Summary of Contents for Bell'O AD715-BTWTK
-
Page 1: Table Of Contents
hello@belloeveryday.com Quick Start Guide Table of Contents 1. Product Overview 1.1 General Information 1.2 Configuration and Functions of Bello 1.3 Bello Status 2. How to use 2.1 Precautionary Steps 2.2 Pairing Bello with Bello App 2.3 Scan Instructions of Bello Index 2.4 Get More Information on Main Page 3. -
Page 2: Product Overview
1.2. Configuration and Functions of Bello Bello is an instrument for quantitative measurement of abdominal fat based on the principle of calculating user’s fat percentage by using multi-wavelength light and analyzing bio-signals. 1.2.1 Product Configuration (Model : AD715-BTWTK) Bello includes: Components... - Page 3 1.2.2 Functions of Bello Top Button (On/Off/Scanning) Display LED Scanning light Charging light Front View LED Source Detector Bottom View USB (5 pin) charging port Back View...
-
Page 4: Bello Status
1.3. Bello Status 1.3.1 Display LED Status In order for the user to know the current operating status of Bello, they should check the display LED indicator during operation. For more information, refer to the LED status examples listed below: Display LED Status Name... - Page 5 1.3.2 Bello Scanning Status Scanning Light (Yellow) Yellow Scanning Light Status Yellow Light Mode Status Light flashes every 1 Scanning second All mode except scanning mode 1.3.3 Bello Battery Status Charging Light (Blue) Blue Charging Light Status Blue Light Mode Status Normal Blue light lights up...
-
Page 6: How To Use
2. How to use 2.1. Precautionary Steps 2.1.1 Precautionary steps before operation • Before operation, please make sure to familiarize yourself with the operating method on the user manual. • Ensure that all product components are included in the product’s package. •... -
Page 7: Pairing Bello With Bello App
2.2. Pairing Bello with Bello App 2.2.1 Installing Bello App • Enter the App store URL (https://apps.apple.com/app/id1485202681) • Search App Stores by Keyword # Bello # Bello Decode • Scan QR Code • Enter the App store URL (https://play.google.com/store/apps/details?id=ohc.app.bello) • Search App Stores by Keyword # Bello # Bello Decode •... - Page 8 Pairing in Android Mode • Android users also have to click on the yellow “Connect” button and enter the 6-digit PIN Code “111111” on the pop-up screen. • If the Bello device is disconnected from the App or fails to connect to the App, Android users should re-enter the 6-digit PIN Code “111111”.
-
Page 9: Scan Instructions Of Bello Index
2.3. Scan Instructions of Bello Index 2.3.1 How to scan your belly fat Scan Upper Belly Scan Lower Belly • When the “Scan upper belly” screen appears on the app, place the Bello device one inch above your belly button and lightly click the TOP button. -
Page 10: Get More Information On Main Page
2.4. Get More Information on Main Page 2.4.1 Overview of Main Page Home Profile (Main Page) Scanning Mode... - Page 11 2.4.2 Main Page Tab Metabolic Health Index Bello Index Bello Everyday Food & Activity Recommendation Discover food and activity recommendations to improve your health Weight & Waist Update weight and waist size Data Sync with Apple Health / Google Fit App Track your daily activity level by syncing data from the Apple Health app and Google Fit app.
- Page 12 Sync Health Data to Track Daily Activity Level • You can track your daily activity level by syncing your data from the Apple Health app or Google Fit app. • In order to keep all of your data in one place within the Bello app, tap the “Sync Data”...
- Page 13 iOS User Android User Profile Bello Inquiry • When you tap the “Email Us” button ( ) at the top right of the screen, you will see Bello Inquiry page as shown in the image below. • By going on the “Bello Inquiry” page, you can send inquiry to hello@belloeveryday.com directly including some information as stated below: - Bello Account - Phone Model...
-
Page 14: Troubleshooting
3. Troubleshooting 3.1. Troubleshooting Name Role • Press and hold the TOP button for at least 10 seconds while the device is turned off. When the device fails to be • Check whether the device is in charging mode. turned ON (Blue battery light is turned on or flashing) •... -
Page 15: Warranty
Please have the following information available when contacting Olive Healthcare Inc. for efficient assistance: - Your product type / model number (e.g. Bello / AD715-BTWTK) - Your proof-of-purchase (e.g. original invoice or cash receipt) indicating the date of purchase, dealer name, model number of the product and serial number;... - Page 16 Appendix A) Electrical Specifications Item Description Operating voltage and power consumption DC 3.3 ~ 4.2V / 0.4VA (Lab. Test at Olive Healthcare) (Battery) 3.7V, 1050mA Battery (For battery operation) Version: BLE 4.1 Bluetooth (2402~2480MHz) Note • The device will be turned off automatically if the device is not being used for more than 3 minutes. •...
- Page 17 C) Safety Precautions When potential safety problems and abnormal symptoms are discovered during operation, immediately stop the operation, and notify customer service (Representative No. of Olive Healthcare). Notes on operation are listed as below: • Do not let direct your eyeball towards, or directly stare at, the scanning light source. Damages can be inflicted on your eyeballs from light being radiated on them.
- Page 18 E) FCC Statement FCC Part 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and (2) this device must accept any interference received, User Manual including interference that may cause undesired operation.
