- Page 1 “There Is No Substitute for Experience” DOW-KEY MICROWAVE MS, MP, CB Matrix Series MP-2U18S-30-GPIB CAN BUS RF SWITCH MATRIX Operator’s Manual Rev 2 THE RF/MICROWAVE SWITCHING TECHNOLOGY SOLUTION COMPANY...
- Page 2 Copyright © Dow-Key Microwave Corporation 2010, all rights reserved. Information in this publication supersedes that in all previously published material. Specifications and price change privileges reserved. Printed in the U.S.A. Dow-Key is a registered trademark of Dow-Key Microwave Corp. Document Number: 49101-264 Revision 2 4822 McGrath Street, Ventura, CA 93003 Tel: (805) 650-0260 Fax: (805) 650-1734...
- Page 3 WARRANTY Dow-Key Microwave Corporation warrants this product to be free from defects in material and workmanship for a period of 1 year from date of shipment. This warranty does not apply to defects resulting from product tampering or modification without Dow- Key’s express written consent.
- Page 4 Manual Revision History The revision history shown below lists all revisions and addendums created for this manual. The revision level increases numerically as the manual undergoes subsequent updates. Addendums are released between revisions and contain important change information that the user should incorporate immediately into the manual.
-
Page 5: Table Of Contents
Table of Contents 1 General Information ...................... 1 Introduction ......................1 MS Matrices ....................... 2 MP Matrices ....................... 3 CB Matrices ......................4 Technical Specifications ..................5 Safety Precaution ....................6 ... - Page 6 Condition Register .................... 34 Event Register ....................34 Enable Register ....................34 The Status Byte Register ................. 35 The Standard Event Register ................36 IEEE 488.2 Common Commands ..............37 ...
-
Page 7: General Information
General Information Introduction Dow-Key Microwave Switch Matrix series electromechanical RF matrices. They come equipped with a GPIB (IEEE 488) port which allows the user to easily access the matrix remotely. Other interfaces included are an RS-232 port, an USB (used as virtual serial port) and a CAN Bus port. -
Page 8: Ms Matrices
General Information MS Matrices MS-Series stands for Multiple Switches. It is a matrix where a number of independent switches are populated on the rear panel or inside the matrix enclosure. From an RF point of view the switches are not interconnected and all switch’s RF ports are available to the user on the rear panel of the matrix. -
Page 9: Mp Matrices
General Information 1.3 MP Matrices MP-Series stands for Multiplexer. It is a matrix with one input connecting to many outputs (only one at the time) or, since the RF switches are bi-directional, many inputs connected to one output (only one at the time). The switches are populated either on the rear panel or inside the matrix chassis. -
Page 10: Cb Matrices
General Information 1.4 CB Matrices CB-Series stands for Crossbar. It is a matrix with several inputs connecting to several outputs. Only one input can be connected to one output at any given time. The switches are populated inside the matrix chassis and are interconnected so that any input can connect to any output and vice versa. -
Page 11: Technical Specifications
General Information 1.5 Technical Specifications Refer to appendix A... -
Page 12: Safety Precaution
General Information Safety Precaution Safety precautions should be observed before using this product and any associated instrumentation. This product is intended for use by qualified personnel who recognize the safety precautions required to avoid possible injury. Inspection The Matrices were carefully inspected, both electrically and mechanically before shipment. -
Page 13: System Layout
System Layout Front Panel Layout Note: The matrices shown below are with the LCD on the front panel and rear mounted switches. Matrices with front mounted switches have same dimensions regardless of switch location. See also Appendix A and B. Figure 2-1 shows the 2U, 3U and 4U Model general layout, which includes: •... -
Page 14: Rear Panel Layout For 2U Models
System Layout Rear Panel Layout for 2U models Figure 2-2 shows the general layout of the rear panel of a variety of 2U models. All models have common parts which include: • Power Entry Module with built in Fuse • Chassis Ground Post •... -
Page 15: Rear Panel Layout For 3U Models
System Layout Rear Panel Layout for 3U models Figure 2-3 shows the general layout of the rear panel of a variety of 3U models. All models have common parts which include: • Power Entry Module with built in Fuse • Chassis Ground Post •... - Page 16 System Layout 3U MS series (with external switches) 3U MS series (with internal switches) or MP series or CB series 3U MS series combined with MP series or CB series GND stud Figure 2-3, Various 3U Models Rear Panel Layout...
