damage or Failure Steps Turn off system. Unplug system from wall outlet. Contact Brainlab support. System User Guide Rev. 1.6, Planning & Transfer Systems... - Page 20 Correct Handling System User Guide Rev. 1.6, Planning & Transfer Systems...
-
Page 21: Iplan Workstation Performance And Iplan Workstation Premium
IPLAN WORKSTATION PERFORMANCE AND IPLAN WORKSTATION PREMIUM IPLAN WORKSTATION PERFORMANCE AND IPLAN WORKSTATION PREMIUM Chapter Overview 3.1.1 Contents Topics Covered Section System Components Page 22 Confidentiality Page 24 System Set Up Page 25 Connections, Cabling, Indicators and Drives Page 31 Turning System On/Off Page 35 Troubleshooting... -
Page 22: System Components
System Components System Components 3.2.1 Component Overview Monitor Figure 1 Workstation, Keyboard & Mouse Figure 2 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 23: Safety Instructions
IPLAN WORKSTATION PERFORMANCE AND IPLAN WORKSTATION PREMIUM Safety Instructions 3.3.1 Laser Safety DVD/CD The optical drive is a Class 1 laser according to IEC 60825-1. It contains a light emitting diode (LED) Drive/Writer which may produce a stronger laser beam than a Class 1 laser. It is dangerous to look directly at this laser beam. -
Page 24: Confidentiality
When using internal drives (such as the DVD writer) for local backups, store the data media contain- ing the backup data in a secure place. BIOS The BIOS is password protected. Contact Brainlab support if it is necessary to enter it. System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 25: System Set Up
IPLAN WORKSTATION PERFORMANCE AND IPLAN WORKSTATION PREMIUM System Set Up 3.4.1 Pre-Installation & Environmental Sustainability Pre-Installation The system is delivered pre-installed and can be used immediately. Environmental The production and the selection material used within the system is optimized to be environmentally Sustainability sustainable. -
Page 26: Ventilation & Clearances
System Set Up 3.4.2 Ventilation & Clearances Ventilation Do not block or cover ventilation slots on system cover or housing or other delivered equipment like the monitor. Air must be allowed to circulate through these slots to en- sure that the system operates properly and does not overheat. Do not place system near or over a radiator or heat register or in direct sunlight. -
Page 27: System Batteries
Depending on your system configuration, a battery is used for the internal BBWC (Battery Backed Write Cache) functionality of the RAID controller. Authorization Only Brainlab support is authorized to replace system internal batteries. Risk of Fire and Burns There is risk of fire and burns if the battery pack is not handled properly. To reduce risk of personal injury, follow the precautions below. -
Page 28: Ergonomics
System Set Up 3.4.4 Ergonomics Introduction For ease-of-operation, the monitor, keyboard and mouse are ergonomically designed. Unfavorable arrangement of these devices, incorrect arm positioning or posture or uninterrupted in- put via the keyboard or mouse can lead to: • Tenseness •... - Page 29 IPLAN WORKSTATION PERFORMANCE AND IPLAN WORKSTATION PREMIUM How to Position the Monitor 70° 70° min. 50 cm (19.7 in) Figure 4 Steps Arrange monitor so that it is illuminated by a light source that is above it and to one side: •...
- Page 30 System Set Up How to Adjust Chair/Desk > 90° > 90° Figure 6 Step Adjust chair and/or desk so that: • Your feet rest flat on floor with your knees at an angle of at least 90° • Your calves are relaxed, without any pressure on your joints •...
