REPLACING THE NOMAD
FOR NOMAD
1
3
Make sure the Nomad
1.
Begin with the back of the Nomad
1
the rear panel.
2.
Use a Phillips Head screwdriver to unscrew and remove the eight (8) screws.
2
Then, remove the rear panel.
3.
Once the rear panel is removed, notice a black strap, which holds the Battery
3
Pack in place. There is one (1) screw on each side of the strap. Remove both
using the same Phillips Head screwdriver. This will then release the Battery
Pack strap.
4.
Pull the Battery Pack out of the Nomad
4
by unclipping the Connector.
FOR RE-INSTALLATION: Repeat steps 1– 4 in reverse order.
BATTERY PACK (P/N 600-200-400)
®
NOW, N32, AND N56
®
is turned OFF before starting.
®
|
APPROXIMATEL Y 4 MINS
2
4
facing you. Locate the eight (8) screws on
®
Body. Then, detach it from the light
®
CONNECTOR