-
Page 17: Rear Panel Layout For 4U Models
System Layout Rear Panel Layout for 4U models Figure 2-4 shows the general layout of the rear panel of a variety of 4U models. All models have common parts which include: • Power Entry Module with built in Fuse • Chassis Ground Post •... - Page 18 System Layout 4U MS series (with external switches) 4U MS series (with internal switches) or MP series or CB series 4U MS series combined with MP series or CB series GND stud Figure 2-4, Various 4U Models Rear Panel Layout...
-
Page 19: Top View Layout
System Layout Top View Layout Figure 2-5 shows the top view layout of all models. Note: The dimension indicated on the drawing is for 3U and 4U models. For 2 U models the depth dimension is 15.625” D (without handles) Figure 2-5, Top View of 2U, 3U and 4U Models... -
Page 20: Rf Configuration
System Layout RF configuration Refer to appendix B. -
Page 21: Connections
Connections Power Connection 3.1.1 Line Voltage The matrix operates from a line voltage in the range of 110V to 240V at a frequency of 50 or 60Hz. Line voltage selection is automatic. CAUTION: Operating the unit on an incorrect line voltage may cause damage, possibly voiding the warranty. -
Page 22: Ground Connection
Connections Insert small bladed screwdriver to release the fuse. Figure 3-1, Power Entry Module Line Fuse Rating Manufacturer Manufacturer Part No. Voltage 110-240V 1A, slow blow, 250Vac, ¼” x 1-1/4” Bel Fuse Inc. 3SB 1-R Table 3-1, AC Line Fuse Information Ground Connection The rear panel GND ground screw (refer figures 2-2, 2-3 and 2-4) should be connected to safety earth ground using #18 AWG or larger wire. -
Page 23: Rs232 Connection
Connections RS232 Connection The switch matrix may be operated over this connection (See Section 6 for a description of the commands). The RS232 connection is configured with these default settings: 9600 Baud, 8 bit data, no parity, 1 stop bit. The baud rate can be changed thru the touch screen LCD to: 1200, 2400, 4800, 9600, 19200, 38400, 57600,115200 bits/sec Figure 3-2 and Table 3-2 show the pin numbers and functions for the RS232... -
Page 24: Can Bus Connection
Connections CAN Bus Connection This connection allows the internal matrix controller to be easily interfaced to another Dow-Key Microwave Switch Matrix, using a one-to-one (straight through) cable. This allows a master matrix to control an extension matrix. However, the extension matrix being interfaced must not have any internal, intelligent controller;... -
Page 25: Gpib Control Connection
Connections GPIB Control Connection On the rear panel of the matrix is a GPIB (IEEE-488) control port which gets connected to the GPIB port of a computer (controller) using a shielded IEEE- 488 interface cable with metric mounting screws. Figure 3-4 shows the connector configuration and Table 3-4 shows the signal assignments. -
Page 26: Interface Signals
Connections 3.5.2 Interface Signals The GPIB (IEEE-488) interface system consists of 16 signal lines and 8 ground lines. The 16 signal lines are divided into 3 groups (8 data lines, 3 handshake lines, and 5 interface management lines). See table 3-4 for the signal assignments. -
Page 27: Handshake Lines
Connections 3.5.4 Handshake Lines The three handshake lines (NRFD, NDAC, DAV) control the transfer of message bytes among the devices and form the method for acknowledging the transfer of data. This handshaking process guarantees that the bytes on the data lines are sent and received without any transmission errors and is one of the unique features of the IEEE-488 bus. -
Page 28: Usb Port
Connections The REN (Remote Enable) signal is asserted only by the System Controller. Its assertion does not place devices into remote control mode; REN only enables a device to go into remote mode when addressed to listen. When in remote mode, a device should ignore its local front panel controls. -
Page 29: Configuring The Matrix For Operation
Configuring the Matrix for Operation Matrix Configuration The ‘brain’ inside Dow-Key Matrices, referred to as the “Matrix Controller”, has been designed to be as generic as possible in regards to how many switches of what positions it may control. Therefore, the matrix must first be informed as to the set of switches it is able to control before it can operate successfully, and this information must be updated as switches are added and deleted to the matrix or connected to the CAN bus port on the rear of the matrix (see section... -
Page 30: Adding And Deleting Switches
Configuring the Matrix Adding and Deleting Switches The following rules apply when adding a switch to the Matrix Configuration (the desired ID to add is referred to as the “target ID”): The desired switch to ADD must be connected to the matrix before ‐... - Page 31 Configuring the Matrix Example procedure: Before adding it to the Configuration you need to find the switch’s ID. To do this select Main Menu>System Settings>Find Switch ID and then follow the instructions in Section 5.2.3 Find Switch ID. If you find the switch you wish to add: Press the BACK key until you see the Main Menu screen.