-
Page 31: Connections, Cabling, Indicators And Drives
IPLAN WORKSTATION PERFORMANCE AND IPLAN WORKSTATION PREMIUM Connections, Cabling, Indicators and Drives 3.5.1 Connections Location Connection ports for external devices are at the back and the front of the system. Availability The connections available on your system depend on your configuration level. Circuit Connect the system and all attached peripherals to same circuit. -
Page 32: Cabling
Connections, Cabling, Indicators and Drives 3.5.2 Cabling Connecting/ Brainlab support connects the system. If a cable is inadvertently unplugged, plug it into the corre- Disconnecting sponding port. Cables Do not pull cables. When using cable management arm components in the rack, ensure that cables are slack enough. -
Page 33: Indicators
IPLAN WORKSTATION PERFORMANCE AND IPLAN WORKSTATION PREMIUM 3.5.3 Indicators Location The indicators are on the system front. Availability The indicators available on your system depend on your configuration level. Illustration Figure 7 Component Meaning Optical drive Lights up when CD-ROM or DVD drive is accessed activity light, NOTE: Only remove the CD/DVD when indicator is unlit. -
Page 34: Drives & Data Media
Ensure that data medium is not visibly damaged or defective. Only use data media authorized by Brainlab. Keep the data medium inserted until the active Brainlab application has been closed. Do not remove the data medium while it is being used by an active application (e.g. -
Page 35: Turning System On/Off
IPLAN WORKSTATION PERFORMANCE AND IPLAN WORKSTATION PREMIUM Turning System On/Off 3.6.1 Power Button Illustration Figure 8 Component Power button System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 36: Turning On System
As a redundant storage system, the system uses a Raid5 hard disk system to increase data avail- System (Optional) ability. High quality hard disks are used in the system to reduce the failure rate. The status of the Raid5 hard disk system is reported during system boot up (before “Brainlab booting up” logo appears): Report Message... -
Page 37: Turning Off System
Emergencies In emergencies (such as damaged casing or cables, penetration of liquids or foreign matter), switch off system immediately, remove power connector and contact Brainlab support. Ensure that the mains outlet which is used for the system is freely accessible. -
Page 38: Troubleshooting
Set correct time and/or date within the operating system • If time and/or date are repeatedly wrong when switching on the system, the battery needs to be replaced On-board backup battery is flat • Contact Brainlab support System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 39: Iplan Net Server
IPLAN NET SERVER IPLAN NET SERVER Chapter Overview 4.1.1 Contents Topics Covered Section System Components Page 40 Safety Instructions Page 41 System Set Up Page 46 Panels, LED Indicators & Drives Page 54 Turning System On/Off Page 65 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 40: System Components
System Components System Components 4.2.1 Component Overview iPlan Net Server, Rack Model Figure 9 Monitor/Keyboard/ Mouse Drawer Console Figure 10 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 41: Safety Instructions
Do not insert foreign objects through the openings. Exchanging Parts Unless authorized by Brainlab, do not open the server or exchange any parts including hot plug spare parts like redundant power supplies, hard disks and fans. If not allowed by Brainlab, third-party accessories are note allowed for use with the server. -
Page 42: Laser Safety
Safety Instructions 4.3.2 Laser Safety DVD/CD The optical drive is a Class 1 laser according to IEC 60825-1. It contains a light emitting diode (LED) Drive/Writer which may produce a stronger laser beam than a Class 1 laser. It is dangerous to look directly at this laser beam. Do not remove any drive covers. Do not open the optical drives. -
Page 43: Symbols On The System Components
IPLAN NET SERVER 4.3.3 Symbols on the System Components General Various symbols may be placed on the system to indicate the presence of potentially hazardous Information conditions. Hazardous Energy Circuits Symbol Meaning Indicates presence of hazardous energy circuits or electric shock hazards. Refer all servicing to qualified personnel. - Page 44 Safety Instructions Power Supply Symbol Meaning Indicate that equipment is supplied by multiple sources of power. To reduce risk of injury from electric shock, remove all power cords to completely dis- connect power from system. Weight Symbol Meaning Indicates that component exceeds recommended weight for one individual to handle safely.
-
Page 45: Confidentiality
IPLAN NET SERVER 4.3.4 Confidentiality Password Password protect your Windows user account to ensure confidentiality of stored data. The password Requirements should: • Be difficult to detect by both humans and computer programs • Consist of at least six characters (the more characters, the stronger the password) •... -
Page 46: System Set Up
System Set Up System Set Up 4.4.1 Ventilation & Clearances General For continued safe and reliable equipment operation, install or position system in a well-ventilated, Requirements climate-controlled environment. Fix the server at the lowest possible position in the server rack. Do not operate the system when a cover is open. - Page 47 IPLAN NET SERVER Fans The system supports variable fan speeds. Fans operate at minimum speed until a temperature change requires a fan speed increase to cool the server. System shuts down in following scenarios: At POST • BIOS suspends the system for 5 minutes if it detects a cautionary temperature level. If caution- ary temperature level is still detected after 5 minutes, BIOS performs an orderly shutdown and enters Standby mode.
