POWER BOAT
Welcome aboard!
We are happy you have chosen Defiant II for your vacation. We are sure you will enjoy cruising
the lovely islands of the Pacific Northwest.
Defiant II is one of the time-tested comfortable boats used in the San Juans and Canadian Gulf
Islands. She combines speed and economy, packing many amenities into a well-planned layout
for comfort and fun.
We trust this manual will help you become familiar with the boat and answer questions about
key operation and safety issues. If you have additional questions about the boat or about places
to visit, please do not hesitate to ask the AYC staff.
Engine Inspection...............................................3
Start-Up.........................................................3
Shutdown.......................................................4
Getting Underway..............................................4
Cruising.........................................................4
Docking.........................................................4
Fueling...........................................................5
OPERATION MANUAL
Defiant II
TABLE OF CONTENTS
Page
1
Advertisement
Table of Contents
Summary of Contents for AYC Defiant II
-
Page 1: Table Of Contents
Defiant II Welcome aboard! We are happy you have chosen Defiant II for your vacation. We are sure you will enjoy cruising the lovely islands of the Pacific Northwest. Defiant II is one of the time-tested comfortable boats used in the San Juans and Canadian Gulf Islands. - Page 2 Boat Electrical …………………………………………….Page A.C. (Shore) Systems…………………………………..…5-6 Inverter………………………………………………..6 Generator……………………………………………...6 D.C. (House) Systems…………………………………7 Batteries………………………………………………..7 Sanitation Systems Marine Toilet……………………………………………….8 Holding Tank……………………………………………….8 Y-Valve……………………………………………………..9 Water Systems Fresh Water Tanks…………………………………………9 Fresh Water Pump…………………………………………9 Hot Water…………………………………………………..9 Shower……………………………………………………..9 Galley Stove/Oven…………………………………………………10 Refrigeration………………………………………………..10 Heating Systems Diesel Heater (DC)………………………………………...10 Electronics VHF Radio, Depth Sounder, Radar………………………10-11 GPS/Plotter………………………….…………………….11 Entertainment AM/FM Radio………………………………………….…..11...
-
Page 3: Boat Operation
Crabbing/Fishing…………………………………….………..13 Other: Bilge Pumps/Safety……………………………………14 Thru-Hull Description...………………………………………14 BOAT OPERATION Engine Inspection Remember your “WOBBS” every morning: Water (Coolant), Oil, Bilges (Inspect and Pump-out), Belts and Sea Strainer. Check the level of COOLANT in the expansion tanks located forward of each engine on the bulkhead in the engine room. -
Page 4: Shutdown
Cruising All close quarters maneuvering should always take place at the upper helm. Because Defiant II carries her dingy on the foredeck—virtually all operating of vessel should take place at the upper helm. -
Page 5: Fueling
No dots are breakers signify irregular use or use with discretion. Note that many 12 volt breakers on Defiant II are not “switchable.” They are always in the “On” position unless they “pop” and need to be reset. 110-Volt AC System... -
Page 6: Inverter
To connect to shore power, plug the 30 amp POWER CORD into the boat and then into the dock receptacle. Check the power rating/plug size of the nearest dock receptacle (that is 50 amp, 30 amp, 20 amp, or 15 amp). If necessary, add a CORD ADAPTER located in the top drawer in the galley. Turn the dock power on. -
Page 7: House) Systems
House (12-volt) System Three battery banks support 12-volt DC power: 1) port & starboard engine start battery (located between the engines and aft in the engine space); ( 2) House battery bank (located on the outside of the engines on both port and starboard sides);... -
Page 8: Sanitation Systems
(about 1 gallon per flush) With an overfilled tank, it is possible to break a hose, clog a vent, or burst the tank. The result will be indescribable catastrophe and an EXPENSIVE FIX to you. Empty the tank EVERY OTHER DAY to avoid this problem. Flushing a few ounces of AYC provided deodorizer will help eliminate odors. -
Page 9: Y-Valve
#2 The tank’s contents can be discharged with the overboard MACERATOR only in specified Canadian waters. To operate the macerator, depress the MACERATOR ROCKER SWITCHES simultaneously on the DC electrical panel. Listen to the macerator pump’s sound. When the pitch becomes higher, the tank is empty. -
Page 10: Galley
wipe down the shower stall and floor. Check for accumulation of hair in the shower and sink drains. Ensure that the faucets and nozzle are completely off after use. GALLEY Stove/oven The stovetop and oven both operate with propane gas. Turn on the “stove” breaker on the AC panel. Your propane stove is activated by the following steps: #1 Turn on the propane tank on the fly bridge (located to the left of the upper helm under the console.) #2 Turn on the Electronic Solenoid ( Electro Systems) located to the right of the lower helm wheel. -
Page 11: Gps/Plotter
There are 2 VHF RADIOS. The first is located at the lower helm. There is a second VHF RADIO located at the upper helm in lower cabinet. Always monitor channel 16 while underway. Depth Sounder There are 2 DEPTH SOUNDERS, one at the lower helm and the other on the Garmin Plotter at the upper helm. -
Page 12: Anchoring/Mooring Bouys
ANCHORING The primary WORKING ANCHOR is a 30# Lewmar plough and is attached to 250 ft chain passed through the deck from the ANCHOR LOCKER. The locker can be accessed through the forward stateroom hatch. Keep in mind that access to the chain is very limited due to a plywood baffle in the chain locker. -
Page 13: Barbecue
Note: Propane bottles are provided by AYC. If you anticipate needing an additional bottle, please ask AYC staff. Caution -- For safety reasons, do not store an opened propane bottle within the salon or engine compartment. Chances are these will leak slightly once opened and propane gas could settle into low spaces. - Page 14 A few should always be out and ready. Your flares and safety equipment are located under the lower helm. Defiant II is equipped with 4 BILGE PUMPS—TWO MANUAL AND TWO AUTOMATIC. The MANUAL switch is located AT THE HELM STATIONS.