-
Page 32: Manual (Local) Operation
Manual (LOCAL) Operation The Touch Screen Interface Power On: Position the rocker switch on the rear panel of the Matrix to the ON position (Figures 2- 2, 2-3 and 2-4) to turn on the matrix. ! Note: The booting sequence will last up to 1 minute. The LCD can appear blank during this time. - Page 33 Manual (LOCAL) Operation The figure above shows the matrix LCD touch screen (sometimes referred to as the “User Interface”, or “UI”) at the main menu screen. Most buttons have a gray background, while indicators will be either green or red. All screens, with exception of the ‘Main Menu’...
-
Page 34: Main Menu
Manual (LOCAL) Operation Main Menu 5.2.1 Switching Operations Switch Operations Menu Set Switch Positions View the currently set position and change the position of a switch who’s ID has been configured to the matrix. Use the arrows to change switch and position numbers. Refer to Appendix B to set RF switches in different positions. - Page 35 Manual (LOCAL) Operation Recall Positions Recall from non-volatile memory the state of the positions of all switch ID’s configured to the matrix, saved as 1 through 30, and set the positions of those switches. Clear Positions Cause all switches configured to the matrix to assume their default position.
-
Page 36: Error Operations
Manual (LOCAL) Operation 5.2.2 Error Operations View the contents of the Error Log (see Section 7.5.1). Each entry is displayed with the oldest being first (First In First Out), showing the Error Record Number (its place in the Error Log), an associated Error Code, an associated Error Data, and a text explanation of the Error. -
Page 37: System Settings
Manual (LOCAL) Operation 5.2.3 System Settings System Settings Menu ! Important Note: The matrix controller is designed to offer the maximum expandability and flexibility possible and therefore has features common to other Dow-Key matrix models. The here described ‘Add’, ‘Delete’ and ‘Find Switch ID’ features are some of those that, although available and fully functioning, should only be used if needed and appropriate. - Page 38 Manual (LOCAL) Operation 4. NOTE: this operation “puts the matrix’s switches to sleep” thereby rendering the matrix inoperable during the process. ENTER or CLEAR or rebooting returns the matrix to normal. Temperatures View current values of a maximum of 4 temperature sensors, and set thresholds at which an Over Temperature alarm should occur.
-
Page 39: Ethernet Options
Manual (LOCAL) Operation 5.2.4 Ethernet Options Ethernet Menu Not applicable to GPIB (IEEE-488) models. This button is not operational. 5.2.5 LCD Options This LCD has no adjustable parameters. 5.2.6 Set RS232 Baud Rate View and select the Serial Port’s Baud rate from a set of preselected values from 1200 to 115,200 b/s (see Section 3.3). -
Page 40: Ieee 488.2 Register Model
IEEE 488.2 Register model Introduction to IEEE 488.2 The topics discussed in sections 4.2 to 4.3 are for the most part transparent to the user during normal operation of the matrix. These sections are here mainly for informational purpose. These sections describe a minimal register model that is required to be able to perform a safe handshaking between the controller and the matrix. -
Page 41: The Status Byte Register
IEEE 488.2 Register Model The Status Byte Register The Status Byte register reports conditions from the other registers. Data in the instruments output buffer is immediately reported on the “Message Available” bit (bit 4). Clearing an event register from one of the other registers will clear the corresponding bits in the Status Byte condition register. -
Page 42: The Standard Event Register
IEEE 488.2 Register Model The Standard Event Register The Standard Event Register reports different types of events that may occur in the instrument. Any or all of these conditions can be reported to the Standard Event summary bit through the enable register. To set the enable register mask, you must write a decimal value to the register using the *ESE command. -
Page 43: Ieee 488.2 Common Commands
IEEE 488.2 Register Model IEEE 488.2 Common Commands This matrix implements common commands that the IEEE-488.2 standard defines. The following contains a list of a subset of these commands. For more details refer to the related section. Table 6-3 Common Commands Mnemonic Name Section... -
Page 44: Remote Operation
Remote Operation Introduction to SCPI SCPI is a command structure that is based on the IEEE-488.2 specification which Dow-key has adapted to work with GPIB, Ethernet, RS-232 and USB controls. The matrix has internal software loaded that uses SCPI command structure. -
Page 45: Command Separators And Conventions
Remote Operation Command Separators and conventions • A colon (:) is used to separate a command keyword from a lower level keyword. • A blank space is used to separate a parameter from a command keyword. • A comma (,) is used if a command requires more than one parameter. •... - Page 46 • For GPIB communication no ASCII termination is required, but the End Or Identify (EOI) line shall be asserted at the end of each command.
