- Page 1 Master-MB Assembly Instruction 672203-GB-96/11...
-
Page 2: Preassembly Information
Polyethylene: Can be recycled. HARDI INTERNATIONAL A/S reserves its right to make any necessary improvements or changes without previous notice, and without any obligation to make such changes of machines and equipment which have already been bought or delivered. - Page 3 1. Check all shipping packages are present. NOTE: Use O-rings where indicated. Lubricate them with non-mineral lubri- cant before assembly. Model 1202/1302 2. Tee with O-ring and pressure damper are fixed to the frame. Tee with O-ring and suction damper are mounted to the pump.
- Page 4 ø 30 x 26 x 2 Model 361 2. Elbow is mounted to suction inlet. Elbow and nipple are mounted to pressure outlet. Use sealing tape. Turn elbows to the left. Fit pump to base with M10 x 20 bolts.
- Page 5 M6 x 20 3. Fit bottom half of protective guard. Lubricate conical or splined shaft lightly and connect transmission shaft and fit cover. Attach chain to pre- vent rotation of the protec- tive guard. For conical connection recheck the grub screw is tight after 5 min.
- Page 6 BK operating unit 5. Place ball in the main ON/OFF valve and turn the handle so the ball disappears. Fit valve seat and connect main valve to the distri- bution valves. 6. Fit operating unit to rack arm and arm holder. The holder can be shortened if necessary.
- Page 7 8. Mount MANIFOLD fittings (and eventual valves). Now bolt bracket to the left hand side.
- Page 8 F = From distribution valves to boom. Shortest for centre/inner section. H = From HARDI-MATIC to tank. K = From pressure manifold to safety valve. M = From pressure mainfold to operating unit. N = From Self Cleaning Filter (if fitted) to tank.
- Page 9 Fit hoses inside the tank: From main ON/OFF valve (hose C). From HARDI-MATIC (hose H). NOTE: For sake of good order, it may be necessary to shorten some hoses. This is best done when assembly is completed and before hoses are se- cured with plastic straps.
- Page 10 14.Connect hydraulic hose to the ram. Remember the spacer and secure with split pins. Fit the 4 bolts to the lift wagon but do not tighten. Lower wagon down the gantry. Fit the pin and secure with split pins. Adjust glide pads A so distance B is equal.
- Page 11 15a.Fit rear nozzle holder. 16.Lock the trapeze and fit boom wings. (Easiest with 2 persons). 17.Fit outer section locks. Do it with the boom unfolded to ensure the pins and holes line up.
- Page 12 18.Fold the boom (left side first) and fit the transport brackets (shortest on left side). 19.Nozzle tubes are supplied with one lock nozzle saddle per tube A. The rest can slide lengthwise B allowing for extension and contraction. Tubes and hoses are connected. REMEMBER: Lubricate O-rings before fitting.
- Page 13 20. Fit boom skid. 21.With boom at minimum height, secure hoses up over the side of the gantry to the operating unit. Check that hoses do not catch or pinch whilst raising/lowering or folding/unfolding the boom. Organize hoses in tidy bundle (may be necessary to shorten some) and secure in brackets and with straps.
- Page 15 Notes:...
