HIGH WALKERS

DECORATORS STILTS

Adjustable Working Height 450 - 750mm (18 - 30in)

Load Bearing 114Kg (250lbs)

INTRODUCTION

The correct assembly of these stilts is essential, for both

your personal safety and to guarantee product satisfaction.

Please take time to read and understand these instructions

fully before assembling your stilts. (Reference page 2).

Be sure you fully understand how the High Walkers stilts

should be ﬁ tted and the correct sequence for ﬁ tting and

removing of your stilts after use. (Reference page 3).

Always make sure that all bolts and ﬁ ttings are tight and

secure, before you attempt to walk around on your stilts.

Please take 10 to 15 minutes to practice using and

become comfortable walking in the High Walkers stilts. It is

really very easy, but a little practice is essential before you

start your work, this should avoid any possible accidents.

Be sure to clean your High Walker stilts after use and

check that all bolts and ﬁ tting remain tight. If you look after

the High Walkers stilts, they will look after you.

On page ﬁ ve we provide you with some useful tips on

using your High Walker stilts.

On page seven the Do's and Don'ts of working on High

Walker stilts. These will to help you prevent unnecessary

accidents

Table of Contents

Need help?

Do you have a question about the HIGH WALKERS and is the answer not in the manual?

Questions and answers

Summary of Contents for Faithfull HIGH WALKERS

Page 1 Please take time to read and understand these instructions fully before assembling your stilts. (Reference page 2). Be sure you fully understand how the High Walkers stilts should be ﬁ tted and the correct sequence for ﬁ tting and removing of your stilts after use. (Reference page 3).
Page 2 ASSEMBLY OF HIGH WALKERS STILTS 1) Loosen the Strut Tube Clamp (A) on the side of each stilt. Insert the tubes into and through the lower tube clamps. Leave the tube clamps loose, for now. 1) Strut Tube Clamp 2) Attach the Lower Strut Tubes (B) to the rear outer leg bracket with the attached 1/4”...
Page 3 FITTING YOUR HIGH WALKERS STILTS Strap Tightening Sequence IMPORTANT - • When mounting your stilts, always attach the leg straps, before ﬁ tting the foot straps. • When dismounting always unbuckle the leg straps, after unbuckling the foot straps. Select a clear & level area away from doors, ﬂ oor vents, stairwells or windows.
Page 4 Height Adjustment Undo the two Wing Nuts (F) and then slide out the two height adjusting bolts on each stilt, evenly raise or lower the stilt legs to the desired height, then simply replace the bolts and reﬁ t the wing nuts.
Page 5 WARNING It is important that you read and observe the following instructions. We cannot be held responsible for any accident resulting from improper or irresponsible use of this product. It is essential that these stilts are inspected before use and maintained in accordance with these instuctions. WALKlNG PRECAUTIONS IMPORTANT: Always take short, deliberate, distinct steps and walk with your stilts well apart.
Page 6 Adjustment for Walking If you have a tendency to lean forward or backward while walking, you should adjust the action springs. Make the following adjustments after removing your stilts. To correct for leaning backward while walking, tighten the lower spring adjuster (I). To correct for leaning forward while walking, tighten the upper spring adjuster (J).
Page 7 DO’S AND DON’TS • Do inspect Stilts thoroughly before • Don’t wear stilts without having the use, making sure that the structure proper instruction on the use of them. is free of any sign of damage, that • Don’t wear stilts that are there is no excessive wear at the uncomfortable or incorrectly adjusted.
Page 8 The Faithfull Tools Catalogue features approximately 2,600 products. Ask your local Faithfull Tools stockist for a copy, or contact the address below. FAITHFULL TOOLS Long Reach, Galleon Boulevard, Crossways Business Park, Dartford, Kent, DA2 6QE, United Kingdom E-mail: enquiries@faithfulltools.com www.faithfulltools.com...
