RAINBOW MAXX
WARNING
• Luminaires must be installed by a qualified electrician in accordance with all national and local electrical and
construction codes and regulations. Please read through this document entirely before beginning the installation.
• Risk of electric shock- turn power off before inspection, installation or removal.
Electrical Requirements
• Suitable for wet locations.
• Follow all National Electric Codes (NEC) and local codes.
Notes
• If the external flexible cable or cord of this luminaire is damaged, it shall be replaced by a special cord or cord
exclusively available from the manufacturer or his service agent.
Customer Service
• For technical assistance please call 800-285-6780 x2 or email support@ggled.net
Supplied Materials
Rainbow Maxx Series Luminaire(s)
1
50' Leader Cable(s)
2
240W 24VDC LED Power Supply
3
Arch Mount Brackets & Hardware
4
STRONG.
INSTALLATION MANUAL PAGE 1
SIMPLE.
Rev Date 20 0421
COMPACT.
Advertisement
Table of Contents
Summary of Contents for G&G Rainbow Maxx Series
- Page 1 Customer Service • For technical assistance please call 800-285-6780 x2 or email support@ggled.net Supplied Materials Rainbow Maxx Series Luminaire(s) 50’ Leader Cable(s) 240W 24VDC LED Power Supply Arch Mount Brackets & Hardware Rev Date 20 0421 STRONG.
- Page 2 T 800.285.6780 E support@ggled.net www.ggled.net RAINBOW MAXX INSTALLATION MANUAL PAGE 2 Mounting • Mount the Maxx series luminaire using the supplied arch mounting brackets & hardware. • The brackets are universal (no left or right) and are designed to sit on top of the arch with the U-bolts around the bottom (see images below).
- Page 3 T 800.285.6780 E support@ggled.net www.ggled.net RAINBOW MAXX INSTALLATION MANUAL PAGE 3 Electrical Connection Diagrams • DO NOT plug LED fixture directly into AC voltage. • Fixtures require and are supplied with a 24VDC LED power supply. • LED power supply must be placed in a UL approved enclosure. Enclosure 120-277V Input...
- Page 4 T 800.285.6780 E support@ggled.net www.ggled.net RAINBOW MAXX INSTALLATION MANUAL PAGE 4 Controlling The Fixture Controlling the Rainbow Maxx is simple. There is a single control button on the end of the luminaire opposite the power input underneath a waterproof cap. The button has three functions and allows the user to change the mode, cycle through various effects and adjust the speed of the effect.
