1.
General Description
This supplement contains information required for reading, writing and erasing data to/from Renesas Electronics RX66T
series MCU with built-in flash memory.
2.
Operating Environment and List of supporting MCU
2.1 Operating Environment
Use the MCU mentions in this supplement in an environment as follows.
Table2.1 Operating environment
MCU series name
RX66T series
If your S/W version of EFP-LC is old one, download the latest version data from the website below.
< EFP-LC latest S/W free download site >
http://www.suisei.co.jp/download_e/productdata_efplc_e.html
List of supporting MCU
2.2
Show correspondence MCU table in Table2.2 The program to the RX family in EFP-LC needs the setting of the MCU
type.
Please set MCU type by MCU set command of the script command.
Please refer to MCU set command of the EFP-LC instruction manual for the details of the MCU set command.
Table2.2 List of supporting MCU
Set value of the MCU type
38 : RX ( Little endian )
39 : RX ( Big endian )
EFP-LC TypeE Supplementary manual
(For RX66T）
Correspondence MCU series name
RX66T
EFP-LC Version
Ver.2.00.07 or later
（1/24）
EFP-LC TypeE Supplementary manual
Suisei Electronics System CO.LTD.,
1st Edition issue Apr. 2020
(For RX66T)

Advertisement

loading
Need help?

Need help?

Do you have a question about the EFP-LC and is the answer not in the manual?

