Mercedes-Benz NTG 5.5 / 6 / MBUX Camera Video interface
Compatible with 7" , 8" , 10" and 12" screens
Dipswitch settings
Rearviewcamera Activation and reverse signal
Installation, wiring and LVDS cable
Compatible with cars like:
A-class (W177)
B-class (W247)
CLS-Coupé (C257)
New Sprinter (W907)
E-class W213 / C238
S-class (facelift from June 2017)
page 3-4
page 5
page 7 to 11
page 12-17
Article code: 300 214
1
Advertisement
Table of Contents
Summary of Contents for Mercedes-Benz NTG 5.5
- Page 1 Mercedes-Benz NTG 5.5 / 6 / MBUX Camera Video interface Compatible with 7” , 8" , 10” and 12" screens Compatible with cars like: A-class (W177) B-class (W247) CLS-Coupé (C257) New Sprinter (W907) E-class W213 / C238 S-class (facelift from June 2017)
- Page 2 Diagram: The interface should be installed behind the radio / navi head unit in between.
- Page 3 DIP 6 settings WITH TOUCHSCREEN LCD NO TOUCHSCREEN LCD 7 or 8 INCH LCD 10 or 12 INCH LCD DUALSCREEN 7 INCH NOT USED...
- Page 4 DIP 8 SETTINGS REARVIEWCAMERA (V4) Show FRONT CAMERA 10 seconds after reverse MUST BE UP (OFF) Guide lines Down / ON 7 and 8 inch UP / OFF 10 and 12inch After adjusting the dipswitch 8, please disconnect the power supply and connect this again (black connector) Dip 1 Video 3 –...
- Page 5 Rearviewcamera activation When put gear in Reverse the interface switches automatically to Reverse camera input, usually detected by CANbus system of the car. Unfortunately sometimes reverse it's not reacting by CANbus because the car can have different CAN protocol/codes. Also the guide lines can not be guaranteed. In this case the reverse trigger wire of the interface should be connected with the analog reverse licht signal like shown below.
- Page 6 Example installation MB Sprinter MBUX: Remove LCD part: 2x torx screws behind the air vent. Take out the LCD part as shown below:...
- Page 7 Take out the headunit: Backside of headunit (version 1): Backside of headunit (version 2):...
- Page 8 Take out the GREEN VIOLET LCD connector: Connect the interface LVDS cables in between like shown below:...
- Page 9 Take out the white (or black connector on some headunits) power connector: Take out the GREY part from the black housing in the white connector:...
- Page 10 Connect the CANbus wires of the interface (version 1): Interface: Blue = CAN+ / Grey = CAN- Car wires: Pin 15 = CAN+ / Pin 22 = CAN- Connect the power wires (version 1): Interface: Yellow = +12V / Black = ground ...
- Page 11 Additionally: Connect the power and CANbus wires of the interface (head unit version 2) as below:...
- Page 12 Troubleshooting When you DON’T have OEM image (only black screen with sound of the radio) Please check the LVDS cable Please check the power 7supply of the interface Installation with CANBUS: Yellow wire has +12 Volt ? Installation WITHOUT CANBUS: Yellow and purple wire has +12 Volt ?
- Page 13 Troubleshooting When you have OEM image. After putting in reverse, nothing is happening (no rearviewcamera image, it stays in OEM image) Please check the green wire (“Reverse IN”)
- Page 14 Please check your dipswitch 5 (dip 8 settings) Must be down (ON)
- Page 15 Troubleshooting When you have OEM image, but no rearviewcamera image. After putting in reverse, it switch to black image. Check the power supply of the rearviewcamera...
- Page 16 Check camera input of the interface Power supply of the rearviewcamera Do NOT connect the powercable of the rearviewcamera to the reverselight. This 12V is NOT stable, most of the cars have “duty circle” in the 12V reverselight. We suggest to find a stable 12V in the fusebox. To extend the service life of the rearviewcamera, we recommend a ignition 12 Volt.
- Page 17 Troubleshooting Rearview image adjustment When you have black/grey border in the rearview image When you have camera image, press the menu button on the side of the interface. The interface menu will pop up in the screen. With Up or Dn you can move the selection bar. Select position H or position V to adjust the position of the camera image.
