GOLDEN RETRIEVER
Installation Instructions
The Golden Retriever is a portable, ruggedized case with a high
performance 5 in 1 Parsec antenna built into the lid. It is available with
MIMO LTE, MIMO WiFi, and GPS. This compact, portable office in
a box is perfect for a wide variety of mobile communications. Add a
wireless router and battery and this Golden Retriever case antenna will
provide on the go connectivity wherever you are. Designed to operate
roughly up to 5 simultaneous devices at once.
REQUIRED TOOLS
Phillips Screwdriver
REQUIRED ACCESSORIES (PRO5GR2L2WG-L OR PRO5GR2L2WG-A)
Router (select one of the following routers.)
•
CRADLEPOINT IBR900-1200M
•
CRADLEPOINT IBR600
•
INSEEGO SKYUS 160
•
SIERRA WIRELESS AIRLINK RV55
Ethernet Cords: 2pc (Length as required by the customer)(Not required for A version)
Power Supply (required for router)
Extension Cord (NEMA 5-15 Plug to NEMA 5-15 Socket)
Electronic Equipment Power Cord (NEMA 5-15 Plug x IEC C13 Socket, SVT)
REQUIRED ACCESSORIES (PRO5GR2L2WG-G1 OR PRO5GR2L2WG-G2)
Router (select one of the following routers.)
•
CRADLEPOINT IBR900-1200M
•
CRADLEPOINT IBR600
•
INSEEGO SKYUS 160
•
SIERRA WIRELESS AIRLINK RV55
Ethernet Cords: 2pc (Length as required by the customer)(Not required for A version)
Battery: PowerAdd Pilot Pro 2 23000mAH Portable Battery Charger
Ethernet Cords: 2pc (1pc for G1 version. Length as required by the customer)
USB Cords: 1 pc (Length as required by customer. Only for G2 version)
Cradlepoint 2x2 Power to Barrel Adapter (Part #170665-000)
Advertisement
Summary of Contents for Parsec Srl GOLDEN RETRIEVER
- Page 1 GOLDEN RETRIEVER Installation Instructions The Golden Retriever is a portable, ruggedized case with a high performance 5 in 1 Parsec antenna built into the lid. It is available with MIMO LTE, MIMO WiFi, and GPS. This compact, portable office in a box is perfect for a wide variety of mobile communications.
-
Page 2: Router Installation
Router Installation: Step 1. Check the power options available on the case. - For PRO5GR2L2WG-G1 or PRO5GR2L2WG-G2: Install the battery on the top cover plate as directed in the “Router Power Options” step. - For PRO5GR2L2WG-L or PRO5GR2L2WG-A: No Battery Option. Step 2. - Page 3 Step 4. Connect the Antenna cables to the router. Clean all connectors so there is no dust in the terminals. Follow the chart to connect the cables. (Figures 2-4) FIGURE 2 FIGURE 3 FIGURE 4...
- Page 4 Step 5. (PRO5GR2L2WG-G1 OR PRO5GR2L2WG-G2) Use the Cradlepoint 2x2 Power to Barrel Adapter to connect the router to the battery. Connect one of the switch’s barrel connector to the battery and the other to the cradlepoint 2x2 power to barrel adapter. (Figure 5) FIGURE 5 Step 6.
- Page 5 All cables connected to the router Step 7. Mount the router onto the router mount plate. Match the holes on the router to the holes on the base plate. Fasten the router using the four 1/4-20, 1/4 inch screws provided in the kit. (Figure 7) FIGURE 7...
- Page 6 Router and Case connection Instructions: All connections diagram...
- Page 7 Step 1. There are two RJ-45 ports for G2 and L versions and one for the G1 version of the case. Choose which port you want to use for WAN and LAN connectors. Connect one end of the ethernet cords from the router to the RJ-45 ports on the case. (Figure 8) FIGURE 8 Step 2.
- Page 8 Router Power Options: PRO5GR2L2WG-G1 and PRO5GR2L2WG-G2 have the option of a battery. Parsec provides a battery tray for PowerAdd Pilot Pro 2 23000mAH Portable Battery Charger. For installing the battery follow the instructions below. Step 1. Insert the battery in the battery tray. (Figure 10) Step 2.
- Page 9 Step 6. Connect the USB port on the case to the battery using the USB cord. Step 7. Turn ON the power switch to turn the router on. (Figure 14) FIGURE 14 PRO5GR2L2WG-L and PRO5GR2L2WG-A come with an AC adapter with 16-inch extension cord. Parsec provides an AC adapter mounted on the case for L and A version.
-
Page 10: Antenna Operation
Antenna Operation: Step 1. Make sure all cables are properly connected. Check all of the connections and make sure there is no loose connections. Step 2. Before turning on the antenna, always snap the fan and vent caps open. (Figure 16) FIGURE 16 Step 3. - Page 11 Step 4. Connect a network cable between the ethernet ports on a computer and one of the ethernet ports on the antenna enclosure. Make sure you are connected to a LAN port and not a WAN port. Step 5. Bring up a web browser on the computer and type 192.168.0.1 into the address bar. You should see the Cradlepoint login. (Figure 17) Step 6.
- Page 12 Step 7. In the router, click on Status, Internet, and then Connections in the dropdown menu. You should see options related to SIM cards installed. Select the option with a cellular SIM. (Figure 19) FIGURE 19 Step 8. If all of the steps are completed, the antenna should be on and operating. Close the top cover plate using the thread forming screws provided in the kit.
