PARTS LISTING GENERAL INSTRUCTIONS – ROUND POOLS LEDGE COVER S-POOL SCREW COVER RIGHT S-POOL SCREW COVER LEFT S-POOL COMMON LEDGE (15’ – 33’ Round) STABILIZER TOP PLATE METAL UPRIGHT (FOR 52’’ TALL POOL) METAL UPRIGHT (FOR 54’’ TALL POOL) BOTTOM FOOT PLATE...
Page 4
TOP LEDGE 38917 S-POOL SCREW COVER RIGHT 38920 S-POOL SCREW COVER LEFT 38921 S-POOL COMMON RAIL (12’ Round Only) 38928 S-POOL COMMON RAIL (15’ – 33’ Round) 38919 STABILIZER XXXXX TOP PLATE 38918 METAL UPRIGHT (FOR 52’’ TALL POOL) 38970 METAL UPRIGHT (FOR 54’’...
Page 5
TOP LEDGE 38917 S-POOL SCREW COVER RIGHT 38920 S-POOL SCREW COVER LEFT 38921 S-POOL COMMON RAIL (12’ Round Only) 38928 S-POOL COMMON RAIL (15’ – 33’ Round) 38919 STABILIZER XXXXX TOP PLATE 38918 METAL UPRIGHT (FOR 52’’ TALL POOL) 38970 METAL UPRIGHT (FOR 54’’...
Page 6
PREPARATION Plan your installa on rst Check local laws on construc on and electrical installa on. Also make sure that you meet security standards related to fences and pool cover. Select an appropriate site for your swimming pool by considering the following points: + Distance from the fence + Do not install your pool on concrete, + Overhead electrical wires...
Page 7
GROUND PREPARATION Be careful Above ground pools are not designed to be installed below ground level. Outside ground forces can collapse pool wall. If you have an irregular terrain, contact your dealer for approppriate advice. Pools installed on irregular terrain ARE NOT COVERED BY THE MANUFACTURER WARRANTY.
Page 8
GROUND PREPARATION Leveling your pool site The en re pool area must be completely leveled. Level it using carpenter’s level and a straight plank or a transit. Nail one end of a straight 2-by-4 (5cm x 10cm) wood plank to the top of a stake.
Page 9
ASSEMBLING THE POOL BASE stones installa Concrete pa o stones may be placed at the base of each upright of your pool. Each bo om plate will show the loca on for a pa o stone. Make a mark on the ground at each base plate.
Page 10
ASSEMBLING THE POOL WALL DO NOT SKIP THIS STEP! Otherwise you might end up with a slightly oval shape, which can cause problems later on. (image 7) Pu ng up the wall the pool wall: plywood, some extr to make the cove, the liner and a ladder Make sure the skimmer and water return holes are located where you need them to be.
Page 11
ASSEMBLING THE POOL WALL IMPORTANT NOTE: It is preferable to use very ne sand that is easily compacted. Be careful not to spill sand on the bo om rails. We also suggest installing vinyl-covered hooks and rope to hold the wall steady (image 10). Ideally the help of several people should be solicited to hold the wall in place.
Page 12
ASSEMBLING THE POOL WALL Fasten and seal the wall tening the screws start from either the top and go down or vice versa. Do not start necessary. (image 13) IMPORTANT NOTE: S ck a screwdriver through two of the holes to help line up the ends of the walls.
Page 13
ASSEMBLING THE POOL WALL Pu ng down the pool base and cove You must spread a sand base down across the re b om of the pool. The base should be 2" to 3" deep (5 cm - 7.5 cm). Along the inside of the pool wall you must form a pool cove that is 3"...
Page 14
INSTALLING THE LINER Close the skimmer opening with cardboard and adhesive tape so that the Set the liner in place. Open the carton. Do not use anything sharp to open the carton. Unpack and unfold the liner and spread it out in the sun to warm it up. Inspect all the seams and surfaces for holes.
Page 15
INSTALLING THE LINER TYPE 1 - overlap up and down, perpendicular t r. (remove stabilizers gradually as you fold the liner over the top of the wall.) This will assure that the liner begins going over the wall straight. (image 19) IMPORTANT NOTE: Some liners may t very ghtly, it is be er to install uprights, top plate and rail before going onto next step.
Page 16
INSTALLING THE LINER TYPE 2 – bead/snap bead liner With a snap bead liner you should have received a beaded liner track (referred to as a “coping bead receiver”). (image 22) The beaded liner track should be installed onto the pool wall all of the way around the pool. These pieces should be as close together as possible.
Page 17
INSTALLING THE LINER TYPE 3 – hung/J or V-bead line The top of the wall of the liner has what is called a “V-Bead” welded onto it. Simply open up the bead with your ngers and hang it directly on top of the pool wall. (image 23) When this is done properly, the only por on on the outside of the pool wall is approximately 1”...
Page 18
ASSEMBLING THE POOL FRAME Install the uprights The wall joints are hidden behind the upright on most pools. This assures that the skimmer and the skimmer return holes are not obstructed. Insert the upright in the bo om joining plate un l the hooks snaps. (image 25) IMPORTANT NOTE: Use the ridges in the pool wall to make sure the upright column is straight up and down.
Page 19
ASSEMBLING THE POOL FRAME 11 . Install top plate Align the top plate on the upright and insert it in. The top plate slides into the top of the upright by applying pressure thus securing the wall and the upright together. Secure it with the four 1/2"...
Page 20
ASSEMBLING THE POOL FRAME Install screw covers The arrows must point toward the inside of the pool. Match each screw cover, right (R) and le (L) with proper screw cavity on top ledge and snap in place. (image 29) Install the ledge cover Place ledge cover over the top plate and push downward un l the side hooks snap in place.
Page 21
Rules for safe pool use NECESSARY SAFETY EQUIPMENT: A light and strong pole not less than 12 (3,66m) long with blunt ends. A ring type life preserver with a throwing rope a ached to it. Have emergency numbers near the pool and also at the telephone nearest to the pool.
