Summary of Contents for decrane aerospace MAP-9101-10 Series
- Page 1 Installation Manual MAP-9101-10x-x Moving Maps Server Document # 540372 MAP-9101-100-x MAP-9101-101-x 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.decraneaerospace.com...
- Page 2 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Document Revision History Rev. Level Date Description 12/2008 Initial Release Reference Documents (or latest revision) Document # Description 526167 Rev B MAP-9101-100-x Outline Drawing 526371 Rev IR MAP-9101-101-x Outline Drawing Service Bulletin List...
-
Page 3: Table Of Contents
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Table of Contents Section Description Page General Information ...... -
Page 4: General Information
Introduction This manual contains information for the proper application and installation of the DeCrane Aerospace Audio International (DAAI) server, Model No: MAP-9101-10x-x. The MAP-9101-10x-x is a Moving Map Server with a Single Compact Flash Hard Disk Drive and the ability to display the end user’s customized logo. -
Page 5: Optional Equipment
Audio Briefings o Up to 100 Optional Equipment DeCrane Aerospace Audio International offers a comprehensive family of Cabin Control Modules for PC interfaces. These modules provide convenient solutions for a variety of frequently encountered interfacing needs or special requirements and are an important part of DAAI’s “building block”... -
Page 6: Application
2.2.1 Video Output (SVGA, NTSC Analog, and SDI) Typical interfaces include various video distribution and/or signal manipulation devices. The unit is capable of interfacing and providing output to all DeCrane Aerospace Audio International and standard COTS (Commercial-Off-The-Shelf) video devices and/or equipment. 2.2.2 Briefer Audio Output (Mono Analog) This interface is only available for model MAP-9101-101-x. -
Page 7: Additional Interfaces
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 2.3. Additional Interfaces 2.3.1 Audio Interface This interface is only available for model MAP-9101-101-x. This unit provides for the routing of the audio briefer to two (2) audio briefer outputs to allow routing of the briefer to two separate locations. - Page 8 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 2.3.5 Data Communication Interface(s) 2.3.5.1 RS-232 (Serial Port) This unit incorporates one (1) RS-232 serial data bus interface for general purpose communication to external devices. Full hardware handshaking capability is provided. 2.3.5.2 ARINC 429...
-
Page 9: Installation
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Only model MAP-9101-101-x’s can be used to connect a USB mouse connection for map control. Either USB port will accept the mouse connection. Installation Prior to Installation 3.1.1 During the design and layout of the aircraft cabin, careful consideration of the location of the MAP-9101-10x-x is necessary. -
Page 10: Unpacking And Inspection
3.2.2 If damage has occurred during shipping, a claim should be filed with DeCrane Aerospace Audio International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from DAAI by contacting the Repair Department at 501.801.8101. -
Page 11: Wiring Requirements
(6) inches between the lines. 3.4.2 Power Wires DeCrane Aerospace Audio International recommends that the chassis be electrically bonded to the airframe structure by the grounding lug with <0.1 resistance using <50 impedance cable. -
Page 12: Updating Logo File
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 3.4.6 Composite and SDI Video Connections Composite and SDI video connections are recommended to use shielded coaxial cable in accordance with PIC V76261 or equivalent. 3.4.7 SVGA wiring shall be in accordance with NEMA WC 27500 or equivalent. -
Page 13: Updating Audio Briefings
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual the \logo\ directory. The map server will automatically reboot after the file is copied. During the boot process, the USB flash drive must be removed. If the USB flash drive is not removed during the reboot process, the Map Server will continue to reboot as it recognizes the drive after start up and recopies the logo file. - Page 14 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Playlist files must have specific names in order for the control software to locate and play them when they are triggered by an external command. The file name also contains a number which is used to select that list.
- Page 15 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 3.6.4 Setup for Filezilla To setup Filezilla and establish a connection, start Filezilla and press Ctrl+S to open the site manager. You will see a screen similar to the one shown below. Select “New Site” and enter the following information in the proper...
- Page 16 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Select the desired files on the left side, then drag and drop them into the proper directory on the right. Document # 540372, Rev IR, 12/2008 Page 15 of 29...
