- Page 1 User Manual WKP-3603 LED PAR 36*3W UV This product manual contains important information about the safe installation and use of this product. Please read and follow these instruction carefully and keep this manual in a safe place for future reference.
-
Page 2: Safety Warning
Understanding of Product Safety Warning When unpacking and before disposing of the carton, check if there is any transportation damage before using the product. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. ... -
Page 3: Main Technical Parameters
Main Technical Parameters Power supply Rated Voltage: AC90~240V Rated Frequency: 50~60Hz ± 10% Rated Power: 108W LED Type: 36pcs ×3W UV Drive Current: 700mA LEDs: 395nm Life: About 50,000 hours Control Control Protocol: International standard DMX-512 signal ... -
Page 4: Product Features
Product Features Using the latest LED control technique of Company, newest intelligent LED Par light can realize intelligent operation and control through its special menu at the back. It’s more convenient and easy to operate. This product is designed for building large area spread light, large concerts, outdoor landscape lighting, wedding scene, small performances, slow club KTV and various performance occasion. - Page 5 DMX Connection Method If the lighting working on DMX mode it needs be connected to the DMX controller For example: if using DMX 8 channels mode, the first DMX address value must be 1st, next device should be plugs 8 (e.g., 1,9,17,25...). ...
-
Page 6: Operation Method
3 Operation Method panel functions introduction MENU：Menu button/return button, enter the menu selection interface or previous menu. ENTER：Confirmation button, used to confirm the selected function. UP/DOWN：Upward/downward select function or Parameter increment / decrement. Menu Overview - 5 -... - Page 7 Static Color Setting (STATIC) Find【STATIC】menu and press【ENTER】 to enter color static setting. Press【ENTER】button to select【UV】. Press【UP/DOWN】button to adjust parameters. Press【MENU】button to return to the menu, the selected parameters will be automatically saved. After setting lighting fixture's static color, restart the lighting fixture's power supply. The setting was preserved.
-
Page 8: Control Channel
DMX Channel Mode setting (PERS) Find【PERS】menu and press【ENTER】to enter DMX channel mode setting. Press【UP/DOWN】button to select【1CH, 2CH……】3 kinds DMX channel modes. Press【ENTER】to confirm or【MENU】to exit. The setting will be automatically saved. Function Settings (SET) Find【RESET】menu and press【ENTER】to restore the factory settings. Restore factory settings parameters: 1. -
Page 9: Product Maintenance
4.2----2CHs Mode: Channel DMX Data Control function Detail description Linear dimming from 0~100% 16 bit dimming Linear dimming from 0~100% 4.3----3CHs Mode: Channel DMX Data Control function Detail description Linear dimming from 0~100% NO FUNCTION STROBE Regular strobe Random strobe Linear dimming speed (DIM=OFF) Dimmer speed adjustment Non-linear dimming speed1 (DIM=1) - Page 10 Remark: This product warranty for one year. We provide pay-needed maintenance service after the warranty. But because of natural and man-made disasters or improper operation caused damage not under warranty range! SUPER-CAN INDUSTRY GROWING GROUP CO.,LTD. MADE IN CHINA - 9 -...
