Jasco Energizer 44577 Quick Start Manual

Wireless Remote Control
10" Light Bar
BATTERY INSTALLATION:
Open the battery compartment on the back of the light by
sliding the back cover in the direction of the arrow. Insert
6 AA batteries, noting polarity. Replace cover by sliding in
opposite direction.
REMOTE:
NOTE: Remove battery isolation tab for first time use.
To replace exhausted battery, unscrew the battery door on
the back of the remote. Insert 2 CR2032 batteries, noting
polarity. Replace the cover and screw back in.
IMPORTANT: Different types of batteries or new and used batteries
should not be mixed. Exhausted batteries should be removed from
the fixture and disposed of properly.
Fig. 1
1
REMOTE OPERATION:
1. Switch to "RF" for remote control functions (See Fig. 1).
NOTE: To control multiple light bars, all light bars must be in
"RF" position.
2. On the remote, press the "I" button to turn the lights on.
3. Press the "O" button to turn the lights off.
MANUAL OPERATION:
1. Move switch to ON position to turn the light on.
2. Move switch to OFF position to turn the light off.
Fig. 2
2
3
MOUNTING INSTRUCTIONS:
NOTE: Mounting template is provided under the product.
To mount light: Remove battery cover and mount in
desired location using screws and the included mounting
template or double-sided tape. Reattach light to mounted
battery cover. Anchors are included for installing screws in
the sheetrock.
NOTE: Battery door may remain mounted when changing batteries.
Functional range may be adversely affected by one or more of the following
factors: weather, radio frequency interference, low battery in remote or
obstructions between the transmitter and receiver.
FCC NOTE: The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications could
void the user's authority to operate the equipment.
FCC STATEMENT: This device complies with Part 15 of the FCC rules. Operation
is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. This device must not be co-located
or operating in conjunction with any other antenna or transmitter. This equipment
has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
MADE IN CHINA/HECHO EN CHINA
©2018 Energizer. Energizer and certain graphic designs are
trademarks of Energizer Brands, LLC and related subsidiaries and
are used under license by Jasco Products Company, LLC. All other
brand names are trademarks of their respective owners. Neither Jasco
Products Company, LLC nor Energizer Brands, LLC is affiliated with the
respective owners of their trademarks.
Contact our U.S.-based Consumer Care at 1-800-654-8483 between
7AM-8PM CST.
90-day warranty. Visit www.byjasco.com for warranty details.