-
Page 17: Electrical Characteristics
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Electrical Characteristics 3.7.1 Electrical Specifications Electrical Nominal Power 1 A at +28 VDC Maximum Power 1.5 A at +28 VDC +18 to +32 VDC Operating Voltage Range +28 VDC preferred Audio Output Output Type... -
Page 18: Mating Connector Information
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual frame ground with less than 0.010-ohm resistance using less than 50-ohm impedance cable. 3.7.4 Power Interruption This unit is capable of maintaining full normal operation during power interruptions not greater than 200msec. Due to the... - Page 19 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual J7 CONNECTOR (10/100BASE-T ETHERNET PORT) PART NUMBER MATING CONNECTOR MAP-9101-100-1 95043-2891 (RJ45 Plug) or equivalent (Molex) MAP-9101-100-2 95043-2891 (RJ45 Plug) or equivalent (Molex) J8 CONNECTOR (SVGA) PART NUMBER MATING CONNECTOR MAP-9101-100-1 DD15M10JVL0 Male Plug or equivalent...
- Page 20 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual J7 CONNECTOR (10/100BASE-T ETHERNET PORT) PART NUMBER MATING CONNECTOR MAP-9101-101-1 95043-2891 (RJ45 Plug) or equivalent (Molex) MAP-9101-101-2 95043-2891 (RJ45 Plug) or equivalent (Molex) J8 CONNECTOR (SVGA) PART NUMBER CONNECTOR MATING CONNECTOR DD15F10JV30 DD15M10JVL0...
-
Page 21: 3.9 Pinout Assignment Descriptions
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 3.9 Pinout Assignment Descriptions 3.9.1 MAP-9101-100-x Pinout Assignment Descriptions All wiring harnesses to the unit shall be supplied and fabricated by the installing agency. +28V IN RS485A RS485B RS485 Shield ARINC 429 RX A1... - Page 22 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Ethernet Transmit + Ethernet Transmit – Ethernet Receive + Reserved Reserved Ethernet Receive – Reserved Reserved Red Video Green Video Blue Video Reserved Ground Red Ground Green Ground Blue Ground Sync Ground Reserved...
- Page 23 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 3.9.2 MAP-9101-101-x Pinout Assignment Descriptions All wiring harnesses to the unit shall be supplied and fabricated by the installing agency. +28V in RS485A RS485B RS485 Shield ARINC 429 RX A1 ARINC 429 RX B1...
- Page 24 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Ethernet Transmit + Ethernet Transmit – Ethernet Receive + Reserved Reserved Ethernet Receive – Reserved Reserved Red Video Green Video Blue Video Reserved Ground Red Ground Green Ground Blue Ground Sync Ground Reserved...
-
Page 25: 3.10 Post-Installation Test
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 3.10 Post-Installation Test Two (2) externally viewable status LEDs are provided for BIT capabilities. These LEDs are located together, and oriented in a vertical fashion. The LED group location is at the discretion of the designer(s) with consideration given to ease of viewable accessibility. -
Page 26: Specifications
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual • Recheck all connections to the unit for security. Check all harness runs for possible pinching, wire breaks, etc. Recheck all pinouts for application accuracy. • To check data bus integrity, utilizing a voltmeter, oscilloscope, or other voltage instrument, verify proper input voltage on the data bus pins. -
Page 27: Reference Drawings
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the MAP-9101-101-x. All measurements given with a tolerance of ± 0.5". MAP-9101-100-x’s Reference Drawings 7.1.1 Front View 7.1.2 Side View... - Page 28 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 7.1.3 Top View 7.1.4 Back View Document # 540372, Rev IR, 12/2008 Page 27 of 29...
-
Page 29: Map-9101-101-X's Reference Drawings
DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual MAP-9101-101-x’s Reference Drawings 7.2.1 Front View 7.2.2 Side View Document # 540372, Rev IR, 12/2008 Page 28 of 29... - Page 30 DeCrane Aerospace Audio International MAP-9101-10x-x Installation Manual 7.2.3 Top View 7.2.4 Back View Document # 540372, Rev IR, 12/2008 Page 29 of 29...