-
Page 48: Handling Equipment Racks
System Set Up 4.4.2 Handling Equipment Racks Rack Safety To reduce risk of personal injury or damage to equipment, take instructions below into account. Loading Equipment Load the equipment rack from the bottom up. Load the heaviest item into the rack first. Moving Racks Only move equipment racks: •... - Page 49 IPLAN NET SERVER How to Extend System from Rack Figure 11 Steps Power down the server. Disconnect all peripheral cables and power cords. Loosen the front panel thumbscrews. Extend server until server rail-release latches engage. Perform installation or maintenance procedure. Slide the server fully into the rack.
-
Page 50: Installing/Removing Hot-Plug Sas Hard Drive Options
• If only one hard drive is used, install it in the bay with the lowest device number • Hard drives must be supplied by Brainlab • Drives should be the same capacity to provide the greatest storage space efficiency when... -
Page 51: Connecting Redundant Hot-Plug Ac Power Supply
IPLAN NET SERVER 4.4.4 Connecting Redundant Hot-Plug AC Power Supply Precautions To reduce risk of personal injury from hot surfaces, allow the power supply or power supply blank to cool before touching it. To prevent improper cooling and thermal damage, do not operate system unless all bays are populated with either a component or a blank. -
Page 52: Exchanging Hotplug Components
Authorization Only Brainlab support is authorized to exchange hotplug components. In certain cases trained ser- vice technicians could be authorized by Brainlab to open the system to exchange hotplug compo- nents. If you have been authorized by Brainlab to open the system to exchange hotplug com- ponents, precisely follow the precautions below. -
Page 53: System Batteries
A battery is used for the internal BBWC (Battery Backed Write Cache) functionality of the RAID con- troller. Authorization Only Brainlab support is authorized to replace system internal batteries. Risk of Fire and Burns There is risk of fire and burns if the battery pack is not handled properly. To reduce risk of personal injury, follow the precautions below. -
Page 54: Panels, Led Indicators & Drives
Panels, LED Indicators & Drives Panels, LED Indicators & Drives 4.5.1 Front Panel Components Illustration Figure 13 Component DVD tray HP Systems Insight Display Front USB connector Video connector Hard drive bays System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 55: Front Panel Leds & Buttons
LED Green System on Power On/ Standby button/ Amber System shut down, but power still applied system power LED Power cord not attached or power supply failure Contact Brainlab support. System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 56: System Insight Display Leds
AMP mode disabled normal All other LEDs amber failure NOTE: The system’s insight display LEDs represent the system board layout. Troubleshooting If more than one DIMM slot LED is illuminated, contact Brainlab support. System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 57: Rear Panel Components
IPLAN NET SERVER 4.5.4 Rear Panel Components Illustration Figure 16 Component Fiber optic NIC FX1800 graphics card Power supply bay 1 (populated) Power supply bay 2 iLO 2/NIC connector Serial connector Video connector Mouse connector Keyboard connector NIC 2 connector NIC 1 connector USB connectors (2) System User Guide Rev. -
Page 58: Rear Panel Leds And Buttons
Panels, LED Indicators & Drives 4.5.5 Rear Panel LEDs and Buttons Illustration a s d f Figure 17 LED/Button Status Meaning Green Activity exists 10/100/1000 Flashing Activity exists NIC 1 activity LED No activity exists Green Link exists 10/100/1000 NIC 1 link LED No link exists Green Activity exists... -
Page 59: System Insight Display Leds And Health Led Combinations
DIMM failure, slot DIMM in slot X has failed Amber DIMM in slot X is in a pre-failure condition amber NOTE: In the event of failure indications, contact Brainlab support. System User Guide Rev. 1.6, Planning & Transfer Systems... - Page 60 Panels, LED Indicators & Drives LED Indications Regarding Power System Systems insight Health power Status display LED Only one power supply is installed and that power supply is in standby. Power supply (amber) Amber • Power supply fault • System board fault •...
-
Page 61: Sas Device Numbers
IPLAN NET SERVER 4.5.7 SAS Device Numbers Illustration Figure 18 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 62: Sas Hard Drive Leds
Panels, LED Indicators & Drives 4.5.8 SAS Hard Drive LEDs Illustration Figure 19 Component Fault/UID LED (amber/blue) Online LED (green) System User Guide Rev. 1.6, Planning & Transfer Systems... - Page 63 (1 Hz) Replace drive as soon as possible Drive is offline, a spare, or not configured as part of an ar- NOTE: In case of failure indications contact Brainlab support. System User Guide Rev. 1.6, Planning & Transfer Systems...
