GroupGets PureThermal 2 Manual

GroupGets PureThermal 2
The PureThermal 2 FLIR Lepton Smart I/O Module is a hackable thermal webcam
module for the FLIR Lepton Longwave Infrared (LWIR) camera core. It ships pre-
configured to operate as a plug-and-play UVC 1.0 USB thermal webcam that will
work with standard webcam apps such as VLC Media Player on PC, Linux, Mac,
and Android.
For developers, it's reference firmware and hardware schematic are open source
for customized applications. We have also created an open source software
application, GetThermal, to view Lepton data on x86 Linux and macOS platforms.
For computers using a Microsoft Windows OS you can use the
App on the Lepton Getting Started page under the Downloads section.
GetThermal as well as the FLIR Lepton User App with a PureThermal 2 (PT2) both
support the radiometric mode of Lepton 2.5 & 3.5. Stay up to date with
resources, video, and software for PT2 at its

FEATURES

• Get Thermal video over USB right out of the box using freeware apps like VLC on Mac, Linux,
Windows, or Android
• PT2 can do 9 Hz color video over usb using the USB UVC class
• STM32F412 ARM microprocessor. Execute on-board image processing without the need for an
external system
• Through-holes for GPIO and peripheral breakouts to easily attach other devices
• Open source reference firmware is on the GroupGets Github
• Device Firmware Upgrade (DFU) the STM32 ARM MCU over USB
• Debug via JTAG through a 6-Pin plug-of-Nails port using a Tag-Connect TC2030-IDC-NL, an
ARM20-CTX, & ST-Link V/2.
• Powered via USB
• UART, I2C, and GPIO Expansion via standard 0.1" holes
• Compatible with all current 2.x and 3.x Lepton cores
• Compact 30 x 18mm form-factor that can be embedded into other modules or inconspicuously
housed as a standalone web, research, or security camera

APPLICATIONS

• Thermal Imaging
• Non-contact temperature measurements
• Motion Sensing
• Night Vision
• Gesture Recognition
FLIR Lepton® Smart I/O Module
1
FLIR Lepton User
resource page.
GroupGets.com
