1.1 Overview

This chapter provides a brief outline of the functions and features of the WS2030. The

WS2030 is based on the X11DPG-QT motherboard and the CSE-747BTS-R2K20BP

chassis.

In addition to the motherboard and chassis, several important parts that are included with

the system are listed below.

Description

X11DPG-QT Motherboard

4U Chassis

8-port 4U/Tower SAS3 12Gbps Hybrid backplane, supports up to 4x 3.5-

inch SAS3/SATA3 HDD/SSD and 4x NVMe/SAS3/SATA3 storage devices

PASS TO 4 SATA 64/54/44/34CM, W/ 64CM SB, S. 30AWG

4U active CPU heat sink supporting narrow bolster plate mounting

Mechanism for X11 Purley Platform

1U 2200W Redundant, Titanium, 76 (W) x 40 (H) x 336 (L) mm

Power distributor for 4U GPU solution

92x38mm 4-PIN PWM FAN w/ HUS for SC747

92x92x38 mm, 7.5K RPM, SC747 Middle Fan for Passive Cooling GPU

80x80x38 mm 4-pin PWM Fan Assembly for SC743, SC745

1.2 Unpacking the System

Inspect the box the WinFast WS2030 was shipped in and note if it was damaged in any

way. If any equipment appears damaged, please file a damage claim with the carrier who

delivered it.

Decide on a suitable location for the rack unit that will hold the server. It should be situated

in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and

electromagnetic fields are generated. It will also require a grounded AC power outlet nearby.

Be sure to read the precautions and considerations noted in Appendix B.

Chapter 1

Introduction

Main Parts List

Chapter 1: Introduction

Part Number

Quantity

MBD-X11DPG-QT

CSE-747BTS-R2K20BP 1

BPN-SAS3-747TQ-N4

CBL-0188L-02

SNK-P0070APS4

PWS-2K20A-1R

PDB-PT747-6824

Fan-0114L4

FAN-0138L4

FAN-0082L4
