Quadro Qtv Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation Guide
Rev. OCT 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Qtv and is the answer not in the manual?

Questions and answers

Related Manuals for Quadro Qtv

Summary of Contents for Quadro Qtv

  • Page 1 Installation Guide Rev. OCT 2020...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WHAT’S IN THE BOX..................SET-TOP BOX AT A GLANCE................REMOTE CONTROL FUNCTIONALITY............SELF-INSTALL CONNECTION GUIDELINES..........INITIAL BOX POWER ON.................. NETWORK SETUP..................... KURV 2.0 VOICE REMOTE................. 20 SERVICE VALIDATION..................TROUBLESHOOTING..................APPENDIX A – TV CODES FOR REMOTE PAIRING........APPENDIX B –...

  • Page 3: What's In The Box

    WHAT’S IN THE BOX? Qtv STB Set-Top Box Power Adapter (STB) HDMI Cable KURV Remote RCA Analog KURV 2.0 Voice Composite Remote Control Breakout Cable Shown (Optional) AA Batteries...

  • Page 4: Set-Top Box At A Glance

    Top View Front View Status Indicator LED: Indicates power status of STB (Red = Off, Green = On). Infrared (IR) Sensor: Used to communicate with the Power Button: KURV Remote Control. Used to power the Qtv STB On or Off.
  • Page 5 Qtv 2020 | Installation Guide Rear View Side View RJ45: USB: 10/100 Ethernet port used to This port has an output connect to a home router. power capability of 5V DC @ 1 amp. HDMI: Digital A/V output, used to connect to a TV via HDMI cable.

  • Page 6: Remote Control Functionality

    Qtv 2020 | Installation Guide REMOTE CONTROL FUNCTIONALITY Backlighting Hot Keys The remote control is a motion detecting device and will backlight when the remote is picked up or moved. Backlighting will remain on for 3 seconds. KURV 2.0 Voice...
  • Page 7 Qtv 2020 | Installation Guide Hot Keys The following Hot Keys are dedicated short cuts to return the user to the video service regardless of the content or App being viewed. MENU: Displays the Main Menu. LAST: Displays the last 15 items that have been watched.
  • Page 8 Qtv 2020 | Installation Guide Button Functionality TV POWER: Powers on or off TV if remote is programmed with a TV infrared code. TV INPUT: Changes video input on TV if remote is programmed with a TV infrared code. POWER: Switches STB power on or into standby or off mode.
  • Page 9 Qtv 2020 | Installation Guide GOOGLE HOME: Launches AndroidTV main menu including access to Apps. LAST: Displays the last 15 items that have been watched. BACK / EXIT: Returns to previous menu or state within current App. From live video, this key opens the Main Menu.

  • Page 10: Self-Install Connection Guidelines

    Qtv 2020 | Installation Guide SELF-INSTALL CONNECTION GUIDELINES HDMI Cable Connection What You Need • An HD or Ultra High Definition (UHD) TV that can support 720p, 1080p or 4K UHD. • A Broadband Internet connection that supports a wired or WiFi wireless home network (802.11 g, n, or ac).
  • Page 11 Qtv 2020 | Installation Guide Analog Composite Breakout Cable Connection Connect the analog composite cable as shown below. This connection scheme should only be used if the TV does not have a working HDMI port. Video Audio Output to TV...
  • Page 12 Qtv 2020 | Installation Guide Network Connection You must connect your new STB to an internet connection through either a WiFi wireless connection or a wired Ethernet connection. Wired Network Connection If your home router is near the STB location, a CAT-5/5e/6 Ethernet cable may be used for internet connectivity.
  • Page 13 Qtv 2020 | Installation Guide WiFi Network Connection Connect Automatically Using WPS Navigate to the Android main menu by pressing the following key sequences: Home — > Settings — > Network — > WiFi — > Select to enable. Once WiFi has been enabled, using the remote scroll down and select “Connect via WPS”.