Questions and answers

Summary of Contents for Suisei EFP-LC

  • Page 1 < EFP-LC latest S/W free download site > http://www.suisei.co.jp/download_e/productdata_efplc_e.html List of supporting MCU Show correspondence MCU table in Table2.2 The program to the RX family in EFP-LC needs the setting of the MCU type. Please set MCU type by MCU set command of the script command.
  • Page 2 Connect EFP-LC with target system Please connect EFP-LC and the connection with the user target system using EF1TGCB-X( tip wire press cable ) or EF1TGCB-B(4 wire type target connection cable) to show it in Fig3.1. Fig3.1 Connection with target system （2/24）...
  • Page 3 As for RESET output at writer side, see Note 2 in the page 4. *3 : The signal GND has 2 pins(No.1,16)of EFP-LC side connector. When connecting to the target board, you can connect with using only one pin, but connecting more than 2pins is recommended.
  • Page 4 If the reset circuit is CMOS output, disconnect by jumper as described in Notes 1, or connect the EFP-LC side T_RESET signal to reset circuit input. By TXD from a writer, RXD and in combination in RESET signal output timing, a serial input and output mode entry is performed.
  • Page 5 When the handling of the Mode pins is not possible on a user target board, connect the T_BUSY pin of EFP -LC to the mode pin of MCU. Table5.1 Handling of mode pins Mode pin pin handling in EFP-LC MCU series name Pin handling name Signal name（4-wire Cable Pin No.）...
  • Page 6 Verify The data with built-in MCU ROM is collated with the content of the Hxw file. Read Reads data from MCU internal ROM to EFP-LC Check sum confirm a checksum value of the MCU built-in ROM. Lock bit The lock bit with built-in MCU ROM is set in the lock.
  • Page 7 : Current capacity that can be provided is up to about 300mA. Nonetheless in case incoming current of substrate is too much, an error occurs, and in the worst case EFP-LC itself is reset. In case this command is used, please do so, taking account of consumption current of target substrate.
  • Page 8 Please description after the MCU set command (T command ) This command is. Note: After setting, changing does MCU setting (T command) or works at the baud rate that set until cut the power supply of the main body of EFP-LC. Table7.1 Setting baud rate(1)
  • Page 9 S=133 11278 S=173 8670 S=213 7042 S=253 5928 S=134 11194 S=174 8620 S=214 7009 S=254 5905 S=135 11111 S=175 8571 S=215 6976 S=255 5882 S=136 11029 S=176 8522 S=216 6944 S=256 5859 unit［bps］ （9/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 10 Boot mode ID authentication is enabled OCD ID Enabled. OCD ID is valid ERASE BLOCK Configuration of erase block Note: If boot mode ID authentication is set, MCU detailed information is output after the ID collation command. （10/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 11 Detail : (1) Setting of boot mode ID authentication code Set the ID code required for EFP-LC connection to the MCU for which ID code is not set. (2) Verification of boot mode ID authentication code The MCU that has already set the ID code is compared with the ID authentication code.
  • Page 12 * A protection error will occur if block erasure prohibition of the protection function is enabled or in areas where TM (trusted memory) is set. * If all erase is executed while TM is set, all areas except the TM setting area will be erased. No error occurs. （12/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 13 Start / End Address Execution unit Memory area Start address End address [Byte] Code flash xxxxxx00h xxxxxxFFh Data flash xxxxxxx0h xxxxxxxFh * A blank error will occur if the area is set to TM (trusted memory). （13/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 14 * If the program prohibition of the protection function is enabled or if the area is set to TM (trusted memory), a protection error will occur. * When writing to the configuration area (120000h – 1200FFh) of the option setting memory, use the O command (P.17) （14/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 15 7.10 Format: R,[Hxw file name],[start address],[end address] * Hxw file name：Specify here the hxw file name, to be read in EFP-LC. * start address：Start address of the area to be read. * end address：End address of the area to be read.
  • Page 16 * An error will occur if the corresponding block start / end address of the MCU is incorrectl y described. * If you lock the area set as TM (Trusted Memory), you will not be able to unlock it. Note that in this state, the configuration clear command cannot be used. （16/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 17 * If the serial programmer connection prohibition is executed, access with the EFP -LC will not be possible and cannot be canceled. Therefore, be very careful when executing this command. * The block erasure prohibition of the protection setting cannot be canceled by EFP -LC. After executing the command, （17/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 18 (If the ID code is not set, the ID code will be set.) ; Erase all area e,FF7FFFFF,1 Clear user boot area e,00100000,00107FFF,1 Clear data area e,FFF80000,FFFFFFFF,1 Clear user area ; Configuration clear Execute configuration clear command （18/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 19 All FFH TM function Invalid ROM code protection Invalid Note: * This command cannot be used when the lock bit is set. * This command cannot be used when block erase is disabled. （19/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 20 * This command may cause a safety problem depending on the circuit configuration of the target board. Please consider this point carefully and use it at your own risk. * We cannot take responsibility for any damage caused by use. Also, MCU operation at reset release is not guaranteed. （20/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 21 Write program to user area p,Data_Program.hxw,00100000,00107FFF,1 Write program to data area p,Boot_Program.hxw,FF7F8000,FF7FFFFF,1 Write program to user boot area ; Verify check Verify check with “User_Prog.hxw” v,User_Prog.hxw,FFF80000,FFFFFFFF v,Data_Program.hxw,00100000,00107FFF Verify check with "Data_Program.hxw" v,Boot_Program.hxw,FF7F8000,FF7FFFFF Verify check with "Boot_Program.hxw" （21/24） EFP-LC TypeE Supplementary manual (For RX66T)
  • Page 22 ○ : Light up, ◎ : Blink, ● : EXtinction Supplementary information about the script error The EFP-LC compare the addresses of Hxw file address and PBT file written in PBT file. Script error will be raised if the following conditions are satisfied.
  • Page 23 10.1 Write time Table10 shows the writing time of RX66T (512KB). Measurement condition: EFP-LC F / W Ver. 2.00.07 External power supply voltage 5.0 [V] Clock on-chip oscillator clock (no external clock is used) Communication baud rate 1,500,000 [bps] The command was executed for the program ROM area (FFF80000h-FFFFFFFFh).
  • Page 24 Revision history Revised date Content version April 3, 2020 Create New Edition （24/24） EFP-LC TypeE Supplementary manual (For RX66T)
