MU-201S3E_AWS_IoT_GettingStarted
Product Name: GNSS/4G/2G Micro Tracker
Part Number: MU-201S3E
Doc Type: User Manual
Doc Id: WI-RD-E-046
Reversion: V1.2
AWS Service
AWS IoT Core
Application:
Fleet Management
Vehicle Security and Recovery
Asset Tracking
Covert Tracking
1
Tracking Solutions
Embedded Antenna design
GPS&Wireless solutions Provider
Devices publish & subscribe
Billions of devices can publish
and subscribe to messages.
AWS IoT Core
Messages are transmitted
and received using the MQTT
protocol which minimizes the
code footprint on the device
and reduces network
bandwidth requirements.
Advertisement
Related Manuals for Sanav MU-201S3E
Summary of Contents for Sanav MU-201S3E
- Page 1 Tracking Solutions Embedded Antenna design GPS&Wireless solutions Provider MU-201S3E_AWS_IoT_GettingStarted Product Name: GNSS/4G/2G Micro Tracker Part Number: MU-201S3E Doc Type: User Manual Doc Id: WI-RD-E-046 Reversion: V1.2 AWS Service AWS IoT Core Application: AWS IoT Core Devices publish & subscribe...
- Page 2 , and unzip AutoCert.zip to a custom location on your computer. Connect MU-201S3E to PC via the Micro USB 8P data cable. (The Micro USB 8P data cable (AP cable) is an optional accessory you can purchase for your MU-201S3E tracker.
- Page 3 PC) shows in Device Manager. If the PC fails to detect the tracker via a data cable, please download the driver at the link below and install it. http://www.prolific.com.tw/US/ShowProduct.aspx?p_id=225&pcid=41 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 4 4. Press and hold the MU-201S3E power button for more than 3 seconds to start the device. 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 5 5. Log in to your Amazon AWS account and select "IAM" service: If you haven’t register a AWS account, open: https://aws.amazon.com/ and click “Sign In to the Console” button. 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 6 On the Sign in page, click “Create a new AWS account” button. For more details, please refer to the instruction below： https://docs.aws.amazon.com/iot/latest/developerguide/setting-up .html#aws-registration 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 7 6. On the left margin of the IAM service page, select “Users” & click “Add user”: 7. Enter a custom User name & select “Access type” as “Programmatic access”: 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 8 8. To “Set permissions”- select “Attach existing policies directly” & check AWSIoTFullAccess 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 9 For sample policies: For more details, please refer to https://docs.aws.amazon.com/iot/latest/developerguide/exam ple-iot-policies.html. Also refer to https://docs.aws.amazon.com/iot/latest/developerguide/securi ty-best-practices.html 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 10 9. To skip the option to“Add tags”, select “Next: Review” 10. Confirm that the information entered on the “Review” page is correct & click “Create user”: 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 11 11. A button to download the .csv file will appear after you successfully “Create user” 12. Save the .csv file downloaded in the previous step to the AutoCert folder. Execute the AutoCert.exe file： 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 12 AWS IoT service for your device. After logging as an AWS user, you can get the region from the left menu -> Settings -> Custom endpoint： 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 13 “Manage -> Thing” to review the device name you just created by AutoCert.exe in the menu on the left margin under AWS IoT service 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 14 Topic entered in Step 13 by going to “Test” item in the menu on the left margin under AWS IoT: 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
- Page 15 17. After subscribing, you should be able to see the data uploaded by the MU201S3 in the message bar below: 11F., No.2, Sec. 4, Jhongyang Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.) Tel: 886-2-22694456｜Fax: 886-2-22694451｜sanav@sanav.com www.sanav.com www.sanav.com...