  • Page 14: Initial Box Power On

    Qtv 2020 | Installation Guide INITIAL BOX POWER ON The following screens describe the remote key sequences required to setup the KSTB2020. When powered up and fully booted, the box will start on this screen. The three digit number will be unique and change each time the remote is paired.
  • Page 15 Qtv 2020 | Installation Guide Select Skip and press OK to continue. The following screen will be displayed. If the end user wishes to login with their Google ID they may do so at this point. If not, select Skip and press OK to continue.
  • Page 16 Qtv 2020 | Installation Guide Once logged in, the following Terms of Service screen will be displayed. Select Accept and press OK to continue. Select Yes on the Location screen and press OK to continue.
  • Page 17 Qtv 2020 | Installation Guide On the Help Improve screen, select Yes and press OK to continue. On the Choose a Name screen, select the appropriate name for the unit and press OK to continue.
  • Page 18 Qtv 2020 | Installation Guide The following Get Started screen will display the login where your Cable Provider App will be located. This app cannot be unselected. Select Continue and press OK to get to the next screen. On the Welcome screen, arrow right five times to get to the next screen.
  • Page 19 Qtv 2020 | Installation Guide Select Done and press OK to continue. When it is finished processing, the Login screen will be displayed.
  • Page 20 Qtv 2020 | Installation Guide An example login screen is shown. This will be unique for each subscriber. Credentials may be entered using the remote or via a USB keyboard (recommended). Once logged in, the following screen will be displayed. Select “DETAILS” to be prompted for Wi-Fi network section and sign in.

  • Page 21: Network Setup

    If the home router is near the Set Top Box location, a CAT-5/5e/6 Ethernet cable may be used for Internet connectivity. Plug one end of the CAT-5/5e/6 cable into the Qtv STB RJ-45 port. Plug the other end of the cable into any LAN port of the home router.

  • Page 22: Kurv 2.0 Voice Remote

    Qtv 2020 | Installation Guide KURV 2.0 VOICE REMOTE Remote Pairing Operation STB / Remote IR – RF Mode Conversion For customers who wish to place the STB in a non-line of sight position (with respect to the remote control) the remote must operate in RF mode. As the remote operates...
  • Page 23 Qtv 2020 | Installation Guide TV / Remote Programming By default, the remote controls the Volume on TV, and Power on the STB. To program the remote to the TV, such that remote Master Power key presses adjust Power and Volume on the TV by Infrared commands directly follow the instructions below: •...
  • Page 24 Qtv 2020 | Installation Guide TV Code Auto-Search Method If a code is not in Appendix A or B, use this method to find control programming: • Press and hold the key for 3 seconds, until the LED turns green.
  • Page 25 Qtv 2020 | Installation Guide Remote Behavior If the remote has been programmed to the TV and Audio Systems as described on the previous page, the remote’s TV power button ( ) will control the TV power only. This will not affect the powered state of the STB. The “all devices” power button ) will control the TV power as well as the STB and audio system power states if remote has been fully programmed with TV and Audio system.

  • Page 26: Service Validation

    Qtv 2020 | Installation Guide SERVICE VALIDATION RCU/STB Operation Once STB has been installed and credentials have been entered, the user should confirm that remote works as expected with STB. The user should check the following buttons for correct operation.

  • Page 27: Troubleshooting

    Qtv 2020 | Installation Guide TROUBLESHOOTING Observation Things to Check Remediation Video/audio WiFi signal strength in STB Relocate router and STB closer quality is poor on Network connection menu. in proximity with each other STB or network if possible, such that signal...

