GMUSynth Arturia Minibrute Install Instructions

Installing your wood side panels on the Minibrute (MB) requires a
standard Phillips head screw driver. Also recommended is a soft towel
or foam sheet to protect the synthesizer during install.
As a general rule, sometimes getting the fit correct requires a few
adjustments. It is recommended that when installing screws or bolts,
give each screw a few turns just enough to seat the threads. Do not
tighten until all of the screws have been threaded.
1) Place your MB upside down on top of the towel or foam
sheet.
2) Remove and save the 16 screws circled in the photo
above.
3) Carefully slide out the front keyrest:
4) Flip the MB over so the keys are facing away from you:
10/20/2016 – Rev 2.1
5) Slowly lift the sides and front panel up and away from the
keybed. Note the ribbon cables will remain attached.
6) Slide the towel or foam sheet up under the front panel of
the synth and lay the panel flat so that it is upside down
and pointing towards you:
7) Remove and save the 8 self-tapping screws attaching the
side panels circled in the photo below:
