Summary of Contents for Mr.Signal cAPPito

  • Page 1 Instruction Manual English...
  • Page 2 Instruction Manual English Model name: cAPPito Manufacturer: Mr.Signal Order no.: 2248387 instructions´ Identification number --Mr.Signal cAPPito MrS20200305M01-EN-- Product identification number: 2020030301 IMPORTANT! READ CAREFULLY BEFORE USE! KEEP FOR FUTURE REFERENCE!
  • Page 3 1. Introduction Dear customer, this product meets the legal national and European requirements. To maintain this condition and to ensure safe operation, you as the user must observe these operating instructions carefully! These operating instructions belong to this product. It contains important information on commissioning and handling.

  • Page 4: Intended Use

    2. Intended use This product must be operated with an external power supply that complies with the relevant regulations and standards of the country of destination. The power supply of the power supply unit should provide 230 Volts. The power supply itself should supply 5V DC and a minimum rated current of 3A..
  • Page 5 Do not place any containers filled with liquids, e.g. glasses, vases, etc., on • cAPPito or in its direct vicinity and never pour liquids over the device. Liquids could get inside the housing and impair electrical safety. There is also a high risk of fire or life-threatening electric shock! •...
  • Page 6 Use case, highlights, details, Passwords cAPPito Base can help to redically redce the cost of setting up an digital infrastructure (fast internet, end consumer devices, software licenses, maintenance). The bring-your-own-device concept cuts the cost of end user device maintenance on top.
  • Page 7 6. The hardware at a glance 7. Assembly of the hardware 1) Insert the enclosed WiFi dongle into the open USB 3.0 port (blue) of the cAPPito Base. 2) Insert one end of the power supply into the Micro USBC port of the cAPPito Base.
  • Page 8 8. Software and initial operation To save paper all details and features of using cAPPito are shown in the integrated video tutorials. They are also available via the products website. After first connecting to cAPPito, find the video tutorials in the integrated fileshare.

  • Page 9: Overview Of The Modules

    9. Overview of the modules a) Dashboard In the dashboard you start and end the individual modules. (questionnaire, presentations and fileshares) (View„Tutor“) b) Presentation This module can be compared to the function of a "beamer", whereby videos, images and presentations are imported as PDFs for an audience/auditorium/student on their own Smart Device at a desired time.
  • Page 10 (View„Tutor“) (View „Participant“) c) Questionnaire: 'Create a multiple-choice test“ The module „Questionnaire“ for the creation and automatic evaluation of learning objective controls was developed to be used independently of location and decentralised. With the possibility of offering tests during lessons, learners can be optimally supported, e.g. in exam preparation, with a minimum of supervision.
  • Page 11 (View „Tutor“)
  • Page 12 (View „Tutor“) (View „Participant“) d) Fileshare In order to create further interactivity between teacher and student, a temporarily activated folder/list is provided. The aim of this is the upload of teaching materials (worksheets, test evaluations, pictures, short videos, voice) by the student. This folder/list is temporarily unlocked by the tutor on site.
  • Page 13 (View „Tutor“) (View „Participant“)

  • Page 14: Maintenance

    11. Trouble Shooting With cAPPito you have purchased a product that is state of the art and reliable. Nontheless, problems may occur. In the following, the procedure for trouble shooting is described.
  • Page 15 Dispose of the product at the end of its service life in accordance with the applicable legal regulations. You can also send your old cAPPito devices back to Mr Signal GmbH. We will dispose it professionally and as environmentally friendly as possible.

  • Page 16: Technical Data

    14. Technical data The power supply of the cAPPito Base is done by a separate plug power supply (230V) with USB-C connection which delivers 5V at 3A. Voltage: 5,1 V Current: 0.3 - 0.7 A Idling power: 3.7 W Full load power: 6.1 W Transmitter antenna/transmitting power The Mr.Signal Base uses WiFi antennas with the standard 802.11 b/g/n/ac frequency:...
  • Page 17 Data transmission is also possible via HTTPS and complies with thus high safety standards. Storage capacity The memory of the Mr.Signal Bases is 64 GB in the standard model. Mr.Signal Bases with higher capacities are available on request. Please contact us! 15. declaration of conformity Hereby Mr.Signal GmbH, Schumannstr.