  • Page 28: Appendix A - Tv Codes For Remote Pairing

    Qtv 2020 | Installation Guide APPENDIX A TV Codes for Remote Pairing - Top 10 US TV Brands - TV Maker Code / Brand Number SAMSUNG 10305 10265 10001 10012 10051 10092 10011 10118 10124 10132 10145 10176 10221 10306...
  • Page 29 Qtv 2020 | Installation Guide TV Maker Code / Brand Number 10088 10363 10367 10001 10011 10103 10330 10439 AOMNI 10354 APEX 10302 10303 10282 APEX DIGITAL 10303 10373 10384 ARCHER 10388 ASTAR 10390 AUDIOVOX 10345 10319 10380 10374 10388...
  • Page 30 Qtv 2020 | Installation Guide TV Maker Code / Brand Number COMPAQ 10414 CONCERTO 10011 10543 CONTEC 10041 10045 10051 10052 10380 CORENA SYSTEM 10301 CORONADO 10132 CRAIG 10045 10055 10157 10049 10159 10380 10258 CROSLEY 10415 CROWN 10045 10132...
  • Page 31 Qtv 2020 | Installation Guide TV Maker Code / Brand Number ELEMENT 10335 10259 10273 10283 EMERSON 10001 10012 10013 10029 10033 10045 10048 10049 10051 10052 10091 10011 10132 10137 10139 10141 10157 10140 10184 10185 10186 10187 10188...
  • Page 32 Qtv 2020 | Installation Guide TV Maker Code / Brand Number HISENSE 10266 10011 10279 10280 10373 10459 10462 HITACHI 10017 10011 10015 10016 10001 10018 10029 10043 10072 10132 10144 10147 10203 10204 10206 10207 10208 10210 10211 10368...
  • Page 33 Qtv 2020 | Installation Guide TV Maker Code / Brand Number LUXMAN 10011 10543 10013 10021 10053 10034 10145 10148 10413 10415 10393 10303 10315 MAGNASONIC 10001 10011 10348 MAGNAVOX 10001 10003 10011 10060 10061 10062 10064 10065 10066 10086...
  • Page 34 Qtv 2020 | Installation Guide TV Maker Code / Brand Number NORWOOD MICRO 10362 10498 10374 NUVISION 10502 OLEVIA 10011 10342 10535 10315 OLYMPUS 10503 ONWA 10045 10380 OPTONICA 10025 10034 10235 OPTIMUS 10485 10393 10504 10505 OPTOMA 10506 10448...
  • Page 35 Qtv 2020 | Installation Guide TV Maker Code / Brand Number SAMSUNG 10305 10265 10001 10012 10051 10092 10011 10118 10124 10132 10145 10176 10221 10306 10542 10315 10439 10479 10408 10543 SANSUI 10431 10452 10516 10517 SANYO 10013 10026...
  • Page 36 Qtv 2020 | Installation Guide TV Maker Code / Brand Number SUPERSCAN 10436 10530 SUPRE MACY 10002 10372 SUPREME 10409 10373 10479 10301 10532 10533 SYLVANIA 10001 10003 10008 10011 10060 10061 10064 10118 10126 10065 10145 10148 10155 10311...
  • Page 37 Qtv 2020 | Installation Guide TV Maker Code / Brand Number VIDIKRON 10255 10415 VIDTECH 10011 10315 VIEWSONIC 10363 10088 10330 10331 10349 10486 10530 10503 VIKING 10372 VIORE 10316 VISART 10551 VITO 10360 VIZIO 10011 10315 10351 10530 WARDS...

  • Page 38: Appendix B - Audio System Codes For Remote Pairing

    Qtv 2020 | Installation Guide APPENDIX B Audio System Codes for Remote Pairing Audio Maker Code / Brand Number ADCOM 20088 20098 20218 20147 20233 AIWA 20142 20182 20025 20141 20022 20110 AKAI 20128 ANAM 20026 20188 20189 ANTHEM 20004 B&K...
  • Page 39 Qtv 2020 | Installation Guide Audio Maker Code / Brand Number LG (GOLDSTAR) 20069 20077 20018 20192 LOTTE 20191 20193 LUXMAM 20042 20084 MAGNAVOX 20013 20092 MARANTZ 20013 20093 20047 20072 20063 20203 20221 20250 MAXELL 20078 MCINTOSH 20160 20016...
  • Page 40 Qtv 2020 | Installation Guide Audio Maker Code / Brand Number SONY 20008 20176 20005 20025 20107 20145 20090 20170 20195 20209 20216 20305 SOUNDESIGN 20043 20075 TAEKWANG 20128 20186 20195 TEAC 20066 20067 20026 20190 TECHNICS 20126 20094 20109...
  • Page 41 Qtv 2020 | Installation Guide Notes...