-
Page 47: Common Commands
Remote Operation Common Commands The following contains the IEEE 488.2 common commands of SCPI that the GPIB controller is compatible with. The possible error codes assume that the correct syntax is used and, in case of a multiple command string the string is not too long. If these conditions are not met, any given command can generate these error codes: 3, 4, 30 7.4.1... -
Page 48: Ese
Remote Operation 7.4.3 *ESE? Syntax *ESE? Description This query allows the user to determine the current contents of Standard Event Status enable register. The value returned corresponds to the binary-weighted sum of all bits enabled by the *ESE command. Note: This command can NOT be concatenated with other commands. It must be issued as a single command. -
Page 49: Idn
Remote Operation 7.4.5 *IDN? Syntax *IDN? Result A string is returned which consists of the following parts: Model Matrix model number Model Possible error codes None Example “*IDN?” Result “MP-2U18S-30-GPIB” 7.4.6 *OPC Syntax *OPC Description This command causes the device to set the Operation Complete bit in the Standard Event Register when all pending operations have been finished. -
Page 50: Opc
Remote Operation 7.4.7 *OPC? Syntax *OPC? Description This query returns an ASCII character “1” when all pending operations have been finished. Result ASCII character “1”. Possible error codes None Example 1 *OPC? Result “1” Example 2 :SWIT1 4; SWIT2 4; *OPC? Result “0”... -
Page 51: Rst
Remote Operation 7.4.8 *RST Syntax *RST Description This command performs a device reset. This will set the instrument so that all switches are in the default state. For SPnT switches the default state is: all RF ports are open (position 0). For a transfer switch the default state is: position 1 is closed. -
Page 52: Sre
Remote Operation 7.4.10 *SRE Syntax *SRE <enable_value> Parameters Enable_value Value that corresponds to the binary-weighted sum of the bits you wish to enable in the register. Description Enable bits in the Status Byte enable register. To enable bits in the Status Byte enable register, you must write a decimal value that corresponds to the binary-weighted sum of the bits you wish to enable in the register. -
Page 53: System Commands
Remote Operation System Commands The following contains the SCPI system commands that the GPIB, RS-232 and USB control is compatible with. 7.5.1 SYST:ERR? Syntax SYSTem:ERRor? Description Query the instrument’s error queue. A record of up to N errors is stored in the instrument’s error queue. - Page 54 Remote Operation Example “SYST:ERR?” Result was “1, INVALID CHARACTER”, check for more errors. Description: This error is no longer supported. The error code is maintained and reserved for legacy purposes only. “SYST:ERR?” Result was “2, OUTPUT BUFFER OVERFLOW”, check for more errors. Description: This error is no longer supported.
- Page 55 Remote Operation SYST:ERR?” Result was “10, SWITCH DID NOT RESPOND,x”, check for more errors. Description: Switch x did not respond to a position query. E.g. CAN bus communication failure or damaged switch. SYST:ERR?” Result was “11, SWITCH’S RESPONSE INVALID,x”, check for more errors. Description: Switch x responded but with the wrong response code.
- Page 56 Remote Operation SYST:ERR?” Result was “30, COMMAND UNRECOGNIZED”, check for more errors. Description: This error code is generated when the commanded string does not contain any valid keyword (e.g. Route, System, *IDN?, *RST, ….) at all. SYST:ERR?” Result was “36, ID IS OUT OF RANGE”, check for more errors. Description: A non existing switch ID has been commanded.
