Summary of Contents for PulseAudio PA-EXTDA
- Page 1 DIGITAL-ANALOG AUDIO EXTENDER PART NUMBER PA-EXTDA DIGITAL AND ANALOG AUDIO EXTENSION OVER A SINGLE CAT5E/6 CABLE pulseaudio1.com | vanco1.com | 800.626.6445...
-
Page 2: Dear Customer
DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. THIS PRODUCT IS 100% INSPECTED AND TESTED IN THE UNITED STATES TO VERIFY PERFORMANCE PARAMETERS. -
Page 3: Package Contents
FEATURES The Pulse Audio PA-EXTDA is a digital-analog audio extender over a single Cat5e/6. It is designed to extend the analog audio signals up to 170m, or digital audio signal up to 290m via toslink or coax audio input. Selecting the audio source is quick and easy with the use of a toggle switch. -
Page 4: Panel Descriptions
PANEL DESCRIPTIONS TRANSMITTER TOSLINK digital audio input port, connects to audio source COAX digital audio input port, connects to audio source Stereo audio input port, connects to audio source Toggle switch for selecting audio source input Micro USB port for updating firmware RJ45 port, connects to the “TP IN”... -
Page 5: Connect And Operate
CONNECT AND OPERATE Connect an audio source to any of the inputs on the Transmitter unit 2. Set the switch on the transmitter to the corresponding input that will be transmitting the audio (1: Toslink, 2: RCA-Coax, 3: 1/8” Stereo Jack) 3. -
Page 6: Specifications
Dimension ............88mm x 80mm x 21.5mm SAFETY AND NOTICE The PA-EXTDA has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipment, the PA-EXTDA should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 7: Technical Support
TECHNICAL SUPPORT In case of problems, please contact Vanco Technical Support by dialing 1-800-626-6445. You can also email technical support issues to techsupport@ vanco1.com. When calling, please have the Model Number, Serial Number (affixed to the bottom of the unit) and Invoice available for reference during the call. - Page 8 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 | fax: 630.879.9189 visit: www.vanco1.com Introducing a new brand from Learn more at pulseaudio1.com...
