Summary of Contents for SkiTuning BASEMAN
- Page 1 BASEMAN Original operating manual Version 1.1...
- Page 2 Table of content Foreword .................. 3 1.1. Intended Use................3 Overview .................. 4 General ..................5 Preparation ................5 Calibrate the dial gauge ............. 6 Measuring ................. 6 Technical specifications ............. 7...
- Page 3 1. Foreword Before initial startup of the BASEMAN device this operating manual must be read by the operating perso- nel and those responsible for maintenance. It complements the training manuals. Damage or injuries cau- sed by ignoring the content mentioned in these manuals will not assure warranty. The operator is obliged by law to keep the accident regulations in mind, which are regulated within the operator’s country/state.
- Page 4 2. Overview Abb.1 Nr Beschreibung Display USB interface (not needed) Zero button LED- Lamp Lamp holder - fastening screws Lamp holder Straightedge Straightedge - marking Straightedge - fastening screws 10 Calliper 11 Angle of support 12 Adjusting nut 13 ON/OFF button 14 mm/inch button...
- Page 5 In order to work correctly on the bottom edge the actual amount of degrees of the bottom edge must be known. The BASEMAN measures the bottom edge angle precisely to 0,01 degrees. IMPORTAINT: Material which has been already removed cannot be undone anymore. For instance, if material is grinded to 1.5 degrees, one cannot anymore grind back to 1.0 degrees...
- Page 6 5. Calibrate the dial gauge 1. Switch on the dial gauge 2. Put the BASEMAN on a straight surface, adjust the support angle upwards with the adjusting nut (straightedge fully lies upon) ATTENTION: the straitedge has to bear on the surface picture 4 3.
- Page 7 7. Technical specifications Type Baseman weight 288 g ambient temperature limit 0 to 40°C humidity < 80% accuracy 0,01 mm dial gauge battery 1x Lithium Battery CR2032 LED- lamp battery 3x Lithium Battery LR41...
