- Page 1 T.P.I. Top Performer Immersion Installation Manual...
- Page 2 T.P.I. (Top Performer Immersion) Installation Manual Installation Attaching TPI to Top Performer tank: Place hole in back of TPI over immersion well. (See Diagram 1) TPI should fit flush against the tank without immersion well protruding beyond bottom of TPI case.
- Page 3 Adjustments Adjusting the Temperature Setting: The temperature setting slide is on the right-hand side of the TPI. (See Diagram 3) The TPI comes with a factory set temperature setting of 120F. To adjust the temperature setting, slide the lever to the desired setting, using the indicator scale. TPI has a normal temperature setting range from 100F to 140F.
- Page 4 Diagram 1 Screw C Screw B Complete Installation Screw B Screw C Diagram 2...
- Page 5 Diagram 3 Diagram 4 Inserting the probe wires 5.A – Position tool (such as screwdriver) on top of white buttons. 5.B – Push down on white buttons and push wires down into black holes in top of connector. (This can also be done one side at a time) 5.C –...
