Atos E-BM-AS Series Quick Start Manual

Digital electronic E-BM-AS drivers
DIN-rail format, for proportional valves without transducer
POWER
STATUS
S1
S2
E-BM-AS
Scale Bias
1

MODEL CODE

-
E-BM
AS
Off-board electronic driver
in DIN rail format
AS = digital basic driver,
for valves without transducer
PS = Serial communication interface
01H = for single solenoid proportional valves
05H = for double solenoid or two single solenoid
proportional valves
2

BLOCK DIAGRAM

Electronic
reference
input signals
1
B
CMD1
2
CMD-
3
CMD2
4
DGND
A
Current
supply to 4
solenoids
3
2
1
CURRENT TO CURRENT TO
SOLENOID S1
SOLENOID S2
Only for 05H
Internal
Rererence
Generator
C D
Enhanced
Diagnostic
Hydraulic
B A
Power
Limitation
(option /W)
Ramps Linearization
DVD E-SW-BASIC
Programming Software
- /
-
01H *
PS
Options:
- = standard 24 V
12 = 12 V
DC
A = max current limitation for ex-proof valves
C = current feedback 4 ÷ 20 mA for
remote transducer, only for IW
I = current reference input 4 ÷ 20 mA
(omit for standard voltage reference
input ±10 V
P = electrical supply for external potentio-
meters to generate reference signal,
not available with I option (see 4.4)
W = power limitation function, only for 05H
(see 7.7)
RS232
RJ45
CONNECTOR
REFERENCE
GENERATOR
SCALE
SCALE
SINGLE SOLENOID VALVE
VALVE'S ELECTRICAL CONNECTORS
E-SW
programming
software
*
power supply
DC
power supply
)
DC
MICROCONTROLLER
REFERENCE S1
LOGIC
REFERENCE S2
BIAS LINEARIZ. RAMPS
BIAS LINEARIZ. RAMPS
TWO SINGLE SOLENOID VALVES
01H 05H
Table
E-BM-AS
Digital drivers control the current to the
solenoid of Atos proportional valves without
transducer, according to the electronic
reference input signal.
The solenoid proportionally transforms the
current into a force, acting on the valve
spool or poppet, against a reacting spring,
thus providing the hydraulic regulation.
E-BM-AS can drive up to two single or one
double solenoid proportional valves.

Electrical Features:

• 4 fast plug-in connectors
• RJ45 connector for RS232 Serial com-
munication to program the driver with the
Atos PC software
• 4 leds for diagnostics (see section
• ±5 V output supply for external referen-
DC
ce potentiometers (/P option)
• Electrical protection against reverse pola-
rity of power supply
• Operating temperature range: -20 ÷ +60 °C
• Plastic box with IP20 protection degree
and standard DIN-rail mounting
• CE mark according to EMC directive

Software Features:

• Intuitive graphic interface
• Setting of valve's functional parameters:
bias, scale, ramps, dither
• Linearization function for the hydraulic
regulation
• 2 selectable modes for electronic reference
signal: external analog input or internal
generation
• /W option max power limitation function
• Complete diagnostics of driver status
1
DI1
C
2
DI2
3
DI3
4
DI4
D
DC/DC
CONVERTER
POWER
1
SUPPLY V+
2
POWER GND
3
ENABLE input
4
STATUS output
EARTH
DOUBLE SOLENOID VALVE
05H
G030-8/E
)
10
ON/OFF
inputs
G030
