Summary of Contents for Moffat SDHU
- Page 1 Sanitisers Models: SDHU, SDCU,SDRU,SDRUCT,SDBU,SDSU Operating & Service Manual Manual 018 Issue 001 July 2020...
-
Page 2: Table Of Contents
To ensure the best results from this unit please take the time to read and follow all safety, installation and maintenance guidelines carefully before proceeding to install. Keep this manual in a safe place for future consultation. These appliances are CE-marked in compliance with the relevant Low Voltage &... -
Page 3: Specification
1: Specification Model Weight Dimensions Power supply (kg) L X W X H (mm) SDHU 450 x 281 x 622 Battery 12v 7Ah Lead Acid SDCU 500 x 400 x1470 with Fused 2.1mm with DC SDRU 550 x 425 x 1472 power lead 1.5m... -
Page 4: Battery Recharge Safety
3: Battery Recharge Safety Important safety instructions for the charger and battery block Should you come into contact with acid from the battery, immediately wash the acid off with water. If acid gets into your eyes, immediately rinse your eyes with water and see a doctor at once! The maximum charging time of the battery is approx. -
Page 5: Wall Mounting
1: Wall Mounting ( Model SDHU.) These instructions are produced as a guide only. • Decide the position that the unit is to be fixed to the wall. • Measure and mark out the location for the fixing holes on the wall. - Page 6 • Place hand under the dispensing nozzle 20 times to allow the Gel to pump through the unit, when the Gel starts to appear continue for an additional 3 times to ensure the system is functioning correctly. Note: Dispensing volume is factory set Models: SDHU, SDCU, SDRU. SDRUCT, SDSU. Models: SDBU. Charger. Battery.
-
Page 7: Operation 6
4:Battery and Gel Connection Models: SDHU, SDCU, SDRU. SDRUCRT, SDSU. Battery connection point Battery lifts out for charging Dispensing Nozzel Vertical Gel Tube Spare Gel Bottle Models: SDBU. Dispensing Nozzel Vertical Gel Tube Battery connection point Spare Gel Bottle Battery lifts out for charging... -
Page 8: Cleaning
17: Cleaning Before attempting to clean the unit, please ensure that the Unit is isolated from the electric supply and allowed to cool down, with all food plates and other Dishes removed from the unit. Do not use a water jet or pressure spray to clean this appliance. Disconnect trolley from mains and wait until appliance has cooled. - Page 9 Battery 12v 7Ah Lead Acid with Fused 2.1mm DC power 12v Lead acid charger 750mA with 2.1mm DC outlet...
- Page 10 Thank you for choosing E&R Moffat! Scan the QR code below to visit the E&R Moffat website for further information: E&R Moffat Ltd. www.ermoffat.co.uk Bonnybridge +44 (0) 1324 812272 FK4 2BS sales@ermoffat.co.uk Scotland...
