Coltene BioSonic Suvi Premier Quick Start Manual

Ultrasonic Scaler QuickStart Guide:

Scaler
1. Press S button to turn ON the Scaler.
2. Tip Working mode:
Choose the correct working mode that is marked on the
base of each tip by pressing the corresponding working
mode button on the keypad:
or
40 %
70 %
3. Select scaler function:
With every push of the S button, the function toggles from:
1
Scaling with water
2 Dry mode: scaling without water
3 Irrigation mode: just water, no scaling
The unit is in standby mode when the power cord is
4
connected and the green LED is illuminated.

4. Water regulation:

Depress the foot control pedal in the leftmost position and
adjust the water flow with the control ring on the scaler
handpiece until the water is dripping.

5. Foot Pedal Control:

The scaler is activated when the foot control pedal is
pressed down. The power is regulated from left/ZERO
to right/MAX within the chosen working mode. In ZERO
position there are two functions:
a) irrigation with no scaling power: hold the footpedal
down.
b) diagnostic light: press the footpedal once.
6. Cleaning:
Comprehensive cleaning function:
The cleaning function can be started by pressing C. Water
or disinfectant cleans the water line and handpiece. The
cleaning cycle stops automatically after 80 seconds.
7. Push the S button for 3 seconds to turn the scaler OFF.
or
100 %
2
3
1
4
ON
OFF
ZERO
MAX
