- Page 1 1300 301 755 TRAVEL8.COM.AU PERMANENT GUARDRAIL SYSTEM FOR HIGHEST LEVEL OF SAFETY WHEN WORKING AT HEIGHTS MUST BE READ AND UNDERSTOOD PRIOR TO USE...
- Page 2 Typical Guardrail Requirements (From AS1657 :2013 Standards) Guardrail on Platforms Guardrail Height Guardrail is not required on a platform if Minimum height for the height to lower landing is less than guardrailing is 900mm from 300mm and (W) is not more than 1000mm. the walking surface.
- Page 3 Typical Guardrail Requirements (From AS1657 :2013 Standards) Typical Walkway Application Types ACROSS SLOPE IN-LINE WITH SLOPE 0 - 7 Degrees 0 - 7 Degrees Roof Angle : 0 - 7 Degrees Roof Angle : 0 - 7 Degrees - Walkway same angle as roof - Walkway same angle as Direction of Travel roof...
- Page 4 SENTRY GUARDRAIL CRITERIA PART (View 1) PART (View 2) CRITERIA CHECKED / COMMENTS Minimum Qty of fixings:- 4 x 5mm bulb-tite rivets or 3 x 8mm bulb-tite rivets For any guardrail channel fixed to roof deck Minimum 2 fixings into Handrail Minimum 2 fixings into Kneerail Minimum Qty - 2 x Fixings for each connection point...
- Page 5 SENTRY GUARDRAIL CHECKING CRITERIA PART (View 1) PART (View 2) CRITERIA CHECKED / COMMENTS Up tp 400mm Overhang 300* *Overhang Allowance 300mm Preferred 400mm Max if multiple span (more than 2 posts) Max 2000 **Post Spacing Max 2200 2000mm Preferred 2200mm Max if multiple span (more than 2 posts) DESCRIPTION...
- Page 6 2000 Max 450 NOTE - SENTRY Guardrail System is standard 1000mm high Guardrail over 1100mm high will require an additional mid-rail Max 450 Max 560 TOEBOARD POST SPACING - 2 POSTS Max 10mm Gap under toeboard 2000 Preferred (Max 2200 if more than 2 posts) GW374 - Handrail Extrusion SENTRY Post GW375 - Kneerail Extrusion...
- Page 7 END CAP DETAILS SD910 - 16mm SD TEK Screw - QTY 2 Groove to locate TEK Screw SD907.20 - 20mm SD TEK Screw SD907.48 - 48mm SD TEK Screw - QTY 2 SD907.20 - 20mm SD TEK Screw POST CONNECTION DETAILS DESCRIPTION DRG No.
- Page 8 QTY 2, 10 x 75mm Trubolt or QTY 2, 8 x 75mm Screwbolt or similar or QTY 2, 10mm Stud with Chemset - 75mm deep REFER TO D9088 FOR GUARDRAIL DETAILS DESCRIPTION DRG No. DATE 1029 MOUNTAIN HWY BORONIA VIC 3155 T +61 1300 301 755 F +61 1300 881 092 3002...
- Page 9 Concrete Parapet (Must be structurally sound and/or verified by Engineer) SD910.10 - Screw 10-16 x 16mm Tek S_S SENTRY Handrail Endcap SD907.20 - 20mm Tek Screw GW351.20 SENTRY Guardrail Post SENTRY Kneerail End Cap SD907.20 - 20mm Tek Screw Check edge distance SD907.48 - 48mm Tek Screw with fixing manufacturer QTY 2, 10 x 75mm Trubolt or...
- Page 10 NOTES The SENTRY Guardrail Systems complies with AS1657 when installed as per the instructions detailed. These drawings and Instructions must be read in conjunction with the Australian Standards Criteria. Guardrail height is to be 900 - 1000mm from the walking surface or the nosing of a stair tread.
- Page 11 Max 2000 Main Support Channel (38 x 65 x 3mm) 5mm Bulb-tite Rivet Nitrile foam seal Roof deck Approx 230mm Spacing Notes - A 3rd rail is recommended if the roof slope is above 12 deg - A toeboard is required if an object can fall from a platform or walkway onto an area which persons have access to the area below.
- Page 12 NOTES The SENTRY Guardrail Systems complies with AS1657 : 2013 when installed as per the instructions detailed. These drawings and Instructions must be read in conjunction with the Australian Standards Criteria. Guardrail height is to be 900 - 1000mm from the walking surface or the nosing of a stair tread.
- Page 13 SD910.10 10-16 x 16 SS Tek Screw SD907.20 12-14 x 20 SS Tek Screw SD907.48 12-14 x 48 SS Tek Screw SD907.45 12-14 x 45 Gal Tek Screw SD913 5mm Bulb-tite Rivet Top Batten Main Support Channel Bulb-tite Rivet Nitrile foam seal Roof deck FIXING DETAILS DESCRIPTION...
