  • Page 1 Multi Player Series DJ Controller Hardware Diagram...
  • Page 2 Using a DJ controller If you use a USB cable to connect a DJ Player and a DJ controller, you can use the DJ controller to control some of the performance functions of the DJ Player. Furthermore, one DJ controller can be used to control up to four players connected with PRO DJ LINK. * Only players that support connecting a DJ controller can be controlled.
  • Page 3 Switching the player to use Description of the screen Deck number of the DJ controller Player number Changing the player you wish to control 1 Connect players and a DJ controller using USB cables. 2 Press the [USB] button on the player connected to the DJ controller. The [CONTROLLER ASSIGN] screen is displayed.
  • Page 4 DDJ-SP1 Hardware Diagram Name Function (+SHIFT) DECK 3 Switch Player 1/3 DECK 4 Switch Player 2/4 SYNC SYNC MASTER (Press and hold) INSTANT DOUBLES SLIP SLIP QUANTIZE CENSOR SLIP REVERSE PARAM.1 [<] LOOP CUTTER PARAM.1 [>] LOOP DOUBLE AUTO LOOP...
  • Page 5 PAD 4 2 beats (FWD) PAD 5 4 beats (REV) PAD 6 4 beats (FWD) PAD 7 8 beats (REV) * PAD 8 8 beats (FWD) * * XDJ-1000MK2 is not supported. © 2016 Pioneer DJ Corporation. All rights reserved.