-
Page 64: Disk And Network Drives
Data Media Only use data media authorized by Brainlab. Keep the data medium inserted until the active Brainlab application has been closed. Do not remove the data medium while it is being used by an active application (e.g. when exiting the application, copying data or saving screenshots). This can damage data on the data medium or lead to a software crash. -
Page 65: Turning System On/Off
IPLAN NET SERVER Turning System On/Off 4.6.1 Power On/Standby Button Location The Power On/Standby button is located on the front panel Illustration Figure 20 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 66: Turning On System
Power Source Operate system using the power source indicated on type plate. If you are unsure of type of power available, consult Brainlab support or your local power company. Waiting Period If system has been turned off, wait at least 15 seconds before turning it on again. Oth- erwise, high input current may trip the circuit breaker. -
Page 67: Turning Off
In emergencies (such as damaged casing, elements or cables, penetration of liquids or foreign matter), switch off system immediately, remove power connector and con- tact Brainlab support. UID Button & UID Pressing the UID button illuminates the blue UID LEDs on the front and rear panels. In a rack envi- LEDs ronment, this feature facilitates locating a server when moving between front and rear of rack. - Page 68 Turning System On/Off System User Guide Rev. 1.6, Planning & Transfer Systems...
-
Page 69: Technical Information
TECHNICAL INFORMATION TECHNICAL INFORMATION Chapter Overview 5.1.1 Contents Topics Covered Section Power Specifications & Electrical Standards Page 70 System Specifications Page 73 Environmental Requirements Page 76 Compliances iPlan Workstations Page 78 Compliances iPlan Net Server Page 80 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 70: Power Specifications & Electrical Standards
Power Specifications & Electrical Standards Power Specifications & Electrical Standards 5.2.1 Power Specifications iPlan Workstation Performance Workstation Monitor 19” 100 - 127 V: 10 A AC 100 - 120 V, Maximum operating voltage 200 - 240 V: 6 A 200 - 240 V (50 W max.) Frequency 50-60 Hz, autosensing 50-60 Hz, autosensing... - Page 71 TECHNICAL INFORMATION Monitor/keyboard/mouse drawer console kit (optional) Maximum operating voltage 100-240 Vac Frequency 50-60 Hz Power consumption < 60 W System User Guide Rev. 1.6, Planning & Transfer Systems...
-
Page 72: Electrical Standards
Power Specifications & Electrical Standards 5.2.2 Electrical Standards iPlan Workstations iPlan Workstations Monitor • EN60950 • EN60950 • UL60950 • UL60950 Certificate • CSA22.2 No. 60950 • CSA-C22.2 No. 60950 • FCC part 15 class B • TCO’99 • CSA recognition mark •... -
Page 73: System Specifications
TECHNICAL INFORMATION System Specifications 5.3.1 Dimensions & Weight iPlan Workstations iPlan Workstations Monitor Height 455 mm Width 220 mm Depth 530 mm approximately 8 kg (19”) Weight approximately 28 kg approximately 10 kg (21”) iPlan Net Server iPlan Net Server Monitor/keyboard/ mouse drawer console Height 43.2 mm... -
Page 74: Technical Specifications
System Specifications 5.3.2 Technical Specifications iPlan Workstations iPlan Workstation Performance iPlan Workstation Premium E5440 x 1 E5440 x 2 Processor/ (4 usable CPU cores) 2.83 GHz, 1.5 MB cache per core cache (8 usable CPU cores) 1 x 250 GB 4 x 250 GB in RAID5 configuration Hard disk (SATAII, 7200 rpm minimum, 8... - Page 75 TECHNICAL INFORMATION Flatscreen Monitor, iPlan Workstations Display 19” TFT active matrix, EIZO 21” TFT active matrix, EIZO Type Resolution 1280 x 1024 1600 x 1200 16.7 million colors from a palette of 1.06 billion, Colors 256 gray values from a palette of 1024 Input VGA, DVI iPlan Net Server...
-
Page 76: Environmental Requirements
Environmental Requirements Environmental Requirements 5.4.1 Moving, Storage and Operating Conditions Restrictions to • Store or operate system at locations which are protected against moisture, wind, sunlight, dust, Location salinity, and sulfur. • Do not store system in near vicinity of chemical products or gas. •... - Page 77 TECHNICAL INFORMATION Considering All temperature ratings shown are for sea level. An altitude derating of 1°C per 300 m (1.8°F per Altitude 1,000 ft) to 3048 m (10,000 ft) is applicable. No direct sunlight allowed. Altitude maximum for storage corresponds to a pressure minimum of 70 kPa. System User Guide Rev.