- Page 14 670 Max DESCRIPTION DRG No. DATE 1029 MOUNTAIN HWY BORONIA VIC 3155 T +61 1300 301 755 F +61 1300 881 092 2628 30/8/2019 GW5 - ALUMINIUM WALKWAY WITH E sales@sayfa.com.au E sayfa.com.au GUARDRAIL ONE SIDE - LEVELLED Code THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au...
- Page 15 SD910.10 10-16 x 16 SS Tek Screw SD907.20 12-14 x 20 SS Tek Screw SD907.48 12-14 x 48 SS Tek Screw SD907.45 12-14 x 45 Gal Tek Screw SD913 5mm Bulb-tite Rivet Top Batten Main Support Channel Bulb-tite Rivet Nitrile foam seal Roof deck FIXING DETAILS DESCRIPTION...
- Page 16 NOTES The SENTRY Guardrail Systems complies with AS1657 : 2013 when installed as per the instructions detailed. These drawings and Instructions must be read in conjunction with the Australian Standards Criteria. Guardrail height is to be 900 - 1000mm from the walking surface or the nosing of a stair tread.
- Page 17 2000 550 Min 670 Max DESCRIPTION DRG No. DATE 1029 MOUNTAIN HWY BORONIA VIC 3155 T +61 1300 301 755 F +61 1300 881 092 4070 10/7/2019 ALUMINIUM WALKWAY WITH SENTRY E sales@sayfa.com.au E sayfa.com.au Code GUARDRAIL ON BOTH SIDES - LEVELLED THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN 2 - MV PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au...
- Page 18 SD910.10 10-16 x 16 SS Tek Screw SD907.20 12-14 x 20 SS Tek Screw SD907.48 12-14 x 48 SS Tek Screw SD907.35 12-14 x 35 SS Tek Screw SD913 5mm Bulb-tite Rivet Top Batten Main Support Channel Bulb-tite Rivet Nitrile foam seal Roof deck FIXING DETAILS DESCRIPTION...
- Page 19 2000 Max 670 Max GW357 - Double Guardrail Post Kit Walkway Batten GW354 - Guardrail Post Kit with Walkway Support GW357 - Double Guardrail Post Kit 50 - 300mm NOTE: All Drawings are designed to comply with current Australian Standards and Compliance Codes for maintenance access.
- Page 20 GW382 Handrail Elbow SENTRY Corner Elbow Installation Insert the corner elbow into the handrail extrusion and fix with 1 x 20mm tek screw from the underside. Slide the adjacent handrail tube section onto the SD907.20 - 20mm Tek Screw elbow then secure using 1 x 20mm tek screw as before.
- Page 21 AL782 - Sentry Handrail Splice GW376 and GW377 Splice Join Installation Insert the splice join halfway into the handrail/kneerail tube. Fix 2 x 20mm Tek Screws through the tube into the splice join. Slide the next section of handrail/kneerail tube over the SD907.20 - 20mm Tek Screw splice join and fix with another 2 x 20mm Tek Screws.
- Page 22 4.5mm Aluminium Rivet GW387 - Closure Bend Kit Cut the Handrail tube flush with the post (Note, this is the preferred option but it not critical - MAX overhand SD907.20 - 20mm Tek Screw of top handrail tube - 300mm) Ensure the kneerail is protruding approx 200mm.
- Page 23 SW378 - SENTRY Handrail Endcap SD907.20 - 20mm Tek Screw SD910.10 - Screw 10-16 x 16mm Tek Screw (2 per post) SD907.20 - 20mm Tek Screw GW379 - SENTRY Kneerail Endcap SD907.48 - 48mm Tek Screw (2 per post) GW384 - Handrail Brace Note: - 2 required for every straight run of guardrail DESCRIPTION DRG No.
- Page 24 Standard GW353 Base Kit 8mm Bulbtite Rivet (4) 20mm Tek Screw (2) Shortened base option 50 x 50 x 3 Angle (300mm) Post and Brace as per standard installation details Teks or rivets Shortened base option (4 x 8mm Rivets Total + 2 x 20mm Teks or Rivets) Standard GW353 Base Kit (4 x 6mm Rivets Total) DESCRIPTION...
- Page 25 EPDM Seal Roof Deck 20mm Tek Screw Min 4 Fixings per post EPDM Foam Seal C-Channel Section Guardrail to be installed as per SENTRY Installation Manual Standard SENTRY GW353 Post NOTE Fixing through roof rib is a recommendation only. Local and State plumbing regulations will need to be adhered to at all times.
