1A
Parts in this box.
Arms x 2
Back Side Rails x 2
Stretchers x 2
1B
Hardware in this box.
100mm
Bolts x 4
Long Allen Key
x 1
Page 1 of 8
WINSTON TRAY ARM
Seat Side Rails x 2
*Note: Use 4pc of 100mm Bolts and 4pc of 60mm Bolts
to attach the arms to the Stretchers.
80mm
Bolts x 4
Clevis Pins
Metal Bracket
x 2
x 4
BIFOLD FUTON FRAME
Back Rails and Slats x 1
Seat Rails and Slats x 1
60mm
30mm
16mm
Bolts x 10
Bolts x 12
Bolts x 16
Wooden
Barrel
Wood
Dowels x 18
Nuts x 18
Buttons x 4
Assembly Instructions
Full Size • Queen Size
Full Size: Slat Supports x 6
Queen Size: Slat Supports x 6
1C
Queen size only:
Extra parts.
B3 Roller complete
with Clevis pin,
Washer and
Locking pin x 4
0309
2pc with extra holes
2pc with extra holes
& plastic stoppers
3pc are longer for
the Back deck
2pc with extra holes
2pc with extra holes
& plastic stoppers
Short Legs x 2
50mm Bolts x 2
Advertisement
Table of Contents
Related Manuals for Continental Refrigerator WINSTON TRAY ARM
Summary of Contents for Continental Refrigerator WINSTON TRAY ARM
- Page 1 BIFOLD FUTON FRAME Assembly Instructions WINSTON TRAY ARM Full Size • Queen Size 0309 Parts in this box. 2pc with extra holes 2pc with extra holes & plastic stoppers Arms x 2 Back Rails and Slats x 1 Full Size: Slat Supports x 6...
- Page 2 BIFOLD FUTON FRAME Assembly Instructions WINSTON TRAY ARM CONTINENTAL Full Size • Queen Size FRAME 0309 Fit the Slat Supports to the Back Deck. Fit the B3 Rollers to the Back Side Rails The Back Deck slat bundle is longer than the seat.
- Page 3 BIFOLD FUTON FRAME Assembly Instructions WINSTON TRAY ARM CONTINENTAL Full Size • Queen Size FRAME 0309 Assemble the Side Rails to the Back Deck. Wooden Dowels 60mm Bolt Back Side Rail Push fit or lightly tap the Wooden dowels into the ends of the...
- Page 4 BIFOLD FUTON FRAME Assembly Instructions WINSTON TRAY ARM CONTINENTAL Full Size • Queen Size FRAME 0309 Fit the Slat Supports to the Seat Deck. Wood The Seat Deck slat bundle is shorter than the seat. Block Identify the correct slat supports as shown below,...
- Page 5 BIFOLD FUTON FRAME Assembly Instructions WINSTON TRAY ARM CONTINENTAL Full Size • Queen Size FRAME 0309 Assemble the Side Rails to the Seat Deck. Wooden Dowel 80mm Seat Side Rail Push fit or lightly tap the Wooden dowels into the ends of the...
- Page 6 BIFOLD FUTON FRAME Assembly Instructions WINSTON TRAY ARM CONTINENTAL Full Size • Queen Size FRAME 0309 Attach Arms to Stretchers. Fasten Stretcher Brackets to the Arms: Wooden Using Bolts and Barrel Nuts attach the Dowel Arms loosely to the Stretchers as shown.
- Page 7 BIFOLD FUTON FRAME Assembly Instructions WINSTON TRAY ARM CONTINENTAL Full Size • Queen Size FRAME 0309 Fit the Back Deck into Position. Insert the Back Deck lying flat. Insert one end first, then gently lower the other end into position.
- Page 8 BIFOLD FUTON FRAME Assembly Instructions WINSTON TRAY ARM CONTINENTAL Full Size • Queen Size FRAME 0309 Attach the Seat Deck to the Back Deck. Queen size only: Attach short legs. Fit the Seat Deck inside of the Back Deck as shown.