-
Page 78: Compliances Iplan Workstations
Compliances iPlan Workstations Compliances iPlan Workstations 5.5.1 Electromagnetic Immunity Electromagnetic The iPlan Workstations are intended for use in the electromagnetic environment specified in the Environment relevant declaration. Assure that the iPlan Workstations are used in such an environment. RF Emissions The iPlan Workstations only use RF energy for internal functions. -
Page 79: Declarations & Certification
TECHNICAL INFORMATION 5.5.2 Declarations & Certification Declarations The iPlan Workstations conform to the following product specifications and regulations: • Safety IEC 60950-1:2001 / EN 60950-1:2001+A11:2004 • IEC 60825-1:1993+A1 / EN60825-1:1994+A11Class 1 for LED’s and Lasers • U.S.A. 21CFR Subpart J - for FC Laser module •... -
Page 80: Compliances Iplan Net Server
Compliances iPlan Net Server Compliances iPlan Net Server 5.6.1 Electromagnetic Emissions Electromagnetic The iPlan Net Server is intended for use in the electromagnetic environment specified in the decla- Environment ration below. Assure that the iPlan Net Server is used in such an environment. RF Emissions The iPlan Net Server only uses RF energy for internal functions. -
Page 81: Declarations & Certification
TECHNICAL INFORMATION 5.6.2 Declarations & Certification Declarations The iPlan Net Server Hardware conforms to the following product specifications and regulations: EMC: Class A • CISPR 22:2005 • EN 55022:2006 • EN 55024:1998 +A1:2001 +A2:2003 • EN 61000-3-2:2006 • EN 61000-3-3:1995 +A1:2001 +A2:2005 Safety: •... - Page 82 Compliances iPlan Net Server System User Guide Rev. 1.6, Planning & Transfer Systems...
-
Page 83: Cleaning
CLEANING CLEANING Chapter Overview 6.1.1 Contents Topics Covered Section General Instructions Page 84 System Unit Case & Keyboard Page 85 Monitor Page 87 System User Guide Rev. 1.6, Planning & Transfer Systems... -
Page 84: Iplan Workstations & Iplan Net Server
iPlan Workstations & iPlan Net Server iPlan Workstations & iPlan Net Server 6.2.1 General Instructions No Disinfection Do not use manual or automatic cleaning and disinfection procedures. No Sterilization Do not sterilize system components. No Liquids Ensure that liquid does not enter the system components, as this could damage the component and/or the electronic. -
Page 85: System Unit Case & Keyboard
If particularly dirty, use a cloth that has been moistened in mild domestic detergent and then carefully wrung out. Clean keyboard and mouse with disinfectant wipes. NOTE: The system inside may only be cleaned by Brainlab support System User Guide Rev. 1.6, Planning & Transfer Systems... - Page 86 iPlan Workstations & iPlan Net Server Do Not Use Do not use caustic cleaning solvents, as they may corrode plastic. System User Guide Rev. 1.6, Planning & Transfer Systems...
-
Page 87: Monitor
CLEANING 6.2.3 Monitor Illustration Figure 23 Component iPlan Workstations Monitor iPlan Net Server Monitor How to Clean Steps Shut down system. Turn off all power and equipment switches. Unplug system from power supply. Wipe monitor face with a moist cloth Do Not Use Do not use alcohol. - Page 88 iPlan Workstations & iPlan Net Server System User Guide Rev. 1.6, Planning & Transfer Systems...
-
Page 89: Index
INDEX ..........iPlan Net Server ............ confidentiality ........airflow, iPlan Workstations ............disk drives ..........exchanging parts ............front panel ..........front panel LEDs ............health LEDs ..................internal health LED cabling, iPlan Workstations ........................... LEDs cleaning .................. - Page 90 ..........moving conditions ............MR safety ........ventilation, iPlan Workstations ........network drive, iPlan Net Server ..............WEEE ....... network drive, iPlan Workstations ............... weight ..........network environment ..........operating conditions ........panels, iPlan Net Server ........password, iPlan Workstations .......
- Page 92 Art-No: 60908-91EN *60908-91EN*...
