Summary of Contents for TVT NVMS
- Page 1 NVMS Storage Server User Manual...
- Page 2 16-disk storage server. Please refer to the real servers as the pictures may be different from the real servers. The storage server is mainly used with NVMS. This manual only introduces its system setup. Please refer to the storage server chapter in the NVMS user manual for detailed use.
-
Page 3: Table Of Contents
Contents Installation ..........................1 Interfaces and Indicators ......................1 Rear Panel Instruction ......................1 HDD Installation .........................2 Default System Configuration ....................2 Web Client Configuration .......................3 Login ...........................3 Disk RAID ..........................3 Network Configuration ......................4 Server Port Configuration ....................5 Change Password ........................6 Basic Information ........................6 Date &... -
Page 4: Installation
NVMS Storage Server User Manual 1 Installation 1.1 Interfaces and Indicators The icons below are for reference only. Please refer to the interfaces and indicators of the real server. Icon Description Icon Description System disk running indicator; flashing Power Key green light indicators the disk works normally. -
Page 5: Hdd Installation
NVMS Storage Server User Manual Description Description Redundant Power Connector USB3.0 interface Management interface RJ45 interface RS232 interface VGA interface USB2.0 interface 1.3 HDD Installation ① Press the blue button, hold the pull rod to pull out the HDD case and then install the HDD into the case. -
Page 6: Web Client Configuration
NVMS Storage Server User Manual The default web management page: http://192.168.0.10:8000. The default username is admin and the default password is also 123456. The disks installed in one storage server used for RAID should be of the same brand, capacity, rotate speed and buffer. -
Page 7: Network Configuration
NVMS Storage Server User Manual Tips: It is recommended to create Raid5 and check hotspare disk for data security. Click “Delete” button to pop up a confirmation dialog box. The created RAID will be deleted if you click “Yes” button. Please be careful to delete the RAID because the record data stored in the RAID will not be recovered once you delete the RAID. -
Page 8: Server Port Configuration
NVMS Storage Server User Manual You will get a virtual IP address if the IP group is enabled. As to the access of the virtual IP address, the operation system of the storage server will judge and transfer the access to eth0 or eth1 automatically. -
Page 9: Change Password
NVMS Storage Server User Manual Auto Report Port: the default number is 2009. Storage server port: the default number is 6009. The above-mentioned ports can be modified and enabled as needed. 3.5 Change Password For safety consideration, it’s strongly recommended to modify the default administrator’s username and password if you access the storage server for the first time. -
Page 10: Upgrade
NVMS Storage Server User Manual 3.8 Upgrade You can upgrade the storage server when there is a new software version. Get the upgrade software from you dealer; click System Maintenance Device Upgrade to go to the interface as shown blow. -
Page 11: Specifications
Up to 800Mbps access, 800Mbps storage and 96Mbps playback Up to 800Mbps access, 800Mbps storage and 96Mbps live view Way of Management WEB management, seamless access to NVMS Capability RAID management, record management, system log as well as alarm processing... - Page 12 Up to 800Mbps access, 800Mbps storage and 96Mbps playback Up to 800Mbps access, 800Mbps storage and 96Mbps live view Way of Management WEB management, seamless access to NVMS Capability RAID management, record management, system log as well as alarm processing...
-
Page 13: Appendix Device Installation
NVMS Storage Server User Manual Appendix Device Installation...