-
Page 57: Syst:serialnumber
Remote Operation 7.5.2 SYST:SERIALNUMBER? Syntax SYSTem:SERIALNUMBER? Description Returns the matrix serial number. Result Possible error codes None... -
Page 58: Syst:status
Remote Operation 7.5.3 SYST:STATUS? Syntax SYSTem:STATUS? Description This command will return all Switch positions, Local/Remote mode, Power supply status, High temperature alarm status, Fan stall alarm and Errors list separated by a semicolon. The status response will reflect ALL items in the matrix, while the error portion of the response is limited to the first 20 errors. -
Page 59: Syst:screensaver
Remote Operation 7.5.4 SYST:SCREENSAVER? Syntax SYSTem:SCREENSAVER? Description This command will return the screen saver time settings n (n is in minutes). Possible values for n are 0, 2, 3, 4, 5, …… Note that 1 is not a valid value. 0 = Screen saver is disabled Possible error codes Factory default value... -
Page 60: Syst:gpibaddress
Remote Operation 7.5.6 SYST:GPIBADDRESS? Syntax SYSTem:GPIBADDRESS? Description This command will return the matrix’s GPIB address. Possible values are 1 to 30 Possible error codes Factory default value Power on behavior Keeps last value *RST effect None 7.5.7 SYST:GPIBADDRESS x Syntax SYSTem:GPIBADDRESS x Description This command will set the GPIB address to x. -
Page 61: Remote Operation
Remote Operation Switch [Module] Command Set The following contains the switch [module] commands of SCPI that the GPIB / RS 232 / USB control is compatible with. 7.6.1 :SWITch<id>[:VALue] <number> Syntax [ROUTe]:SWITch<id>[:VALue] <number> Description This command is used to control the position of the switches. The switch specified by the numeric suffix <id>... -
Page 62: Setting Switch X To Position N
Remote Operation 7.6.2 Setting switch x to position n x = switch [module] address. n = position to set and must be within the switches parameter. (Example: SP10T valid positions are 0 thru 10 only). Examples: • ROUTE:SWITCHx n • ROUT:SWITCHx n •... -
Page 63: Requesting Switch X Current Position
Remote Operation 7.6.3 Requesting Switch x current position x = switch address. Examples: • ROUTE:SWITCHx? • ROUT:SWITx? • :SWITx? Result: Returns the current position of switch x. Possible error codes 10, 11, 12, 13 Timing The timing to execute a command depends on the length of the command (in case of concatenated commands). - Page 64 Remote Operation This page intentionally left blank...
- Page 65 GPIB, RS232 and USB Command description for standard matrices Command Syntax Response Action Returns string in ’Model Name’ in the configuration file. As a minimum will have model name. *IDN? MP-2U18S-30-GPIB Could also have: Vendor, model, serial number, firmware revision (The response shown in this table is just an example).
- Page 66 Remote Operation Note: 1. Commands are NOT case sensitive. 2. For GPIB communication no ASCII termination is required, but the End Or Identify (EOI) line shall be asserted at the end of each command. 3. Every command and response on the serial or USB port shall have “\r\n” Carriage return (0x0D) and Line Feed (0x0A) at the end.
-
Page 67: Technical Specifications
Appendix A Technical Specifications Model: MP-2U18S-30-GPIB Configuration: 4 SP10T switches mounted on the rear panel connected in a 1x30 multiplexing configuration RF Connectors: SMA (on rear panel) Frequency range: DC to 18 GHz Return loss (VSWR) Insertion loss Isolation RF Power: Frequency (GHz): ... -
Page 68: Rf Configuration
Appendix B RF Configuration Model: MP-2U18S-30-GPIB Four normally open SP10T switches (Dow-Key part number: 5A1-520802N-ROHS) mounted on the rear panel. The switches are interconnected in a 1x30 multiplexing configuration as shown below. N.C. = Not Connected These ports are not connected as part of the 1x30 configuration, but are working ports. So this matrix could be considered a 1x37 configuration (although 7 ports will have lower insertion loss then the remaining 30 ports). - Page 69 Appendix B The end user shall reconnect the RF cables as per the schematic above and picture below. Cable #3 Cable #2 Cable #1 Note: Although the above picture is showing a Ethernet matrix model all RF considerations and information in Appendix B are valid.
